PD-30XUE Series
CUSTOMER DISPLAY
FCC Notes:
This equipment generates, uses, and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions manual, may cause interference
to radio communications. It has been
tested an found to comply with limits for a
Class A digital device pursuant to subpart
J of Part 15 of FCC Rules, which are designed
to provide reasonable protection against
interference when operated in a commercial
environment. Operation of this equipment
in a residential area is likely to cause
interference in which case the user at
his own expense will be required to take
whatever measures to correct the interference.
Warranty Limits:
Warranty terminates automatically
when any person other than the authorized
technicians opens the machine. The user
should consult his/her dealer for the problem
happened. Warranty voids if the user does
not follow the instructions in application of
this merchandise. The manufacturer is by
no means responsible for any damage or hazard
caused by improper application.
About This Manual:
Posiflex has made every effort for the accuracy of the content in this manual. However, Posiflex
will assume no liability for any technical inaccuracies or editorial or other errors or omissions
contained herein, nor for direct, indirect, incidental, consequential or otherwise damages, including
without limitation loss of data or profits, resulting from the furnishing, performance, or use of this
material. This information is provided "as is" and Posiflex Technologies, Inc. expressly disclaims
any warranties, expressed, implied or statutory, including without limitation implied warranties of
merchantability or fitness for particular purpose, good title and against infringement.
The information in this manual contains only essential hardware concerns for general user and is
subject to change without notice. Posiflex reserves the right to alter product designs, layouts or
drivers without notification. The system integrator shall provide applicative notices and
arrangement for special options utilizing this product. The user may find the most up to date
information of the hardware from web sites: http://www.posiflex.com or
http://www.posiflex.com.tw All data should be backed-up prior to the installation of any drive unit
or storage peripheral. Posiflex will not be responsible for any loss of data resulting from the use,
disuse or misuse of this or any other Posiflex product. All rights are strictly reserved. No part of
this documentation may be reproduced, stored in a retrieval system, or transmitted in any form or
by any means, electronic, mechanical, photocopying, or otherwise, without prior express written
consent from Posiflex Technologies, Inc. the publisher of this documentation.
© Copyright Posiflex Technology, Inc. 2013
All brand and product names and trademark are the property of their respective holders.
LCD
PD300UE
PD305UE
PD308UE
PD320UE
PD303UE
PD302UE
PD307UE
PD306UE
PD309UE
PD310AUE
PD330UE
PD340/350UE
19430900080
P/N:

Advertisement

loading
Need help?

Need help?

Do you have a question about the PD-30 UE Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for POSIFLEX PD-30 UE Series

  • Page 1 Posiflex will not be responsible for any loss of data resulting from the use, disuse or misuse of this or any other Posiflex product. All rights are strictly reserved. No part of this documentation may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, or otherwise, without prior express written consent from Posiflex Technologies, Inc.
  • Page 2: Product Model Number

    PRODUCT MODEL NUMBER FEATURES • LCD (Liquid crystal display) with dark blue character and yellow green back-light • Two-line display with 20 characters per line • Easy viewing characters (6.0 mm by 9.66 mm) • Long life and trouble free operation •...
  • Page 3: Mechanical Installation

    MECHANICAL INSTALLATION To fix the rear mount upgrade kit like PD-330UE/340UE/350 UE on the back of XP/XT/HS series, please apply carefully 2 screws that come along with each PD unit. Please take out the main item with bracket from the package, and fix these items as the following steps: PD-350UE for XT series A: Hold the PD unit item then turn the screen facing toward you.
  • Page 4 main unit and fasten them to fix PD on the XP series. PD-320UE For this type of mechanical design of standalone customer pole display, it can operate straight away and no needs to assemble with any other host system. Nevertheless, it also can fix on the counter or any place when it needs to be fixed.
  • Page 5 Picture A is going to describe how to adjust the height of customer displays: a) Please hold the compression lock by using thumb and index finger and pull out the lock. b) Please use the other hand to hold the tube and extend to higher or lower profile of display’s height.
  • Page 6 order to keep the PD-320UE stable. (The screws come with PD-320UE and in the carton.) Picture C, the display head of PD-320UE can move as horizontal direction the right or left, as well as front-rear adjustable degree from 15 or 23 °...
  • Page 7 Do not overdo the tightening or unrecoverable thread damage will occur. PD-309UE for KS or DT series The PD-309UE can be attached to the corner in bottom plate of the KS series, with slim base, DT series and Gen.6 & 5 base of KS series.
  • Page 8 Firstly, place the display head and tube on a flat surface and find the cable in the end of tube. Let this cable pass through the short tube on the base stand, as shown in the picture at right. Next, please assemble the display head with tube to the base stand which shows in the right picture.
  • Page 9 Please then refer to the pictures below for the base unit (lowest part) of PD-307UE with 2 enlarged portions to the right and a slightly enlarged side view picture to the left to find 2 bottom locking lugs A’; 2 short cylindrical locating bosses B’...
  • Page 10 Please always keep a gentle pressure at the bottom end of pole base (bottom locking lugs A’) to the left (away from the sidewall of system chassis) when moving the upper part of pole toward sidewall as in the left picture. Please refer to the right picture taken from inside of HT or PB system to show that the 2 short A’...
  • Page 11 out of its base joint to enter the base of host system through the cable exit to connect to the main unit. Match the base joint of PD-305UE or PD-306UE to the system rear connect area. Fit 2 screws through washers at arrowed points in the right pictures to hold the joint tight.
  • Page 12 For PD-300UE model: B-Type USB Port To Display Head The RJ45 type modular connector is for VFD display purpose and also already occupied. Connect the “B” type plug of the interface cable to the base USB connector and the “A” type end to USB port of the host. Insert the DC plug of 12V DC power adaptor to the “12V DC IN”...
  • Page 13: Driver Installation

    FOR OPOS APPLICATION: Find the subfolder UPOS Drivers > OPOS Driver of the Posiflex Product Information CD or download it from web site http://www.posiflex.com/english/03_support/03_download.php?prod=ajc=&ca te=ajY= and execute the file SETUP.EXE to install the OPOS Control “...
  • Page 14: Applicable Commands

    5% to 90%, non-condensing WARNING: If the user opens the pole display housing to make any modification, all the product warranty will be voided. NOTE: Please refer to Posiflex Product Information CD or visit our web http://www/posiflex.com.tw for further information when needed. APPENDIX...
  • Page 15 n = 0, 13h Disable/Enable Rupee Dollar Sign n= 0, 60h US MD1 <1F><01> Specify Overwrite Mode US MD2 <1F><02> Specify Vertical Scroll Mode US MD3 <1F><03> Specify Horizontal Scroll Mode US LF <1F><0A> Move Cursor Up US CR <1F><0D> Move Cursor To Right Most Position Move Cursor To Specified Position <1F><24><n><m...
  • Page 16 <14> <19> Reset <14> <1A> <P> Move Cursor To Position P (P=0~13,14~27h) <14> <1B> Move Cursor To Rightmost Position Of Line 1 <14> <1C> Move Cursor To Rightmost Position Of Line 2 After selecting code page table 19, the Euro Dollar Sign is designated at code <D5>h.
