- Page 1 User manual 20 MINI SPOT Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3 2. Technical Specifications………………………………………………………………………4 3. Descriptions………………………………………………………………………………………5 4. Unpacking…………………………………………………………………………………………5 5. Control Menu ……………………………………………………………………………………6-8 6. DMX Channels ……………………………………………………………………………………8 7. Dimension …………………………………………………………………………………………9 8. Trouble Shooting…………………………………………………………………………………10 9. Fixture Cleaning………………………………………………………… ………………………10 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit. -
Page 4: Technical Specifications
2.Technical Specifications Light Source: LED POWER: 20W LED Color: single WW / CW Color Rendering Index(CRI): Ra≥90 LED Life Time: over 50,000 hours Power supply: Voltage: AC100-240V Max.power: 20W Optics: Fixed Lens: 19°/26°/36°/50°(optional) Iris: optional Color Frame: optional Features: Focus: Can be adjusted by hand Light body: Die-casting Aluminum Body color: Black / White Feature of housing: Small volume, lightweight... -
Page 5: Descriptions
Meanwhile, please keep this manual well for future needs. The 20 MINI SPOT is made of a new type of high temperature strength of die-casting aluminum with nice outlook. The fixture is designed and manufactured strictly following CE standards, complying with international standard DMX512 protocol. -
Page 6: Control Menu
5.Control Menu MENU DOWN ENTER Main key 【MENU】 Main menu or back the last menu Choosing data value 【UP】 【DOWN】 Choosing data value Enter, choose the vice menu or end edit. 【ENTER】 Combination key Combination by 2 or more key. Such as “UP+DOWN” Press UP and DOWN at the same time. Combination key of “UP+DOWN”... - Page 7 Current adjustment Keyboard current adjustment Under any main menu item, press and hold the MENU, after about 3 seconds to enter the "keyboard current adjustment" mode, Then can adjust the current . Proceed as follows: 1、 First see the "r030". "R" stands for red, so only red will be lit at this time, and the other colors will turn off automatically.
-
Page 8: Dmx Channels
LED show English Word/function key operation Description LED waiting time UP/DOWN choose the waiting time 0 = no screen protect Screen protect time High Power UP/DOWN choose high power or not On = 100% off = 33.3% Power choose dMX-controller delay UP/DOWN choose use the controller delay or not controller delay... -
Page 9: Dimension
7.Dimension Size of the fixture: 269(D)*122(W)*122(H)mm... -
Page 10: Trouble Shooting
8.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
