- Page 1 *31963978_0424* Drive Technology \ Drive Automation \ System Integration \ Services Manual Configuration Tool ® MOVISAFE F-Protocol Editor Edition 04/2024 31963978/EN...
- Page 2 SEW-EURODRIVE—Driving the world...
- Page 3 Table of Contents Table of Contents General information ........................ 4 About this documentation .................... 4 Content of the documentation.................. 4 Other applicable documentation .................. 4 Structure of the safety notes ................... 5 1.4.1 Meaning of signal words ................. 5 1.4.2 Structure of section-related safety notes ............ 5 1.4.3 Structure of embedded safety notes............... 5 Decimal separator in numerical values ................ 6...
- Page 4 General information About this documentation General information About this documentation This documentation is an integral part of the product. The documentation is intended for all employees who perform work on the product. Make sure that this documentation is accessible and legible. Ensure that persons re- sponsible for the systems and their operation as well as persons who work with the product independently have read through the documentation carefully and understood it.
- Page 5 General information Structure of the safety notes Structure of the safety notes 1.4.1 Meaning of signal words The following table shows the grading and meaning of the signal words for safety notes: Signal word Meaning Consequences if disregarded DANGER Imminent hazard Severe or fatal injuries Possible dangerous situation Severe or fatal injuries...
- Page 6 General information Decimal separator in numerical values Decimal separator in numerical values In this document, a period is used to indicate the decimal separator. Example: 30.5 kg Rights to claim under limited warranty Read the information in this documentation. This is essential for fault-free operation and fulfillment of any rights to claim under limited warranty.
- Page 7 Safety notes Preliminary information Safety notes Preliminary information The following general safety notes serve the purpose of preventing injury to persons and damage to property. They primarily apply to the use of products described in this documentation. If you use additional components, also observe the relevant warning and safety notes.
- Page 8 Safety notes Designated use 2.3.3 IT security of the environment For drive and control components that are integrated into a network (e.g. a fieldbus, WLAN, or Ethernet network), it is possible to make settings even more remotely. This brings with it the risk of a parameter change that is not visible externally resulting in unexpected, but not uncontrolled system behavior, and this may impact negatively on operational security, system availability, or data security.
- Page 9 Introduction Short designation Introduction Short designation The following short designations are used in this document. Type designation Short designation ® Decentralized inverter from the MOVI‑C Inverter modular automation system: ® • MOVIMOT flexible MMF..-C/DFC.. ® • MOVIGEAR performance MGF..-DFC-C ® •...
- Page 10 Installation of the MOVISAFE® F-Protocol Editor IT security Installation of the MOVISAFE® F-Protocol Editor IT security If you need support with the configuration, contact SEW‑EURODRIVE Service. You can obtain information about current security-related issues by e-mail or on the Product Security Management website. There you will find various contact options for reporting security-related problems.
- Page 11 Installation of the MOVISAFE® F-Protocol Editor Installing the configuration tool Installing the configuration tool The installation program modifies entries in the Windows registry. Make sure that the appropriate authorization to modify registry entries is granted. Proceed as follows: 1. Start the installation file MOVI-C.FS.DeviceConfigHelper.Setup with admin- istrator rights.
- Page 12 Operation of the MOVISAFE® F-Protocol Editor IT security Operation of the MOVISAFE® F-Protocol Editor IT security 5.1.1 Hardening measures Perform the following hardening measures: • Regularly check if updates are available for your products. • Report incidents concerning IT security by e-mail to cert@sew‑eurodrive.com. •...
- Page 13 Operation of the MOVISAFE® F-Protocol Editor Requirements for operation Requirements for operation ® Before opening the MOVISAFE F-Protocol Editor for the first time, the PROFINET in- terface and the PROFIsafe parameters of the inverter must already be configured in the TIA Portal. In the Windows prompt, use the "ping IP address of the inverter"...
- Page 14 PROFIsafe configuration Configuring PROFINET parameters PROFIsafe configuration The configuration of PROFIsafe parameters is explained in more detail using an ex- ® ample. In the example, a MOVIMOT flexible decentralized inverter is integrated into a ® PROFINET network. The inverter has an integrated MOVISAFE CSB51A safety op- tion.
- Page 15 PROFIsafe configuration Configuring PROFINET parameters 2. Enter the IP address parameters of the inverter in the [Ethernet addresses] group. 9007232628507531 3. Set the cycle time and, if required, other PROFINET parameters. ® Manual – MOVISAFE F-Protocol Editor...
- Page 16 PROFIsafe configuration Configuring PROFINET parameters 4. Load the project to the PLC via the programming interface used. 5. Assign the specified PROFINET device name to the inverter. To do so, right-click to open the context menu of the inverter and select [Assign device name]. 9007232625175819 ®...
- Page 17 PROFIsafe configuration Configuring PROFIsafe parameters Configuring PROFIsafe parameters Proceed as follows: ü You have assigned the required number of PROFIsafe process data words to the inverter in the TIA Portal project. 1. Enter the following PROFIsafe parameters in the [PROFIsafe] group: Parameter Meaning F_Dest_Add...
- Page 18 PROFIsafe configuration Configuring PROFIsafe parameters 18014431885589003 ® Manual – MOVISAFE F-Protocol Editor...
- Page 19 PROFIsafe configuration Configuring PROFIsafe parameters ® 2. Activate the MOVISAFE F-Protocol Editor configuration tool. To do so, right-click to open the context menu of the inverter and select [Start device tool]. 9007232634556299 3. Select the "Standard" entry and click [Start]. 36028830406160395 4.
- Page 20 PROFIsafe configuration Configuring PROFIsafe parameters ð The device name and IP address of the inverter are displayed in the ® MOVISAFE F-Protocol Editor. The values for the destination and source ad- dresses are adopted automatically from the TIA Portal. 27021631151653515 INFORMATION Note that the safety options from SEW‑EURODRIVE do not have a password when delivered.
- Page 21 PROFIsafe configuration Configuring PROFIsafe parameters 27021631151628299 6. When the LEDs on the correct target device are flashing, click the [Yes, transmit set values] button. ð The configuration is sent to the inverter. After successful transmission, you will receive a message. 27021631269028747 ð...
- Page 22 PROFIsafe configuration Configuring PROFIsafe parameters 9007232642150411 7. Save the TIA Portal project. ® Manual – MOVISAFE F-Protocol Editor...
- Page 23 Index Index Meaning of the hazard symbols...... 5 Assigning a PROFINET device name .... 14 Other applicable documentation ...... 4 Content of this document ........ 9 Copyright notice ............ 6 Product names............ 6 PROFIsafe configuration Configuring the PROFINET connection.. 14 Decimal separator .......... 6 Configuring the PROFIsafe connection .. 17 Documents, applicable ..........
- Page 28 SEW-EURODRIVE—Driving the world SEW-EURODRIVE GmbH & Co KG Ernst-Blickle-Str. 42 76646 BRUCHSAL GERMANY Tel. +49 7251 75-0 Fax +49 7251 75-1970 sew@sew-eurodrive.com www.sew-eurodrive.com...
