PZ277EK | Version 1.5.0 | 03/2025
Piezo Tip/Tilt Platforms
Short Instructions
S-3xx
User information
These short instructions contain an overview of the most important safety and handling instructions
for piezo tip/tilt stages (hereinafter referred to as "positioner") with the product codes given above
(x: any number).
Subject to change. These short instructions are superseded by any new release. The latest respective
release is available for download on our website.
Downloading and reading the manual
The actions during installation, startup, operation, and maintenance require additional information
from the manuals of your product. Manuals can be titled as follows: "User Manual", "Technical
Note".
Downloading the manuals from the website
1. Open the website www.pi.ws.
2. Search the website for the product number (e.g., S-331).
3. Select the corresponding product to open the product page.
4. Select the Downloads tab.
à The manuals are shown under Documentation.
5. Select ADD TO LIST for the desired manual and then select REQUEST.
6. Fill out the request form and select SEND REQUEST. The download link will then be sent to the
entered e-mail address.
If you cannot find the manual you are looking for or if you have any questions: Contact our customer
service via service@pi.de.
Physik Instrumente (PI) SE & Co. KG, Auf der Römerstraße 1, 76228 Karlsruhe, Germany
Phone: +49 721 4846-0, Fax: +49 721 4846-1019, info@pi.de, www.pi.ws
M O T I O N
|
P O S I T I O N I N G
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for PI S-3 Series
Summary of Contents for PI S-3 Series
- Page 1 If you cannot find the manual you are looking for or if you have any questions: Contact our customer service via service@pi.de. Physik Instrumente (PI) SE & Co. KG, Auf der Römerstraße 1, 76228 Karlsruhe, Germany Phone: +49 721 4846-0, Fax: +49 721 4846-1019, info@pi.de, www.pi.ws...
- Page 2 Ø Do not open the positioner. Safety Installation instructions Intended use NOTICE! Temperature changes and compressive This product is a laboratory device as defined by stress can induce charges in the positioner. After DIN EN 61010-1. The product is intended for in- disconnection from the electronics, the piezo ac- door use and use in an environment that is free tuators can remain charged for several hours.
- Page 3 Ø Mount the positioner on an even surface Ø Observe the applicable standards for at- with similar thermal expansion properties taching the protective earth conductor. (for recommended flatness, see manual). Ø If there is any vibration in your application, NOTICE! Mirrors not fixed centrically can dam- secure the screw connection for the protec- age the positioner.
- Page 4 Ø Keep the maximum operating voltage as Mounting the mirror low as possible during operation. Ø Discharge the positioner appropriately when it is not in use. Handling of vacuum-compatible products NOTICE! If the piezo actuator is vacuum-com- patible, attention must be paid to cleanliness. Adhesive Ø...
- Page 5 Uneven surface Protective earth connector on the prod- Mirror too big Safety washer Flat washer Cable lug of the protective earth conduc- M4 screw 1. Fasten a suitable cable lug to the protective earth conductor. 2. Affix the cable lug of the protective earth conductor to the protective earth connec- tion using the screw set supplied.
- Page 6 PI equipment made available 3. Check that the positioner is affixed firmly. to the market after 13 August 2005. If you have an old device from PI, you can send it to PI free of charge. Companies Physik Instrumente (PI) SE &...
