RZ/V2N Evaluation Board Kit (Secure type)
Table 4.18-3 Pmod Type 3A UART (CN3)
Pin No. Pmod Pin Spec.
1 CTS
2 TXD
3 RXD
4 RTS
5 GND
6 VCC
7 IO1
8 IO2
9 IO3
10 IO4
11 GND
12 VCC
Table 4.18-4 Pmod Type 6A I2C (CN6)
Pin No. Pmod Pin Spec.
1 IO1
2 IO2
3 SCL
4 SDA
5 GND
6 VCC
7 IO3
8 IO4
9 IO5
10 IO6
11 GND
12 VCC
R12UZ0157EJ0110 Rev.1.10
Feb 28, 2025
V2NEVK Connection Destination
RZ/V2N (P52) via level shifter U6
RZ/V2N (P50) via level shifter U6
RZ/V2N (P51) via level shifter U6
RZ/V2N (P53) via level shifter U6
GND
+3.3 V (D3.3V)
RZ/V2N (P57) via level shifter U6
RZ/V2N (P73) via level shifter U6
RZ/V2N (P76) via level shifter U6
RZ/V2N (P77) via level shifter U6
GND
+3.3 V (D3.3V)
V2NEVK Connection Destination
RZ/V2N (P55) via level shifter U7
RZ/V2N (P54) via level shifter U7
RZ/V2N (P21) via level shifter U7
RZ/V2N (P20) via level shifter U7
GND
+3.3 V (D3.3V)
RZ/V2N (P70) via level shifter U7
RZ/V2N (P72) via level shifter U7
RZ/V2N (P90) via level shifter U7
RZ/V2N (P91) via level shifter U7
GND
+3.3 V (D3.3V)
4. Interface Specifications
