  • Page 1 Communication module GSM LT-1 Firmware version 1.14 gsmLT-1_en 04/13 SATEL sp. z o.o. ul. Schuberta 79 80-172 Gdańsk POLAND tel. + 48 58 320 94 00 info@satel.pl www.satel.eu...
  • Page 2 Directive 1999/5/EC. The declaration of conformity may be consulted at www.satel.eu/ce The SATEL's goal is to continually upgrade the quality of its products, which may result in alterations of their technical specifications and firmware. The current information on the introduced modifications is available on our website.

  • Page 3: Table Of Contents

    5.2.3 Main menu of D 10 program ......................15 LOAD 5.2.4 Status bar ............................16 5.2.5 Changing the program access code ....................16 5.2.6 "GSM LT-1" tab ..........................17 5.2.7 "Reporting" tab ..........................22 5.2.8 "TCP/IP downloading" tab.........................26 5.2.9 "Firmware update" tab........................27 5.2.10 "Events buffer" tab ..........................28 ................

  • Page 4: Gsm Lt-1 Module Features

    GSM LT-1 SATEL 1. GSM LT-1 MODULE FEATURES  Simulation of analog telephone line when using the GSM connection.  Built-in industrial GSM telephone working in 850/900/1800/1900 MHz cellular telephony networks.  Capability of remotely checking the status of available resources and the account validity of SIM card installed in the module.

  • Page 5: Integration With Integra Control Panels

    SATEL GSM LT-1 INTEGRA NTEGRATION WITH CONTROL PANELS Fig. 1. Module working in conjunction with the INTEGRA control panel. When connected to the INTEGRA control panel, the module offers the following benefits:  transmission of event codes to the monitoring station via GSM network;...

  • Page 6: Pbx

    It can be used to make outgoing calls to the mobile phone numbers and thus optimize the costs incurred. ESCRIPTION OF THE MODULE ESCRIPTION OF THE ELECTRONICS BOARD Fig. 3. View of GSM LT-1 module electronics board. Explanations for Fig. 3: 1 - external antenna connection. 2 - GSM industrial telephone.

  • Page 7: Led Indicators

    SATEL GSM LT-1 must be activated in the SIM card installed in the module, if the module is to use the functions requiring the GPRS technology. 4 - LEDs (see: section „LED indicators”):  STAT LED indicate the module status, ...

  • Page 8: Installation

    GSM LT-1 SATEL – PUK2 code required, – SIM card busy, – module restart on switching power on, – SIM card damaged, – invalid SIM card, – other errors, – active connection. SIG indicates level of signal received by GSM telephone: –...

  • Page 9: Programming

    SATEL GSM LT-1 9. If the module is to be used as the external modem, connect the module RS-232 port to the suitable port of the device. Fig. 4. Installing the SIM card. 5. P ROGRAMMING You can configure the module using the keypad of telephone connected to the R-1 and T-1 terminals, or a computer with suitable software installed (locally and remotely).

  • Page 10: Function List

    GSM LT-1 SATEL the required parameters. To enter digits, use the number keys. You can also enter special characters: # - press in turn the [ * ] and [1] keys; * - press twice the [ * ] key;...
  • Page 11 SATEL GSM LT-1 [12 ** ] – a six-digit access code, necessary to program the module using a telephone set. In the module with factory default settings, the 123456 value is programmed. The code can only be checked in the D 10 program (see: "Access code"...
  • Page 12 GSM LT-1 SATEL 2 – 5 h 57 min, 3 – 11 h 56 min, 4 – 23 h 55 min, 5 – 2 d 23 h 53 min, 6 – 6 d 23 h 30 min. Having entered the parameter, you can either confirm it at once with the [#] key or enter...
  • Page 13 SATEL GSM LT-1 [41 ** ] – a sequence of up to 4 digits which will replace the "+" character in the phone number from which the CLIP connection is established to the module. [97 ** ] – parameter defining whether the module is to execute the reporting function: 0 –...

  • Page 14: Dload 10 Program

    10 program version 1.00.039 is required for programming and configuration of the LOAD GSM LT-1 module version 1.14. The program is delivered free of charge with the device. Communication between the program and the module can be effected locally or remotely.
  • Page 15 SATEL GSM LT-1 Fig. 5. Computer connection to the module RS-232 port. Shown on the left is the PIN-5 plug to be connected into the module connector. Shown on the right is DB-9 female plug (solder side view). A ready cable is offered in the DB9F/RJ-KPL set.

  • Page 16: Remote Programming

    LOAD The remote programming is available after the following items have been programmed:  in the "GSM LT-1" tab:  PIN code of the SIM card (if PIN code is required by the card);  access point name (APN) for the Internet GPRS connection ("GPRS APN" field);...

  • Page 17: Main Menu Of Dload 10 Program

    SATEL GSM LT-1 In order to establish communication between the module and the computer do the following: 1. Start the D 10 program. LOAD 2. Select the "TCP/IP" in the "Communication" menu. A window will open in which information on server activation will be displayed (see: Fig. 8).

  • Page 18: Status Bar

    GSM LT-1 SATEL Explanations for Fig. 9: - GSM module type. - module firmware version (version number and build date). - information on the status of communication between module and program. - time and date according to the module clock. When logging into the network, the module updates these data automatically, if the operator whose services are used by the module offers such a function.

  • Page 19: Gsm Lt-1" Tab

    (in the "File" menu, select "Configuration", and then "Dload10 users" – see: Fig. 11). 5.2.6 "GSM LT-1" tab Shown in square brackets are the numbers of functions for the DTMF programming mode. Fig. 12. "GSM LT-1" tab.
  • Page 20 GSM LT-1 SATEL PIN code [01] – PIN code of SIM card. Entering a wrong code may result in blocking the SIM card. SMS center no. [02] – telephone number of the short message service center (up to 16 characters). If the number has been written by the operator to the memory of SIM card installed in the device, it need not be entered.
  • Page 21 SATEL GSM LT-1 DNS server – IP address of DNS server to be used by the module. It is necessary for GPRS communication, when the address of device to which the control panel is to connect (monitoring station, computer with D...
  • Page 22 GSM LT-1 SATEL and the D 64 program (this applies to the CA-64 control panel firmware version LOAD 1.04.03 or newer, and the D 64 program version 1.04.04 or newer). LOAD The SMS message sent to the module may have the following form: xxxxxx=yyyy. or xxxxxx=yyyy=, where "xxxxxx"...
  • Page 23 SATEL GSM LT-1  the number to which the SMS message is sent, if the module fails to send the event code to the monitoring station (see: "Tel. number" p. 25). No voltage on T-1/R-1 if GSM trouble [17] – if this option is enabled, voltage on the telephone line terminals will be turned off in case of the GSM telephone trouble.

  • Page 24: Reporting" Tab

    GSM LT-1 SATEL Autorestart every [113] – you can program the time period after which the module, if not used, will restart the telephone. From 1 to 25 hours can be entered. The "use" of the module shall be understood as: ...
  • Page 25 SATEL GSM LT-1 Events buffering – the option is available in the module with built-in GSM u-blox LEON-G100 telephone. It refers to the events received from the INTEGRA control panel through the RS-232 port and the test transmissions sent by the module to the monitoring stations.
  • Page 26 GSM LT-1 SATEL Reporting test send all media – if this option is enabled, the module test transmission is sent over all links which have been programmed using the "Priority" function. If the "Events buffering" option is enabled and the test transmission is sent over all links, the "Events buffer"...
  • Page 27 SATEL GSM LT-1 starting from the first reporting link on the list, only after 7.5 minutes have elapsed since sending the last event. Telephone numbers CDS reporting – the telephone number to which events are reported using the CSD technology. It must be preceded by the country code.

  • Page 28: Tcp/Ip Downloading" Tab

    GSM LT-1 SATEL 5.2.8 "TCP/IP downloading" tab Fig. 14. "TCP/IP downloading" tab. Most of the parameters required for correct communication between the module and the D 10, D X and G X programs using the GPRS technology can only be...

  • Page 29: Firmware Update" Tab

    10 program. LOAD For information on the firmware update server please visit the www.satel.eu site. Update server – the address of server to which the module is to connect for firmware update. It can be entered as an IP address or as a name.

  • Page 30: Events Buffer" Tab

    GSM LT-1 SATEL Server from SMS – if this option is enabled, the address of server, to which the module is to connect, and the port number can be entered in the content of SMS message initiating the connection. If the address is not entered, the module will connect to the server whose address has been programmed in the module.

  • Page 31: Remote Control By Means Of Sms Message

    SATEL GSM LT-1 The events are presented in the descending order (the newest at top, the oldest at bottom). The individual columns show the following information: Received – the date when event was received by the module. Send – the date when event was sent by the module to the monitoring station.

  • Page 32: Starting The Gprs Reporting

    GSM LT-1 SATEL The module offers the following forms of event code sending to the monitoring station:  GPRS – packet data transmission.  CSD – data transmission.  SMS – SMS messages. If the event code is sent using an SMS message, the module will not receive the acknowledgement of receipt of the event code by the monitoring station.

  • Page 33: Starting The Csd Reporting

    SATEL GSM LT-1 TARTING THE REPORTING  Select CSD as the reporting link (see: "Priority" p. 24).  Program the telephone number for CSD reporting (see: p. 25). TARTING THE REPORTING  Select SMS as the reporting link (see: "Priority" p. 24).

  • Page 34: Converting The Pager Type Messages Into Sms Messages

    GSM LT-1 SATEL  the call is answered. If the mobile phone of the message addressee is turned off or out of the network range, and the voice mail service is not active, an automatic message about the existing situation can be generated in the telephone receiver and no number busy signal is sent back.

  • Page 35: Initiating The Module Firmware Update By Sms Message

    SATEL GSM LT-1  pressing in turn the numeric key and [ * ] means entering the letter on the left-hand side of the given key;  pressing in turn the numeric key and [#] means entering the letter on the right-hand side of the given key;...

  • Page 36: Restoring The Factory Settings

    Call the function [13**], enter the digits 1234 and confirm using the # key. The factory settings will be restored. 12.3 M ODULE FACTORY SETTINGS LOAD "GSM LT-1" tab: Modem format: auto Acces code: 123456 RS-232 baud rate: 19200 bps Enabled options:...

  • Page 37: Specifications

    SATEL GSM LT-1 No voltage on T-1/R-1 if GSM trouble Generate routing signal Convert "+" to digits: 00 CLIP answering: no Number of retries: 3 Messaging trouble SMS: CLIP failed Autorestart every: 24 h "Reporting" tab: Enabled options: Events buffering...
