- Page 1 Plasma cutter SPARTUS® ProCUT 65CNC 105CNC User’s manual...
- Page 2 Therefore, our offer covers such a wide assortment of products. Thank you very much for your trust in our company. We would like to invite you to familiarize yourself with the remaining products and offer at www.spartus. info or directly at a local distributor of SPARTUS® products.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1. SAFE USE – HAZARDS ASSOCIATED WITH ARC WELDING AND PLASMA CUTTING ....2 1.1 General safety rules ................................... 2 1.2 Electric shock can kill ................................2 1.3 Welding arc radiation can be dangerous ......................... 3 1.4 Vapours and gases can be dangerous ..........................3 1.5 Noise can be harmful ................................ -
Page 4: Safe Use - Hazards Associated With Arc Welding And Plasma Cutting
USER’S MANUAL 1. SAFE USE – HAZARDS ASSOCIATED WITH ARC WELDING AND PLASMA CUTTING Arc welding and plasma cutting are processes feeder fitted with spool and harness). Care that can pose hazards for the operator and per- shall be taken during manual handling. sons in his vicinity. -
Page 5: Welding Arc Radiation Can Be Dangerous
USER’S MANUAL • Power supply must never be connected Such radiation can be direct or reflected from before the accessories of SK sockets/con- surfaces such as bright metals and light colo- nectors are properly installed in the device. ured objects. •... -
Page 6: Noise Can Be Harmful
USER’S MANUAL Arc welding and allied processes produce wel- in case of an emergency, are in the imme- ding fume which may pollute the atmosphere diate vicinity. surrounding the work. Welding fume is a vary- • In closed rooms or in certain circumstances ing mixture of airborne gases and fine particles during outdoor operations, it may be re- which, if inhaled or swallowed, constitute a... -
Page 7: Fire Or Explosion Hazard
USER’S MANUAL source, observed for an adequate period after its c) effective maintenance of sound protection termination. devices, • „Hot spots” and immediate surroundings d) indication as „ear protection areas” where should be observed until their temperature applicable, has dropped to normal. e) restriction of entry to these „ear protection 1.6.2 Explosion hazard areas”... -
Page 8: Other Hazards
USER’S MANUAL 1.7.4 Moving elements can be dangerous cylinder valve socket when the valve is being opened. • Special valve shield should always be in- stalled during cylinder transportation or when the cylinder is not used. OTHER HAZARDS Arc welding and allied processes carrying other All protective elements and device housing hazards not listed before. -
Page 9: Extra Precautions
USER’S MANUAL 1.9 EXTRA PRECAUTIONS 1.9.1 Potential risk during plasma cutting • during the plasma cutting – plasma arc temperature exceeds a few thousands °C, • large light radiation is accompanied when plasma cutting as a result of burning gases and the igniting of a plasma arc, •... -
Page 10: Electromagnetic Compatibility (Emc)
USER’S MANUAL 3. ELECTROMAGNETIC COMPATIBILITY (EMC) WARNING! This Class A equipment is not intended for use in residential locations where the electrical power is provided by the public low-voltage supply system. There can be potential difficulties in ensuring electromagnetic compatibility in those locations due to conducted as well radiated radio-frequency disturbances. -
Page 11: Conformity With Standards
USER’S MANUAL 4. CONFORMITY WITH STANDARDS The SPARTUS® ProCUT 65CNC/105CNC is in conformity with the relevant Union harmonization legislation: LVD 2014/35/UE Low Voltage Directive EMC 2014/30/UE Electromagnetic Compatibility Directive harmonized standards: EN 60974-1 Arc Welding Equipment – Part 1: Welding Power Sources EN 60974-10 Arc Welding Equipment –... -
Page 12: Technical Specifications
USER’S MANUAL 6. TECHNICAL SPECIFICATIONS 6.1 OPERATION, STORAGE AND TRANSPORT Conditions during operation, storage and transport Range of ambient air temperature -10°C to +40°C during operation Relative humidity of the air up to 50% at +40°C up to 90% at +20°C Ambient air free from abnormal amounts of dust, acids, corrosive substances etc. -
Page 13: Installation And Use
650 × 240 × 445 650 × 240 × 460 7. INSTALLATION AND USE WARNING! SPARTUS® ProCUT 65CNC/105CNC machine is intended for professional and industrial applications. Installation and use of the device may only be carried out appropriately trained professionals. Qualified person (def.) A person who has gained the relevant technical education, training took place and / or gained experience to perceive the risk and avoid hazards during use of the product (IEC 60204-1). -
Page 14: Connecting To Power Supply
USER’S MANUAL ProCUT 105CNC Transport handle Toggle switch ON/OFF Control panel with cover Air preparation block holder Socket SK „+” Compressed air inlet Air preparation block with pressure Plasma torch socket („-”) reducer CNC socket Pressure regulator knob Unit cover The condensate drain tube 7.4 CONNECTING TO POWER SUPPLY Requirements for power network parameters (voltage, permissible range of mains voltage... -
Page 15: Connection Of The Device
USER’S MANUAL 7.4.1 Scheme of connection of power plug connector 400V L1, L2, L3 Phase conductors Protective conductor Neutral conductor WARNING! It is forbidden bridging PE and N cables. it may cause serious risk of electric shock! In some cases, colours of power cords may vary from those shown on diagram. For example when the device has a four-wired three phase power cord. - Page 16 USER’S MANUAL 6. The working pressure is adjusted with the device turned on. 7. The value of working pressure should correspond to the values recommended (see 6.2). 7.5.3 Connecting the device 1. Connect properly plasma torch into socket (see 7.5.1) 2.
-
Page 17: Central Connector
USER’S MANUAL Power indicator Adjustment knob Two position switch Abnormal indicator – overheating – normal work/gas test Abnormal indicator – secure cap Digital meter – current Amps is mounted incorrectly Indicator - shows that cutting process Digital meter – air pressure bar is carried out (The pilot arc is currently working) 7.6 CENTRAL CONNECTOR –... -
Page 18: The Table Below For The Shift And Scale Selection
Number 7.9 THE PROCESS OF CUTTING SPARTUS® Pro CUT 65CNC / 105CNC are equipped in standard with system of contactless arc ignition with HF – high-frequency generator. There is no need for the nozzle tip to contact the surface to ignite the plasma arc. -
Page 19: Recommended Plasma Torches
USER’S MANUAL 7.10 RECOMMENDED PLASMA TORCHES 7.10.1. Plasma torch SPARTUS® SP80H/SP80M (standard PT80™) for ProCUT 65CNC contact cut gouging CODE DESCRIPTION CODE DESCRIPTION Contact tip φ 1.2 60-70A 51311.12 09800 Hand torch head with handgrip 51311.13 Contact tip φ 1.3 70-80A 1a 51620.60... - Page 20 USER’S MANUAL 7.10.2. Plasma torch SPARTUS® SP100H/SP100M (standard PT100™) for ProCUT 105CNC contact cut gouging...
- Page 21 USER’S MANUAL CODE DESCRIPTION 09700 Hand torch head with handgrip 51190.41 O-ring 09700.48 Water cooling tube 09705 Handle with microswitch (kpl.) 07301.20 Microswitch 09710 Machine torch head 07218 Machine handle 07219 Fiberglass positioning tube with rack ...
-
Page 22: Maintenance
USER’S MANUAL 8. MAINTENANCE WARNING! Before performing any maintenance or repairing of device, it should be disconnect from the power source and wait at least 5 minutes. The voltage accumulated in capacitors should be discharged at this time to a safe level. But even after that operation you should be careful. Maintenance and repair work may be performed only by qualified personnel with the appropriate per- missions. -
Page 23: Troubleshooting
10. TROUBLESHOOTING Not all problems with functioning of the device, are the evidence of failure. You can independently carry out an analysis in search of probable failure. In case of doubt, please contact to SPARTUS® dealer or authorized service center. - Page 24 Notes...
- Page 25 Notes...
- Page 26 Notes...
- Page 27 A masterly combination of high quality production, excellent parameters and ergonomics – these are fea- tures of the SPARTUS® Master series of devices, which were created with demanding welding jobs in mind. Precision, functionality, excellent parameters and resistance to high workloads –...
- Page 28 Videopresentation of products Subscribe to the channel SPARTUS.INFO...
