- Page 1 User manual Blind 2K Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions…………………………………………………………………………………3 Technical Specifications……………………………………………………………………………4 Control Menu ………………………………………………………………………………………4-6 DMX Channels ………………………………………………………………………………………7 Trouble Shooting……………………………………………………………………………………8 Fixture Cleaning………………………………………………………… …………………………8 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit. -
Page 4: Technical Specifications
2.Technical Specifications Voltage: AC100 ~ 240V 50 / 60Hz Light source: 2*100W high bright COB LED Control mode: DMX512, self-propelled, master-slave, voice control, RDM. Channel: CH4/ CH9 Dimming: 32-bit 0 ~ 100% linear dimming Operating temperature: - 30 ℃ ~ 50 ℃ Stroboscopic frequency: 1 ~ 30Hz IP rating: IP65 NW: 5KGS... - Page 5 B255 Y（000—255） C、C Key to change brightness O255 Y（000—255） B、C Key to change brightness 2.Backstage display window function Display Function R235 W Current，（020—255）default value (235) G235 W Current，（020—255）default value(235) B235 Y Current，（020—255）default value(235) Y Current，（020—255）default value (235) O235 n255 Total power limit，（050—255）default value(255No limit) LEdF (Host background setting parameters) Do not push to the slave default value (LEdF) LEdO The host pushes to the slave to update the slave...
- Page 6 60 seconds when the light is off. FAN0 The fan is not controlled by temperature or light (always running) CH-A (CH-A) Channel mode switch Default value (CH-A) 1 Master 2 Strobe 3 Function 4 Speed 5R 6G 7B 8W (CH-b) Channel mode switch 1 Master 2R 3G 4B 5W 6 Strobe 7 Function 8 Speed F-14...
-
Page 7: Dmx Channels
4.DMX Channels Channel Function Describe 1 CH Overall dimming, linear dimming, from dark to bright Total dimming Total strobe Total strobe, from slow to fast 0-5 empty; 6-100 jump change Feature Selection 101-150 gradual change 151-200 pulse change 201-255 voice control Function speed Function speed, from slow to fast W Dimming... -
Page 8: Trouble Shooting
5.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
