3. Follow the instructions specific to your construction.
Wood Construction
• Drill an appropriate hole where screws are to be located. Screw must
enter wood.
Masonry Construction
• Due to the variety of masonry materials that may be present at
installation site, hardware is not provided for attaching the anti-tip
bracket to masonry. If bracket is to be mounted to masonry or
ceramic floors, attach anti-tip bracket using two 5/16" OD sleeve
anchors (with 1/4" bolt - either hex bolt head or hex nut head) rated
for minimum 300lb tension for the masonry material present at
installation site. Screw must enter masonry.
Rear rubber pad
Rear range foot
Anti-tip bracket
¹³⁄ "
(20.0 mm)
1 ³⁄ "
(43.6 mm)
