Installation Instructions
REV 1 04/15/20
Hardware
M6 Bolt
M8 Bolt
M10 Bolt
M12 Bolt
Torque Specifications
3 ft-lbs.
7 ft-lbs.
16 ft-lbs.
28 ft-lbs.
ATTENTION: Use correct torque settings to avoid
damaging the running boards and or mounting
brackets. Failure to do so will void your warranty.
If you have any questions please contact our technical
team at 1-866-717-6645
Part No.
1434
Product: Running Boards
Application:
Buick Enclave 2018+
Chev Traverse 2018+
Level of Difficulty:
1
2 3 4 5
Installation Time: 60 min
Advertisement
Table of Contents
Related Manuals for Romik 1434
Summary of Contents for Romik 1434
- Page 1 Part No. 1434 Product: Running Boards Application: Buick Enclave 2018+ Installation Instructions Chev Traverse 2018+ Level of Difficulty: 2 3 4 5 Installation Time: 60 min REV 1 04/15/20 Hardware Torque Specifications ATTENTION: Use correct torque settings to avoid M6 Bolt 3 ft-lbs.
- Page 2 Video Installation Installation Instructions 1434 Bracket Kit Instruction: NOTE: Due to the body design on this vehicle there is a visible gap. Please review images on www.Romik.com before installing. Step 1: Locate front mounting locations and hardware as per 1 page of this installation manual Step 2: Install provided HTC 263 as shown on Figure 1.
- Page 3 Installation Instructions 1434 Bracket Kit Step 6: Locate rear bracket position Figure 8, Install provided HTC 284. Remove factory rubber plug Figure 9 and install proviced HTC 243 Figure 10. Step 7: Install rear bracket as show Figure 11 and 12 Do not tighten...
- Page 4 Running Board Installation Instructions 1) Flip your Romik running boards onto a flat surface, make sure to place the running boards on a towel or cardboard in order to protect the surface Figure 1. 2) Loosen the M8 bolts on back of your running boards Figure 2. Depending on your model there Will be either 6 or 8 bolts installed per side.
