PD – 309 / 2605 Series
User's Manual
Rev. Original
FCC Notes:
This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions manual, may cause interference to radio
communications. It has been tested an found to comply with limits for a Class A digital
device pursuant to subpart J of Part 15 of FCC Rules, which are designed to provide
reasonable protection against interference when operated in a commercial environment.
Operation of this equipment in a residential area is likely to cause interference in which
case the user at his own expense will be required to take whatever measures to correct
the interference.
Warranty Limits:
Warranty terminates automatically when any person other than the authorized
technicians opens the machine. The user should consult his/her dealer for the problem
happened. Warranty voids if the user does not follow the instructions in application of
this merchandise. The manufacturer is by no means responsible for any damage or
hazard caused by improper application.
About This Manual:
Posiflex has made every effort for the accuracy of the content in this manual. However,
Posiflex will assume no liability for any technical inaccuracies or editorial or other
errors or omissions contained herein, nor for direct, indirect, incidental, consequential
or otherwise damages, including without limitation loss of data or profits, resulting
from the furnishing, performance, or use of this material.
This information is provided "as is" and Posiflex Technologies, Inc. expressly
disclaims any warranties, expressed, implied or statutory, including without limitation
implied warranties of merchantability or fitness for particular purpose, good title and
against infringement.
The information in this manual contains only essential hardware concerns for general
user and is subject to change without notice. Posiflex reserves the right to alter product
designs, layouts or drivers without notification. The system integrator shall provide
applicative notices and arrangement for special options utilizing this product. The user
may find the most up to date information of the hardware from web sites:
http://www.posiflex.com or http://www.posiflex.com.tw
All data should be backed-up prior to the installation of any drive unit or storage
peripheral. Posiflex will not be responsible for any loss of data resulting from the use,
disuse or misuse of this or any other Posiflex product.
All rights are strictly reserved. No part of this documentation may be reproduced,
stored in a retrieval system, or transmitted in any form or by any means, electronic,
mechanical, photocopying, or otherwise, without prior express written consent from
Posiflex Technologies, Inc. the publisher of this documentation.
© Copyright Posiflex Technologies, Inc. 2008
All brand and product names and trademarks are the property of their respective holders.
Part 1
P/N: 19430903010

Advertisement

loading
Need help?

Need help?

Do you have a question about the PD-309 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for POSIFLEX PD-309 Series

  • Page 1 About This Manual: Posiflex has made every effort for the accuracy of the content in this manual. However, Posiflex will assume no liability for any technical inaccuracies or editorial or other errors or omissions contained herein, nor for direct, indirect, incidental, consequential or otherwise damages, including without limitation loss of data or profits, resulting from the furnishing, performance, or use of this material.
  • Page 2: Brief Introduction

    THE PRODUCT The PD-309/ PD-2605 is a pole mount customer display option designed for Posiflex mini slim base of KS-2010 or DT-20X POS terminals. It is delivered in separate carton for the host system and shall be installed per instructions in this manual.
  • Page 3: Installation

    INSTALLATION GUIDES HOST SYSTEM PREPARAION For serial interface (RS232) PD-309 or PD-2605 to be used in KS- 2010 or DT-20X series, you have to adjust during power off the internal jumper of the host system to supply 5 V DC to the COM port selected for the serial interface pole display.
  • Page 4 POWER ON SIGN With interface cable connection well installed (and with COM port power set for serial models), turn on the Posiflex POS system, a firmware identifier as power on sign will appear on the pole display screen for a while to indicate that pole display is self-tested O.K.
  • Page 5 CTS signal to the COM port used. No other driver installation is required. FOR USB INTERFACE MODELS: Copy the driver and library from Posiflex Product Information CD or DVD under \Drivers\PD23_26U to your system or download from web site http://www.posiflex.com.tw/Download%20list.asp?Status=1&Series_Name=P D%20Series&Model_Name=PD-2300U.
  • Page 6: Specification

    WARNING: If the user opens the pole display housing to make any modification, all the product warranty will be voided. NOTE: Please refer to Posiflex Product Information CD or DVD or visit our web http://www/posiflex.com.tw for further information when needed.
  • Page 7 APPENDIX APPLICABLE COMMANDS (FOR PD-309) EPSON COMMAND MODE (POWER ON DEFAULT): NAME HEX CODES FUNCTION <08> Move Cursor Left <09> Move Cursor Right <0A> Move Cursor Down <0B> Move Cursor To Home Position <0C> Clear Display Screen <0D> Move Cursor To Left Most Position <18>...
  • Page 8 <14> <04> Overwrite Mode (Default) <14> <08> Back Space <14> <09> Move Cursor Right <14> <0A> Move Cursor Down <14> <0B> Move Cursor Left <14> <0C> Delete Character <14> <0D> Move Cursor To Left Most Position <14> <0E> Clear Display <14>...
  • Page 9 Move cursor left- Set/cancel user-defined ESC % most char. Define user-defined Clear cursor line ESC & char. Delete user-defined Overwrite mode ESC ? US MD1 char. Vertical scroll mode US @ Show firmware version US MD2 Horizontal scroll Select peripheral US MD3 ESC = mode...
  • Page 10 Clear pass through x1 x2 02 Form feed flag 1B 48 pp Digit select Carriage return 1B 43 ad x1 User defined fonts ~ x5 UTC Pass through mode Command [+data] [+CR] ESC uA Top line message ESC uH Redefine graphic ESC uA CR Clear top line ESC uIx Display fonts...

This manual is also suitable for:

Pd-2605 series
