AQUA LASER 300 RGB BEAM
PR-8335
The user manual contains important information about the safe installation and use of a projector. Please read
and follow these instructions carefully and keep the manual in a safe place for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AQUA LASER 300 RGB BEAM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PR Lighting AQUA LASER 300 RGB BEAM

Summary of Contents for PR Lighting AQUA LASER 300 RGB BEAM

  • Page 1 AQUA LASER 300 RGB BEAM PR-8335 The user manual contains important information about the safe installation and use of a projector. Please read and follow these instructions carefully and keep the manual in a safe place for future reference. PR LIGHTING LTD.

  • Page 2: Table Of Contents

    / or dealer. Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the delivery date but the light source is not within the warranty.

  • Page 3: Safetyand Warnings

    1. SAFETYAND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. User Electrical Protective High Goggles Warning Flames Manual shock Gloves Temperature ●...

  • Page 4: Instructions

    ●All power cords must conform to related safety and regulations. ●If a projector is not water and dust proof, while being operated it should not be under rains or in humidity to avoid short circuit. ●Do not switch on and off a projector constantly in very short intervals, otherwise the light source’s and other electrical parts’life will be shortened .

  • Page 5: Appearance

    ●To avoid sunlight or other light penetrating into the head via the front lens, resulting in high temperature internally causing damages to a projector. Before power-off, please use Tilt channel to move the head and make the head facing downward. ●Do not use alcohol or other organic solvent to clean the housing to avoid damage.
  • Page 6 Remarks: 1. The distance between the top of the mounting bar and the top of the head; 2. The Distance between the top of the feet and the top the head; 3. The head’s rotating diameter( the minimum distance between 2 neighboring projectors on the truss) Safety cord Warning! For safety, please run the safety cord...
  • Page 7 WARNING: The projector MUST be lifted or carried by the HANDLES instead of clamps. ● .For safety the safety cord should afford 10 times the Projector’s weight. ● POWER CONNECTION ● Connect the power cord as follows: L (live) =brown E (earth) =yellow/green N (neutral) =blue Before power connection, please ensure the power supplied must match what the nameplate says.

  • Page 8: Setupand Configuration

    DMX TERMINATOR CONNECTION Connect a 120 (OHM) resistor across pins 2 and 3 in an XLR plug and insert into the DMX out socket on the last unit in the chain. PIN 2 PIN 3 5. SETUPAND CONFIGURATION FRONT PANELOPERATION ●...

  • Page 9: Operation Menu

    6.OPERATION MENU Menu Sub-menu Option/Value Option/Value DMX address 001~512 DMX channel 19CH Control Mode Artnet sACN Auto Fan mode Low speed High speed Pan inversion Calibration Tilt inversion Motor Config. Chinese Languages English Display inversion Signal on Screen lock-up Factory defaults NO/YES IP:002.000.000.001 Ethernet...

  • Page 10: Dmx Chart

    Tilt fine 000~255 Strobe 000~255 Dimmer 000~255 Laser switch 000~255 000~255 Green 000~255 Gobo 000~255 Frost 000~255 Prism1 000~255 Prism1 rotation 000~255 Prism 2 000~255 Prism 2 rotation 000~255 Focus 000~255 Reset 000~255 Effect motor reset Reset Pan and Tilt motor reset All motor reset 7.
  • Page 11 Gobo4 29-35 36-42 Gobo5 43-49 Gobo6 50-56 Gobo7 57-63 Gobo8 64-70 Gobo9 71-77 Gobo10 78-84 Gobo11 85-91 Gobo12 92-98 Gobo13 99-105 Gobo1 shaking from slow to fast 106-112 Gobo2 shaking from slow to fast 113-119 Gobo3 shaking from slow to fast 120-126 Gobo4 shaking from slow to fast 127-133...

  • Page 12: Error Message

    8. ERROR MESSAGES If any big problems, please stop using the fixture immediately and ask professional technicians for help. Problems Possible causes A if the power cable is connected properly or not Inaction after power on B、fuse blown up C、switching power supply down A、Main board down Not controlled by DMX signal...
  • Page 13 Frost 1 pc of frost filter Focus DMX linear focus Strobe/dimmer Double flag strobe，0.3-25 Hz/ linear dimmer Movements Pan (0°-540°)，Tilt( 0°-270°) with auto positioning correction function Beam angle Beam angle：0.6° Control International standard DMX 512 signal,3pin XLR connectors(optional 5-pin) Other functions Pan and Tilt speeds adjustable DMX,Art-Net and sACN protocols Housing and ingress protection...
  • Page 14 Base installation:(unit: mm) Photometric...

  • Page 15: Circuit Diagram

    9. CIRCUIT DIAGRAM...
  • Page 18 1582 XingyeAvenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. CounterfeitingWill be Prosecuted! P/N: 320021672...

This manual is also suitable for:

Pr-8335

Table of Contents
