Summary of Contents for Uplus Lighting 200 BLINDER
- Page 1 User manual 200 BLINDER Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions…………………………………………………………………………………3 2. Technical Specifications……………………………………………………………………………4 3. Control Menu …………………………………………………………………………………………4 4. DMX Channels ………………………………………………………………………………………5 5. Trouble Shooting……………………………………………………………………………………6 6. Fixture Cleaning………………………………………………………… …………………………6 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit. -
Page 4: Technical Specifications
2.Technical Specifications VOLTAGES:AC 100V-240V，50/60Hz 2*100W COB Blinder Light Light source: 2*100W high bright COB LED Color temperature:3200K/6500K Beam Angle: 60゜ DMX Channel:4/8 CH CONTROL:DMX512 WORK ENVIRONMENT TEMPERATURE: -10°C-40°C Aluminum housing; IP20 indooor, digital display Good cooling system, over heat protection NW:5 KGS 3.Control Menu Operation method... -
Page 5: Dmx Channels
4.DMX Channels DMX512Control： 8 Channel Model(A001) Display Function Y1、W1、Y2、W2 dimmer : from dark to bright Dimmer Y1 dimmer Y1 dimmer : from dark to bright W1 dimmer W1 dimmer : from dark to bright Y2 dimmer Y2 dimmer : from dark to bright W2 dimmer W2 dimmer: from dark to bright Y1、W1、Y2、W2 strobe: from slow to fast... -
Page 6: Trouble Shooting
5.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
