Installation Instructions
REV 4 02/15/21
Hardware
M6 Bolt
M8 Bolt
M10 Bolt
M12 Bolt
Torque Specifications
3 ft-lbs.
7 ft-lbs.
16 ft-lbs.
28 ft-lbs.
ATTENTION: Use correct torque settings to avoid
damaging the running boards and or mounting
brackets. Failure to do so will void your warranty.
If you have any questions please contact our technical
team at 1-866-717-6645
Part No.
5416
Product: Running Boards
Application:
Kia Sorento 2016-2020
Level of Difficulty: 1
2
Installation Time: 75 min
3 4 5
Advertisement
Related Manuals for Romik 5416
Summary of Contents for Romik 5416
- Page 1 Part No. 5416 Product: Running Boards Application: Kia Sorento 2016-2020 Installation Instructions Level of Difficulty: 1 3 4 5 Installation Time: 75 min REV 4 02/15/21 Hardware Torque Specifications ATTENTION: Use correct torque settings to avoid M6 Bolt 3 ft-lbs.
- Page 2 Video Installation Installation Instructions 5416 Bracket Kit Instruction: Note: This vehicle requires undercarriage panel trimming. Step 1: Locate front mounting locations and hardware as per 1 page of this installation manual Step 2: Remove front factory rubber plug as shown on Figure 1, Install provided HTC 230 as shown Figure 2 Step 3: Temporarily install front bracket Figure 3 and mark section where base touches panel Figure 4.
- Page 3 Installation Instructions 5416 Bracket Kit Step 5: Remove factory rear plug Remove front factory rubber plug as shown on Figure 7, Install provided HTC 230 as shown Figure 8, Remove factory plug as shown on Figure 9, install provided HTC...
