- Page 1 User manual 200 LED BSW Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 Technical Specifications…………………………………………………………………………4 Control Menu ……………………………………………………………………………………5-7 DMX Channels ……………………………………………………………………………………7-9 Dimension …………………………………………………………………………………………10 LUX DATA …………………………………………………………………………………………10 Trouble Shooting…………………………………………………………………………………11 Fixture Cleaning………………………………………………………… ………………………11 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •... -
Page 4: Technical Specifications
fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture. •The equipment must be fixed by professionals. -
Page 5: Control Menu
3.Control Menu 1 — Displays the current DMX address in large font 2 — Logo display area 3 — DMX signal frame rate (FPS) 4 — Current channel mode, the displayed number indicates the current channel number 5 — Show current temperature 6 —... - Page 6 for factory test. User program: run user self-programming program. The editing scene can be set in the [Run Settings] - [Self-Programming] menu. Manual Manually set the value of the channel Run Settings Run parameter settings. Master-slave mode set master-slave mode XY axis general settings X-axis reverse Select "Yes"...
-
Page 7: Dmx Channels
Error Display error message (if any item in this menu is wrong, an exclamation mark will be displayed in the upper right corner of the menu cover) Storage Indicates whether the storage is functioning normally. If the memory is abnormal, the menu information cannot be recorded or read, and the lamp time record and self-programming data may also be lost. - Page 8 252-255 Open color wheel Color 1 (white light) 8-15 color 1+color 2 16-23 color 2 24-31 color 2+color 3 32-39 color 3 40-47 color 3+color 4 48-55 color 4 56-63 color 4+color 5 64-71 color 5 72-79 color 5+color 6 80-87 color 6 88-95...
- Page 9 16-25 GOBO2 26-35 GOBO3 36-45 GOBO4 46-55 GOBO5 56-65 GOBO6 66-75 GOBO7 76-92 GOBO 1shaking from slow to fast 93-109 GOBO 2 shaking from slow to fast 110-126 GOBO 3 shaking from slow to fast 127-143 GOBO 4 shaking from slow to fast 144-160 GOBO 5shaking from slow to fast 161-177...
-
Page 10: Dimension
5.Dimension 6.LUX DATA... -
Page 11: Trouble Shooting
7.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
