Installation Instructions
REV 1 04/15/20
Hardware
M6 Bolt
M8 Bolt
M10 Bolt
M12 Bolt
Torque Specifications
3 ft-lbs.
7 ft-lbs.
16 ft-lbs.
28 ft-lbs.
ATTENTION: Use correct torque settings to avoid
damaging the running boards and or mounting
brackets. Failure to do so will void your warranty.
If you have any questions please contact our technical
team at 1-866-717-6645
Part No.
1016
Product: Running Boards
Application:
Audi Q5 2018+
Level of Difficulty: 1 2
Installation Time: 90 min
3
4 5
Advertisement
Related Manuals for Romik REC-P
Summary of Contents for Romik REC-P
- Page 1 Part No. 1016 Product: Running Boards Application: Installation Instructions Audi Q5 2018+ Level of Difficulty: 1 2 Installation Time: 90 min REV 1 04/15/20 Hardware Torque Specifications ATTENTION: Use correct torque settings to avoid M6 Bolt 3 ft-lbs. damaging the running boards and or mounting M8 Bolt 7 ft-lbs.
- Page 2 Video Installation Installation Instructions 1016 Bracket kit Instruction: NOTE: This vehicle requires undercarriage plastic cover trimming. Step 1: After removing plastic panels locate front mounting locations and hardware as per 1 page of this installation manual Step 2: Remove the second rubber plug on the main chassis Figure 1, install provided HTC 230 Step 3: Locate outer mounting point, the rubber plug is directly inline with the inner rubber plug that was just removed.
- Page 3 Step 8: Proceed to last page of this manual for running board install instructions and torque values Step 9: Raise panels onto vehicle and mark locations to cut. For Technical support please call our team at 1-866-717-6645 and one of our experts will assist you with this installation Thank you for choosing Romik.
- Page 4 Running Board Installation Instructions 1) Flip your Romik running boards onto a flat surface, make sure to place the running boards on a towel or cardboard in order to protect the surface Figure 1. 2) Loosen the M8 bolts on back of your running boards Figure 2. Depending on your model there Will be either 6 or 8 bolts installed per side.
