Summary of Contents for EAE EE-MS12MF
- Page 1 Model No. EE-MS12MF TRANSLATED VERSION Mobile Lifting Table Installation, Operation Lifting Capacity, 1200KG and Parts Manual Distributed by Please read this entire manual carefully and completely before installation or operation of the lift. 06/11/2024...
-
Page 2: Important Notes
Liability The liability of EAE is limit to the amount that the customer has actually paid for this product. This exclusion of liability does not apply to damages caused through willful misconduct or gross negligence on the part of EAE. -
Page 3: Table Of Contents
Installation, Operation and Parts Manual EE-MS12MF IMPORTANT NOTES .............................. 2 SAFETY NOTES ..............................4 1.1 Operation of the lifting table ..........................4 1.2 Checking of the lifting platforms .......................... 4 1.3 Important safety notices ............................4 1.4 Noise ..................................5 1.5 Warning labels .............................. -
Page 4: Safety Notes
Installation, Operation and Parts Manual EE-MS12MF SAFETY NOTES 1.1 Operation of the lifting table This mobile lifting table is designed for dismantling and fixing batteries of electric vehicles as well as engine, gearbox, drive axle, fuel tank, suspension, bracket and chassis components of traditional vehicles. Users are not allowed to use it for any other purposes. The applicable national regulations, laws and directives must be observed. -
Page 5: Noise
Installation, Operation and Parts Manual EE-MS12MF 1.3.10 Do not modify without manufacturer’s advice. 1.3.11 Wear the appropriate personal protection equipment such as safety helmet, safety shoes, safety gloves, etc. 1.3.12 If the lift is going to be left unused for a long time, users are required to: a. -
Page 6: Packing, Storage And Transportation
Installation, Operation and Parts Manual EE-MS12MF PACKING, STORAGE AND TRANSPORTATION Packing, lifting, handling, transporting operations must be performed only by experienced personnel with appropriate knowledge of the lift and after reading this manual. 2.1 The lift was packed as whole for transportation... -
Page 7: Product Descriptions
Installation, Operation and Parts Manual EE-MS12MF PRODUCT DESCRIPTIONS 3.1 General descriptions This mobile lifting table, which is hydraulic driven with mechanical safety locking protection, is designed for dismantling and fixing batteries of electric vehicles as well as engine, gearbox, drive axle, fuel tank, suspension, bracket and chassis components of traditional vehicles. -
Page 8: Dimensions
Installation, Operation and Parts Manual EE-MS12MF 3.4 Dimensions 3.5 Important information about the battery. Normally it takes 8-10 hours to charge a new battery to 100% of its current capacity depending on the temperature of the environment. The normal voltage of a new battery ranges from 12 to 12.9V after being charged for 8 hours and put aside for another 4 hours. -
Page 9: Installation
Installation, Operation and Parts Manual EE-MS12MF INSTALLATION ONLY TRAINED AND QUALIFIED INSTALLERS CAN PERFORM LIFT INSTALLATION DUTIES. Step 1: Remove the packing frames and take out accessories placed under the platform. Prepare 2 wooden battens with thickness of more than 100mm and length of more than 700mm. (other dependable devices may also applicable). - Page 10 Installation, Operation and Parts Manual EE-MS12MF Step 3: Install the jack. Put the steel ball B into position as indicated in the following FIGURE. Untighten screw A attached with the component 3. Insert ball B into component 3, then tighten screw A.
- Page 11 Installation, Operation and Parts Manual EE-MS12MF Connect the wires of mobile jack to the corresponding terminals in the box. (See the following fig.) Fix the cover back. Step 5: Install the handle. Tighten the handle (Pos.1) with the platform extending section by two hex socket cylinder head screws M5x12.
-
Page 12: Commission
Installation, Operation and Parts Manual EE-MS12MF COMMISSION Only authorized persons are allowed to operate the lifting table. Read and digest the complete operation instructions before operating the lifting table. 4.1 Fill the oil reservoir with hydraulic oil ONLY CLEAN AND FRESH OIL ONLY. DON’T FILL THE TANK COMPLETELY FULL. -
Page 13: Operation Instructions
Installation, Operation and Parts Manual EE-MS12MF - Do not change or modify without permission. Otherwise the lift may not operate properly, or a serious accident may occur. - If you find a problem with the lifting table during use or inspection, stop using it and request maintenance. Do not use until it is repaired. - Page 14 Installation, Operation and Parts Manual EE-MS12MF 4.3.2 Hand-held control Description Functions Push it to deactivate all the control buttons on hand-held control. Stop button Rotate this button and push the main switch (Pos.2) to resume the function of all control buttons.
-
Page 15: Use The Pallet Jack
Installation, Operation and Parts Manual EE-MS12MF 4.4 Use the pallet jack Prior to move the table, the load platform must have been lowered fully. The pallet jack is used to move the lift by lifting its base off the floor. -
Page 16: Use The Lifting Platform
Installation, Operation and Parts Manual EE-MS12MF 4.5 Use the lifting platform Before loading operation, run the lifting table without load for a complete cycle to ensure it is in good condition. Get familiar with lift controls by running the lift without load through a few cycles. - Page 17 Installation, Operation and Parts Manual EE-MS12MF Ascend Ensure the load is centered over the carrying table. 1. Make sure that you have read and understood the operation manual before operation. 2. Push the lifting table under the load to be lifted. Lower the mobile pallet jack.
-
Page 18: Trouble Shooting
Installation, Operation and Parts Manual EE-MS12MF TROUBLE SHOOTING ATTENTION: If the trouble could not be fixed by yourself, please do not hesitate to contact us for help. We will offer our service at the earliest time we can. By the way, your troubles will be judged and solved much faster if you could provide us more details or pictures of the trouble. -
Page 19: Maintenance
Installation, Operation and Parts Manual EE-MS12MF TROUBLES POSSIBLE CAUSES SOLUTIONS Too low oil level. Add oil. The relief valve is not adjusted to the right position. Make adjustment. Change the oil. Too hot hydraulic oil ( above 60°）. Abraded seal of the cylinder Replace the seal. - Page 20 Installation, Operation and Parts Manual EE-MS12MF 2. Routine maintenance ITEM METHODS PERIOD Push and turn around the lifting cable to check the flexibility of the Foot casters Every day casters. Surface of the load-carrying Inspect and wipe off the oil and stains before use.
-
Page 21: Annex 1, Electrical Diagrams And Parts List
Installation, Operation and Parts Manual EE-MS12MF Annex 1, Electrical diagrams and parts list... - Page 22 Installation, Operation and Parts Manual EE-MS12MF...
- Page 23 Installation, Operation and Parts Manual EE-MS12MF...
- Page 24 Installation, Operation and Parts Manual EE-MS12MF Component Code Code Descriptions Specification 321203251 Battery 6-EVF-80 Electro-driven unit 322000004 (exclude battery, charger, HELI-DC24V emergency stop switch) 320301011 Limit switch TZ8108 SQ2-1 320301028 Limit switch TZ-8112 320307036 Power switch LW26-20GS/04-1(48mm*48mm) 320307050 Disconnect power switch...
-
Page 25: Annex 2, Hydraulic Diagrams And Parts List
Installation, Operation and Parts Manual EE-MS12MF Annex 2, Hydraulic diagrams and parts list Plastic oil tank Pressure compensating valve Oil-sucking filter Solenoid valve (2P2W, for normal descent) Motor Oil tank lid Gear pump Solenoid valve (2P2W, shift the hydraulic line) - Page 26 Installation, Operation and Parts Manual EE-MS12MF Pos. Code Descriptions Specification 320204313 Motor DM22-2AWU-3BA2R-O,24VDC,2.0kW 330105078 Hydraulic block LBZ-T547TK-1,6061 330304307 Relief valve YF08-40 330302006 Non-return valve DF08-01-00 210101015 Fitting YBZ1-PG02A,5/16-24UNF,35 330105032 Hydraulic block YBZ5-F1.2A2A547A/WUUIT1-01 330305025 Flow-restrictive valve LF08-01 330503037 Hydraulic lock LDPC-08-0.4...
- Page 27 Installation, Operation and Parts Manual EE-MS12MF Pos. Code Descriptions Specification 202109008 Hex socket cylinder head screw M5*12 207101098 Type O seal ring GB/T3452.1,109*5.3 330402020 Oil-back pipe YBZ-F1.2Z1/1-01,φ9.5*85,Q235 330201918 Gear pump CBKA-F1.2DF2 330301003 Cushion valve assembly HCF-Z1/4 330503030 Stainless steel bind...
- Page 28 Installation, Operation and Parts Manual EE-MS12MF Pos. Code Descriptions Specification 624008179 Oil hose Φ4,L=2800mm 624008177 Oil hose Φ4,L=2700mm 624008180 Oil hose Φ4,L=3200mm 624008178 Oil hose Φ4,L=3100mm 624002021B Oil hose φ6,L=500mm 625000017 Front and back-tilt adjusting cylinder YG32-42-20-70-215 625000016 Left and right-tilt adjusting cylinder...
-
Page 29: Annex 3, Exploded Mechanical Drawings And Parts List
Installation, Operation and Parts Manual EE-MS12MF Annex 3, Exploded mechanical drawings and parts list Pos. Code Descriptions Specification 202111001 Hex socket flat head screw M5X10-GB70_3 615062207 Arm assembly MS12M-A2 615068626 Mobile jack MS12MF-A1 615068628 Platform assembly MS12MF-A3 208108015 Tank chain... - Page 30 Installation, Operation and Parts Manual EE-MS12MF Pos. Code Descriptions Specification 202208008 Hex socket cylinder head screw (with shaft shoulder) 20-M16X35-GB5281 202208009 Hex socket cylinder head screw (with shaft shoulder) 20-M16X40-GB5281 420270280 Rolling ball 6435B-A21 208107015 Levelling bubble scale BFHD-3412 204201005...
- Page 31 Installation, Operation and Parts Manual EE-MS12MF Pos. Code Descriptions Specification 202109020 Hex socket cylinder head screw M6X15-GB70_1 208109020 Rubber pressing head M8X75 410563111 Padding plate MS12AC-A2-B6 614059209 Cardan joint holder MS12AC-A3-B3 614059210 Cardan joint cap MS12AC-A3-B4 410563303B Fixed platform MS12AC-A3-B6...
- Page 32 Installation, Operation and Parts Manual EE-MS12MF Pos. Code Descriptions Specification 205103004 Flange bearing 3026-SF-1F 205101054 Bearing 3030-SF-2X 204101012 Flat washer D24-GB95 204301009 Circlip D25-GB894_2 204301010 Circlip D28-GB894_2 204201003 Spring washer D6-GB93 204101004 Flat washer D6-GB95 330310018 Electromagnet DCT45X20 203103007 Hex locking nut...
- Page 33 Installation, Operation and Parts Manual EE-MS12MF Pos. Code Descriptions Specification 614059203 Outside support arm MS12AC-A2-B2 614059204 Inside support arm MS12AC-A2-B3 420560050 Sliding block MS12AC-A2-B4 410562291 Middle shaft of the support bracket MS12AC-A2-B5 410562301 Downside shaft of the cylinder MS12AC-A2-B7 410562311...
- Page 34 Installation, Operation and Parts Manual EE-MS12MF Pos. Code Descriptions Specification 204101009 Flat washer D16-GB95 204101011 Flat washer D20-GB95 204201003 Spring washer D6-GB93 204101004 Flat washer D6-GB95 204201004 Spring washer D8-GB93 204101005 Flat washer D8-GB95 622034385 Power unit DC24V-2KW-F1_2-DC24 322000004 Electro-driven unit...
- Page 35 Installation, Operation and Parts Manual EE-MS12MF Optional Adapter 1 Pos. Code Descriptions Specification 208109024 Adjustable foot D80-M20x100 202205013 Hex socket tight screw M12x30 410562011 Pad plate MS10-A08-B01 410563381 Support rod MS10-A08-B02 Optional Adapter 2 Pos. Code Descriptions Specification 202205013 Hex socket tight screw...
