RZ/V2N Evaluation Board Kit (Secure type)
4.7

MIPI DSI Interface

The V2NEVK has a MIPI DSI interface. This interface is connected from the RZ/V2N on the CPU board to CN11 and
is connected to CN5 on the EXP board with a dedicated FFC. The EXP board converts MIPI DSI to an HDMI signal
and outputs it to the CN4 HDMI connector.
Table 4.7-1 MIPI DSI Connector (CN11)
Pin No. V2NEVK Connection Destination
1 RZ/V2N (P37)
2 RZ/V2N (P41)
3 RZ/V2N (P40)
4 RZ/V2N (P42)
5 RZ/V2N (P36)
6 GND
7 RZ/V2N (DSI_DNDATA3)
8 RZ/V2N (DSI_DPDATA3)
9 GND
10 RZ/V2N (DSI_DNDATA2)
11 RZ/V2N (DSI_DPDATA2)
12 GND
13 RZ/V2N (DSI_DNDATA1)
14 RZ/V2N (DSI_DPDATA1)
15 GND
4.8

USB Interface

The CPU board of the V2NEVK has the following USB connectors.
●
USB3.2 Gen2 host interface
The USB Type-A connector (CN4) is connected to the USB3.2 Gen2 interface of the RZ/V2N.
●
USB2.0 DRD interface
The USB micro-AB connector (CN2) is connected to the USB2.0 (ch. 0) interface of the RZ/V2N.
4.9

Ethernet Interface

The CPU board of the V2NEVK has two Ethernet interfaces. The RJ-45 connectors (CN5 and CN6) are connected to
the Ethernet interface of the RZ/V2N via the Ethernet PHY IC. Connecting this interface to a public line is prohibited.
R12UZ0157EJ0110 Rev.1.10
Feb 28, 2025
Pin No. V2NEVK Connection Destination
16 RZ/V2N (DSI_DNDATA0)
17 RZ/V2N (DSI_DPDATA0)
18 GND
19 RZ/V2N (DSI_DNCLK)
20 RZ/V2N (DSI_DPCLK)
21 GND
22 RZ/V2N (P71)
23 GND
24 +1.8 V (VDD1G_1p8)
25 GND
26 +3.3 V (D3.3V)
27 GND
28 +5.0 V
G1-5 GND
F1-2 GND
