Summary of Contents for Avalue Technology EPM-1605
- Page 1 EPM-1605 USB to mini-PCIe module with USIM interface User’s Manual Ed – 04 September 2024 Part No: E2047UXMP01R...
-
Page 2: Table Of Contents
Hardware Configuration .................... 5 Jumper and Connector List..................6 Setting Jumpers & Connectors ................7 2.2.1 Mini PCI Express connector (MCN1) ............... 7 2.2.2 USB power inverter (MCN2) ................8 2.2.3 SIM CARD slot (MCN3) ................... 8 2 EPM-1605 User’s Manual... -
Page 3: Getting Started
Always note that improper disassembling action could cause damage to the motherboard. We suggest not removing the heatsink without correct instructions in any circumstance. If you really have to do this, please contact us for further support. EPM-1605 User’s Manual 3... -
Page 4: Product Overview
EPM-1605 1.2 Product Overview 4 EPM-1605 User’s Manual... -
Page 5: Hardware Configuration
User’s Manual 2 Hardware Configuration EPM-1605 User’s Manual 5... -
Page 6: Jumper And Connector List
The following tables list the function of each of the board's jumpers and connectors. Connectors Label Function Note MCN1 Mini PCI Express connector 52 header MCN2 USB power inverter 5 x 1 wafer, pitch 1.25mm MCN3 SIM CARD slot 6 header X-SIM 6 EPM-1605 User’s Manual... -
Page 7: Setting Jumpers & Connectors
2.2.1 Mini PCI Express connector (MCN1) Signal PIN PIN Signal M +3.3V M +1.5V MSIM_VCC MSIM_DATA MSIM_CLK MSIM_RESET MSIM_VPP MSIM_SCC8 MSIM_SCC4 M +3.3V M +3.3V M +1.5V MUSBDN MUSBDP M +3.3V M +3.3V M +1.5V M +3.3V EPM-1605 User’s Manual 7... -
Page 8: Usb Power Inverter (Mcn2)
EPM-1605 2.2.2 USB power inverter (MCN2) Signal MUSB5V_IN MUSBDN MUSBDP 2.2.3 SIM CARD slot (MCN3) Signal PIN PIN Signal MSIM_CLK MSIM_DATA MSIM_RESET MSIM_VPP MSIM_VCC 8 EPM-1605 User’s Manual...
