- Page 1 User manual 280 LED BSW Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions………………………………………………………………………………3 Technical Specifications…………………………………………………………………………4 Control Menu ……………………………………………………………………………………5-8 DMX Channel ……………………………………………………………………………………8-10 Dimension…………………………………………………………………………………………10 Trouble Shooting…………………………………………………………………………………11 Fixture Cleaning………………………………………………………… ………………………11 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit. -
Page 4: Technical Specifications
2.Technical Specifications 280W LED BSW 3-in-1 moving head Optics: Light Source:280W white LED beam angle:6°-28° power:380W LED color temperature: 8000K Input voltage:AC100-240V 50-60HZ Pan movement:540° (16bit precision scan) electronic error correction Tilt movement:270°(16bit precision scan) electronic error correction Color: 9 colors + Open，Split Color ,continue bi-directional rotating Fixed patterns: 12 fixed patterns + white light Static gobo wheel：9Gobo+Open and gobo shake , gobo continue bi-directional rotating rotating gobo wheel: 7 gobo + open ,and gobo shake , gobo continue bi-directional rotating... -
Page 5: Control Menu
Control Menu Configuring the Starting Address Each fixture requires a starting address from 1~512. A fixture requiring one or more channels for control begins to read the data on the channel indicated by the starting address. For example, a fixture that uses seven DMX channels and is addressed to start on DMX channel 100, will read data from channels: 100, 101, 102, 103, 104, 105 and 106. - Page 6 2 Operation and parameter instruction Via following operation, enter sub menu(parameter menu) shown in figure3 In main menu, click [UP] [DOWN] [RIGHT] [OK] button into corresponding parameter menu. Set DMX Address Click and select the "ADDR", can enter the page of DMX address setting, range from 1 to 512, the address code shouldn’t is not greater than (512- channels quantity), otherwise the light will not been controlled.
- Page 7 Set display Light support 2 language, rotation display，Enter page as shown in figure 6 to set parameter following: Language：Select display as simplified Chinese or English. Screen Saver ： when panel is idle(these is no operation in 10 second), displayer will enter saver status. ...
-
Page 8: Dmx Channel
Lamp up when: Select lamp on mode, includes 3 mode: power on, after reset done and manual； Factory setting: restore all parameter to factory setting. View status Enter the page as shown in figure 3 , View light current status, version； ... - Page 9 Open 10-19 Gobo 1 20-29 Gobo 2 30-39 Gobo 3 40-49 Gobo 4 50-59 Gobo 5 60-69 Gobo 6 70-79 Gobo 7 80-89 Gobo8 90-99 Gobo 9 100-109 Gobo 1 shake from slow to fast CH10 Fix Gobo 110-119 Gobo 2 shake from slow to fast 120-129 Gobo 3 shake from slow to fast 130-139...
-
Page 10: Dimension
CH14 prism 128-187 Prism 1 188-195 Prism 2 0-127 Rotation from 0-400 degree 128-187 Forwards rotation from fast to slow CH15 Prism rot 188-195 Stop 196-255 Backwards rotation from slow to fast 0-127 No function CH16 Frost 128-255 Frost CH17 Zoom 0-255 CH18... -
Page 11: Trouble Shooting
6.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
