Q'STRAINT QLK QE-9317 Installation Instructions Manual

M O U N T I N G B R AC K E T I N S TA L L AT I O N I N S T R U C T I O N S
• Some foot rest options will require the user to raise prior to allow docking. Any kerb climbers fitted to the chair may interfere with the docking process
– please ensure at least 85mm ground clearance.
• This is a comprehensive step-by-step instruction guide on how to install the Quantum R-Trak Wheelchair Bracket (Q3 2024; Wheelchair manufacture
date).
• Please note, some images may not be the same colour as the supplied equipment.
• Make sure to read, understand and follow these instructions.
• To address any questions, contact the nearest Q'STRAINT® office.
• All deviations and alterations from these instructions MUST be reported to both your supervisor and Q'STRAINT®
• For installation of the QLK Docking system, please refer to the separate Installation Instructions and the Use and Care Manual.
• All equipment and components MUST be installed and serviced by an
experienced and trained technician.
• The QLK Wheelchair Docking System complies with all applicable
requirements of ADA, FMVSS, CMVSS, SAE J2249, CSA Z604, AS2942, ISO
10542-1 and ANSI/RESNA WC-4 SECTION 18.
• This System is a complete integrated system, do not alter or modify it in any
way and do not interchange or substitute any components. Any deviation
from these recommendations is the responsibility of the installer.
• The QLK Docking System, bracket and its components MUST be regularly
inspected, cleaned, and maintained.
• Do NOT attempt to repair, adjust, or modify any component(s) of the QLK
system or bracket without consulting a Q'STRAINT® representative.
• The QLK Wheelchair Docking System should not be operated by anyone
who does not have full comprehension of how the System works or if the
System is not working properly.
• The QLK Wheelchair Docking System, bracket and all system components
including floor and wall anchorages MUST be replaced after a vehicle
collision.
Q U A N T U M R - T R A K
READ ALL INSTRUCTIONS PRIOR TO INSTALLATION
IMPORTANT SAFEGUARDS AND WARNINGS
SAVE THESE INSTRUCTIONS
• The QLK Wheelchair Docking System MUST be installed with a compliant
occupant restraint system (shoulder and lap belt).
• Broken and worn components MUST be replaced.
• All damages and defects MUST be reported to both your supervisor and
Q'STRAINT®.
• Only use Q'STRAINT® components with this system, including hardware
and wheelchair interface bracket unless otherwise stated.
• Q'STRAINT wheelchair brackets and QLK docking station have been
designed and tested as a system, for use with specific wheelchairs.
Q'STRAINT supply all the components/hardware required to install the
system so the configuration is the same as that tested and set out in the
individual installation instructions. Occasionally, wheelchairs may have
additional components installed which are not detailed in our installation
instructions and which may need to be temporarily removed in order to gain
access to fixing holes or support frames to enable the attachment of the
wheelchair bracket. It is the responsibility of the installer to ensure that all
such wheelchair component(s) are put back in their original location using
the original fixings or fixing of the same size and grade. Each wheelchair
should be test driven after fitment of the bracket, to ensure it is functioning
correctly.
