POSIFLEX PD-300 Seroes User Manual

PD300 SERIES
2 X 20 LCD

CUSTOMER DISPLAY

Rev. : A3
I.

FEATURES

l Low profile customer display with display area 147 mm by 21 mm
l Two - line LCD display with 20 characters per line.
l Dark blue character with yellow green back-light
l Easy viewing characters (6.0 mm by 9.66 mm)
l Euro dollar sign supported in USA/European font table
l Simple installation using standard serial interface to computers
l Selectable command emulation modes including PST and EPSON
command emulation modes
l Long life, trouble free and user friendly operation
l Tilt angle from 0°C to 90°C for best viewing effect (PD303 & PD305)
l Supports applications for desk top stand-alone (PD303), touch terminal
rear top mount (PD302) and rear mount with swivel (PD305).
FCC NOTICE
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions manual, may cause interference to radio communications. It has been tested and found to
comply with limits for a Class A digital device pursuant to subpart J of Part 15 of FCC Rules, which are designed to
provide reasonable protection against interference when operated in a commercial environment. Operation of this
equipment in a residential area is likely to cause interference in which case the user at his own expense will be required to
take whatever measures to correct the interference.
WARRANTY LIMITS
Warranty will terminate automatically when the machine is opened by any person other than the authorized
technicians. The user should consult his/her dealer for the problem happened. Warranty voids if the user does not follow
the instructions in application of this merchandise. The manufacturer is by no means responsible for any damage or
hazard caused by improper application.
ABOUT THIS MANUAL
This manual assists the user to utilize the LCD customer display PD300 series. This series covers several sub
series for various applications. These series of products receive instructions in serial communication protocols and is
capable of entering pass through mode so that all instructions received pass on to next connected serial device if properly
configured.
The manufacturer of the PD300 series heartily apologizes to the user for reserving the right to change or to
modify this manual without notice due to the rapid and constant progress and improvement on science and technology.
The user may always obtain the most up to date information through any of our web sites: http://www.posiflex.com.tw,
http: //www.posiflextw.com, http://www.posiflexusa.com.
TRADE MARKS AND SERVICE MARKS
POSIFLEX is a registered trademark of Mustek Corp..
Other brand and product names are trademarks and registered trademarks and service marks of their respective
owners.
P/N: 19430900040
Copyright Mustek Corp. 2002, 2003
1
PD302
PD303
PD305
