- Page 1 Plasma cutter SPARTUS® ProCUT 145CNC User’s manual...
- Page 2 Therefore, our offer covers such a wide assortment of products. Thank you very much for your trust in our company. We would like to invite you to familiarize yourself with the remaining products and offer at www.spartus. info or directly at a local distributor of SPARTUS® products.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1. SAFE USE – HAZARDS ASSOCIATED WITH ARC WELDING AND PLASMA CUTTING ....2 1.1 General safety rules ................................... 2 1.2 Electric shock can kill ................................2 1.3 Welding arc radiation can be dangerous ......................... 3 1.4 Vapours and gases can be dangerous ..........................3 1.5 Noise can be harmful ................................ -
Page 4: Safe Use - Hazards Associated With Arc Welding And Plasma Cutting
USER’S MANUAL 1. SAFE USE – HAZARDS ASSOCIATED WITH ARC WELDING AND PLASMA CUTTING Arc welding and plasma cutting are processes feeder fitted with spool and harness). Care that can pose hazards for the operator and per- shall be taken during manual handling. sons in his vicinity. -
Page 5: Welding Arc Radiation Can Be Dangerous
USER’S MANUAL • Power supply must never be connected Such radiation can be direct or reflected from before the accessories of SK sockets/con- surfaces such as bright metals and light colo- nectors are properly installed in the device. ured objects. •... -
Page 6: Noise Can Be Harmful
USER’S MANUAL Arc welding and allied processes produce wel- in case of an emergency, are in the imme- ding fume which may pollute the atmosphere diate vicinity. surrounding the work. Welding fume is a vary- • In closed rooms or in certain circumstances ing mixture of airborne gases and fine particles during outdoor operations, it may be re- which, if inhaled or swallowed, constitute a... -
Page 7: Fire Or Explosion Hazard
USER’S MANUAL source, observed for an adequate period after its c) effective maintenance of sound protection termination. devices, • „Hot spots” and immediate surroundings d) indication as „ear protection areas” where should be observed until their temperature applicable, has dropped to normal. e) restriction of entry to these „ear protection 1.6.2 Explosion hazard areas”... -
Page 8: Other Hazards
USER’S MANUAL 1.7.4 Moving elements can be dangerous cylinder valve socket when the valve is being opened. • Special valve shield should always be in- stalled during cylinder transportation or when the cylinder is not used. OTHER HAZARDS Arc welding and allied processes carrying other All protective elements and device housing hazards not listed before. -
Page 9: Symbols Used In Instructions
USER’S MANUAL 1.9 EXTRA PRECAUTIONS 1.9.1 Potential risk during plasma cutting • during the plasma cutting – plasma arc temperature exceeds several thousand °C, • large light radiation is accompanied when plasma cutting as a result of burning gases and the igniting of a plasma arc, •... -
Page 10: Electromagnetic Compatibility (Emc)
Methods of reducing electromagnetic interference are listed in detail in the standard EN 60974-9 „Arc welding equipment – Part 9: Installation and use”. 4. CONFORMITY WITH STANDARDS SPARTUS® ProCUT 145CNC plasma cutter is in conformity with the relevant Union harmoniza- tion legislation: LVD 2014/35/UE... -
Page 11: Ce Marking
It is also equipped with an air gouging function. SPARTUS® ProCUT 145CNC are professional plasma cutters that will find application in manu- facturing sectors, industry and as sources of CNC plasma tables. -
Page 12: Technical Parameters Of Device
800 × 260 × 495 7. INSTALLATION AND USE WARNING! SPARTUS® ProCUT machine is intended for professional and industrial applications. Installation and use of the device may only be carried out appropriately trained professionals. Qualified person (def.) A person who has gained the relevant technical education, training took place and / or gained... -
Page 13: Proper Cooling
USER’S MANUAL 7.1 PROPER COOLING The unit should be placed stable on a dry and flat surface. Avoid too much slope and slippery surfaces. Check regularly that the vents (inlet, outlet) are not covered. The minimum distance between the machine vents and walls should be 50 [cm]. 7.2 MOVEMENT AND HANDLING Please take special care when moving the machine. -
Page 14: Connecting To Power Supply
USER’S MANUAL 7.4 CONNECTING TO POWER SUPPLY Requirements for power network parameters (voltage, permissible range of mains voltage fluctuations etc.) are given in the table with technical parameters of device and on the rating plate of cutter. Before connecting the unit to the power source: •... -
Page 15: Device Connection
USER’S MANUAL Use the proper pressure reducer which allows reduction of input pressure to the limit value. To an appropriate working pressure. 1. Make sure that the air filtering block is installed properly. 2. Check, using the PRESSURE button, the pressure coming out of the compressor or installa- tion. -
Page 16: Control Panel
USER’S MANUAL CONTROL PANEL PROCUT 145 CNC MODE LCD display Cutting current knob Cutting mode button: standard cutting/ Air check button grid cutting /air gouging mode Cutting mode: display the cutting mode currently in use. standard cutting grid cutting air gouging mode Pressure: air pressure value currently in use (PSI / BAR). - Page 17 USER’S MANUAL MESSAGES A. „E01 Overheat” message – information about overheating. The alarm will release after the period of fan cooling. You can restart the machine. B. „E10 Missing phase” message – information about the lack of phase. If the input voltage is short of phase, the machine will not work properly, and the following alarm will appear: C.
-
Page 18: Central Connector - Setup Of Pins
7.9 THE PROCESS OF CUTTING SPARTUS® ProCUT 145CNC is equipped in standard with system of contactless arc ignition wit- hout HF – high-frequency generator. There is no need for the nozzle tip to contact the surface to ignite the plasma arc. -
Page 19: The Table Below For The Shift And Scale Selection
USER’S MANUAL 7.10 THE TABLE BELOW FOR THE SHIFT AND SCALE SELECTION Measure an input voltage in the plasma cutter CNC socket (5, 6 pin). Check if it is compatible with required for CNC controller. Maximum voltage 18V. The factory presets the voltage divider to 20:1. To change the voltage divider to a different setting: 1. -
Page 20: Recommended Plasma Torch
USER’S MANUAL 7.11.3 RECOMMENDED SPARTUS® SP45HY / SP85HY / SP125HY PLASMA TORCH hand SPARE PARTS CODE DESCRIPTION CODE DESCRIPTION NW05900 NW51419.16 Hand torch head Nozzle 125A NW03700.60 O-ring NW51419G Gouging nozzle 125A NW05905 Handle with microswitch NW60309A Shield cap 45-85A Swirl ring 45A „Precision Cut”... - Page 21 USER’S MANUAL 7.11.4 RECOMMENDED SPARTUS® SP45MY / SP85MY / SP125MY PLASMA TORCH machine SPARE PARTS CODE DESCRIPTION OPIS NW05910 NW51419.16 Machine torch head Nozzle 125A NW07300.60 O-ring NW60309A Shield cap 45-85A NW07218 Fiberglass positioning tube NW60309AV Shield cap 45-85A Max Life...
-
Page 22: Maintenance
USER’S MANUAL 8. MAINTENANCE WARNING! Before performing any maintenance or repairing of device, it should be disconnect from the power source and wait at least 5 minutes. The voltage accumulated in capacitors should be discharged at this time to a safe level. But even after that operation you should be careful. Maintenance and repair work may be performed only by qualified personnel with the appropriate per- missions. -
Page 23: Troubleshooting
10. TROUBLESHOOTING Not all problems with functioning of the device, are the evidence of failure. You can independently carry out an analysis in search of probable failure. In case of doubt, please contact to SPARTUS® dealer or authorized service center. - Page 24 Notes...
- Page 25 Notes...
- Page 26 Notes...
- Page 27 A masterly combination of high quality production, excellent parameters and ergonomics – these are fea- tures of the SPARTUS® Master series of devices, which were created with demanding welding jobs in mind. Precision, functionality, excellent parameters and resistance to high workloads –...
- Page 28 Videopresentation of products Subscribe to the channel SPARTUS.INFO...
