RZ/V2N Evaluation Board Kit (Secure type)
4.

Interface Specifications

This section describes the interface specifications of the V2NEVK.
4.1

Reset

When resetting the V2NEVK, control it by using the power control switches (SW2, SW3) and software.
4.2

LED

The V2NEVK has seven LEDs. Table 4.2-1 lists the colors and functions of these LEDs.
Table 4.2-1 RZ/V2H Secure Evaluation Board LEDs
LED Color
LD1 Green
LD2 Green
LD3 Green
LD4 Green
LD5 Yellow
LD6 Yellow
LD7 Green
4.3

Switches

The V2NEVK has seven switches. Table 4.3-1 lists the functions of the respective switches.
Table 4.3-1 RZ/V2N Secure Evaluation Board Switches
Switch Shape
DSW1 DIP switch
DSW2 DIP switch
DSW3 DIP switch
JSW1 DIP switch
SW1 Push switch
SW2 Slide switch
SW3 Slide switch
R12UZ0157EJ0110 Rev.1.10
Feb 28, 2025
Function/Usage
PMIC_PWRON indicator
Power D5.0V1 (5 V) indicator
Power VDD1G_1p8 (1.8 V) indicator
Power S1.8V (1.8 V) indicator
Signal monitor
Signal monitor
Power USBC_VBUS_OUT (20 V) indicator
Usage
Mode setting (see Section 2.2, Mode Setting)
Mode setting (see Section 2.2, Mode Setting)
Mode setting (see Section 2.2, Mode Setting)
Mode setting (see Section 2.2, Mode Setting)
NMI
Power switch (PMIC_RAA215300 ON/OFF)
Power switch (USBC VBUS OUT 20V ON/OFF)
