- Page 1 User manual LED PROFILE FIX Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3 2. Technical Specifications………………………………………………………………………4 3. Descriptions………………………………………………………………………………………5 4. Unpacking…………………………………………………………………………………………5 5. Control Menu ……………………………………………………………………………………6-7 6. DMX Channels ……………………………………………………………………………………7 7. Dimension …………………………………………………………………………………………8 8. Trouble Shooting…………………………………………………………………………………9 9. Fixture Cleaning………………………………………………………… ………………………9 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit. -
Page 4: Technical Specifications
2.Technical Specifications Light Source: LED POWER: 300W LED Color: CW 5600k or WW 3200K (300W) COB LED Color Rendering Index(CRI): Ra≥90 LED Life Time: over 50,000 hours Power supply: Voltage: AC100-240V Max.power: 300W Optics: Fixed Lens: 19°/26°/36°/50°(optional) LED Life Time: over 50,000 hours Iris: optional Color Frame: optional Features:... -
Page 5: Descriptions
Meanwhile, please keep this manual well for future needs. LED PROFILE FIX is made of a new type of high temperature strength of die cast aluminum casing with nice outlook. The fixture is designed and manufactured strictly following CE&RoHS standards, complying with international standard DMX512 protocol. -
Page 6: Control Menu
5.Control Menu Operation Status Mode Display Description “A”stand for standard channel mode,，“xxx”stand for ID address DMX Mode Axxx “D”stand for basic channel mode，“xxx”stand for ID address Dxxx “S”stand for stand alone mode，“MC”stand for“Mixed Color” Manual Mode S-MC DMX Settings Menu Operation Option Description... -
Page 7: Dmx Channels
Settings Menu Operation Option Description Touch Screen Calibration Touch screen adjust Dimmer Frequency Change the dimmer 500HZ frequency …… Each 100HZ for increase or decrease 25000HZ Standard Incandescent Dimmer Curve Change dimmer curve Linear Quick Over Temperature Temperature setting 45~95 Each 5 for increase or decrease Backlight Adjust... -
Page 8: Dimension
7.Dimension Size of the fixture: 767.6(D)*297.3(W)*273.7(H)mm... -
Page 9: Trouble Shooting
8.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
