- Page 1 Model No. EE-F9M Installation, Operation and Parts Manual Two Post Lift， Manual Release Lifting Capacity 3500kg Distributed by Please read this entire manual carefully and completely before installation or operation of the lift. DATE: 08/09/2023...
-
Page 2: Important Notes
Liability The liability of EAE is limit to the amount that the customer has actually paid for this product. This exclusion of liability does not apply to damages caused through willful misconduct or gross negligence on the part of EAE. -
Page 3: Table Of Contents
Installation, Operation and Parts Manual EE-F9M IMPORTANT NOTES ............................2 SAFETY NOTES..............................4 1.1 Operation of lifting platforms..........................4 1.2 Checking of the lifting platforms ........................... 4 1.3 Important safety notices ............................5 1.4 Warning labels ............................... 6 1.5 Potential safety risks .............................. 7 1.6 Noise level................................ -
Page 4: Safety Notes
Installation, Operation and Parts Manual EE-F9M SAFETY NOTES 1.1 Operation of lifting platforms This lift is specially designed for lifting motor vehicles. Users are not allowed to use it for any other purposes. The applicable national regulations, laws and directives must be observed. -
Page 5: Important Safety Notices
Installation, Operation and Parts Manual EE-F9M 1.3 Important safety notices 1.3.1 Recommend for indoor use only. DO not expose the lift to rain, snow or excessive moisture. 1.3.2 Only use this lift on a surface that is stable and capable of sustaining the load. Do not install the lift on any asphalt surface. -
Page 6: Warning Labels
Installation, Operation and Parts Manual EE-F9M 1.4 Warning labels All safety warning labels are clearly depicted on the lift to ensure that the operator is aware of and avoid the dangers of using the lift in an incorrect manner. The labels must be kept clean and they have to be replaced if detached or damaged. Please read carefully the meaning... -
Page 7: Potential Safety Risks
Installation, Operation and Parts Manual EE-F9M 1.5 Potential safety risks 1.5.1 Mains voltage nsulation damage and other faults may result in accessible components being live Safety measures: Only ever use the power cord provided or a tested power cord. -
Page 8: Packing, Storage And Transportation
Installation, Operation and Parts Manual EE-F9M PACKING, STORAGE AND TRANSPORTATION Packing, lifting, handling, transporting operations must be performed only by experienced personnel with appropriate knowledge of the lift and after reading this manual. 2.1 The lift was dismantled into the following 2 parts for transportation... -
Page 9: Products Descriptions
Installation, Operation and Parts Manual EE-F9M PRODUCTS DESCRIPTIONS 3.1 General descriptions This is chassis supporting vehicle lift for road vehicles. It is mainly composed by two posts, two carriages, four swing arms and a power and control unit. It is driven by an electro-hydraulic system. The gear pump delivers hydraulic oil to oil cylinders and pushes upwards its piston. The cylinder piston drives to raise the carriage and swing arms. -
Page 10: Dimensions
Installation, Operation and Parts Manual EE-F9M 3.4 Dimensions Dimension scheme with four 2-stage arms... - Page 11 Installation, Operation and Parts Manual EE-F9M Dimension scheme with two 3-stage arms and two 2-stage arms...
-
Page 12: Safety Devices Descriptions
Installation, Operation and Parts Manual EE-F9M 3.5 Safety devices descriptions POS. Description Function Arm lock Ensure the supporting arms are locked and avoid swinging during lifting process Steel rope Balance carriages at both sides. Rubber pad Safe contact with the wheelbase... -
Page 13: Installation Attentions
Installation, Operation and Parts Manual EE-F9M 4.1.3 Foundations preparations Refer to Annex 1 for footing. To ensure stability and safety under load, the lift shall be installed with the base frame being in direct and firm contact with the concrete foundation. Don't attempt to fix the base frame directly onto floor with ceramic and other decorated surfaces otherwise you put the lift into a very dangerous situation. -
Page 14: General Installation Steps
Installation, Operation and Parts Manual EE-F9M 4.3 General installation steps ONLY TRAINED AND QUALIFIED INSTALLERS CAN PERFORM LIFT INSTALLATION DUTIES. Step 1: Remove the packaging and take out the accessories attached. ： Attention The packs must be opened adopting all the precautions required to avoid injury to persons (keep at a safe distance when cutting the straps) or damage to parts of the machine (be careful that no parts are dropped while you are opening the packing). - Page 15 Installation, Operation and Parts Manual EE-F9M Anchoring bolt (foundation thickness ) (drilling depth) (anchoring depth) M18x160 ≥200mm 130mm 105mm 240mm ≤55mm Step 4: Fix the slot base plate. Use suitable means to raise the lifting carriage to the first locking position and then place the slot base plate between two base plates of the post.
- Page 16 Installation, Operation and Parts Manual EE-F9M Fix the release rope Release rope fixed at the operative side. The release rope goes through pulleys at the bottom of the column. 1.Release rope Fix the other end of the rope to the locking unit at the other post.
- Page 17 Installation, Operation and Parts Manual EE-F9M c. Fix the protective cover. 1.Hex socket cylinder head screw M6*8 Step 6: Connect the synchronization steel rope. 1. Route and fix according to the following scheme. 2. Before attempting to route the cables, raise the lifting carriage at both sides to the first latching position making sure that the mechanical safety locking units in each post are fully engaged.
- Page 18 Installation, Operation and Parts Manual EE-F9M Step 7: Install the power and control unit. 1. Cross socket cap head screw M5x8 2. Control box 3.Hex head flange screw M8x30 4.Anti-vibration pad 5. Hex flange nut M8 6.Hydraulic power unit Step 8: Connect the hydraulic hoses Connect oil hoses according to the following diagram.
- Page 19 Installation, Operation and Parts Manual EE-F9M Step 9: Make the electrical connection. ONLY qualified electricians are permitted doing the electrical connection. Read the name plate and check that the supply voltage is adapted to the voltage of the lift. Read the electrical scheme in Annex 2 for reference and connect wires to the corresponding terminals in the control box.
- Page 20 Installation, Operation and Parts Manual EE-F9M Step 11: Fill with hydraulic oil. ONLY CLEAN AND FRESH OIL ONLY Lift must be fully lowered before changing or adding hydraulic oil. Prepare 10 liters anti-abrasive hydraulic oil. Fill about 8 liters into the oil tank to run the lift up and down for 2 or 3times after the electrical system is connected.
-
Page 21: Items To Be Checked After Installation
Installation, Operation and Parts Manual EE-F9M 4.4 Items to be checked after installation Check items √ Screw torque of expansion bolts : 80-100Nm; √ Rising speed ≥20mm/s; √ Noise with load ≤75dB(A); √ Grounding resistance: not bigger than 4Ω; √... - Page 22 Installation, Operation and Parts Manual EE-F9M 5.2 Operation instructions POS. Description Function Unlocking handle Release the mechanical locking unit. Control descending movement. Lowering handle Engage the mechanical locking unit. Power switch Turn on or off the power supply Indicating light...
-
Page 23: Trouble Shooting
Installation, Operation and Parts Manual EE-F9M TROUBLE SHOOTING ATTENTION: If the trouble could not be fixed by yourself, please do not hesitate to contact us for help. We will offer our service at the earliest time we can. Troubles could be judged and solved much faster when more details or pictures could be provided. -
Page 24: Inspection And Maintenance
Installation, Operation and Parts Manual EE-F9M INSPECTION AND MAINTENANCE Easy and low cost routine inspection and maintenance can ensure the lift work normally and safely. Follow the below routine inspection and maintenance schedule with reference to the actual working condition and frequency of your lift. - Page 25 Installation, Operation and Parts Manual EE-F9M Components Methods Period Check if mechanical locking hooks can engage or disengage Mechanical safety locking unit Every day simultaneously. Use proper means to activate the switch and push UP button Max lifting height limit switch Every 30 days to check if the carriage stop rising.
-
Page 26: Annex 1, Floor Plan
Installation, Operation and Parts Manual EE-F9M Annex 1, Floor plan General requirements: Indoor installation only. The space requirement specified in the below scheme is for reference only. There must be sufficient space for driving and lifting vehicles and enough safety distance shall be reserved according to the regulations of the local authorities. -
Page 27: Annex 2, Electrical Schemes And Parts List
Installation, Operation and Parts Manual EE-F9M Annex 2, Electrical schemes and parts list... - Page 28 Installation, Operation and Parts Manual EE-F9M POS. Code Descriptions Specification 320104002 Transformer JBK5-40VA 380V400V415V-24V 320104001 Transformer JBK5-40VA 220V230V240V-24V 320301029 Limit switch TZ-8168 320304001 Main switch LW26GS-20/04 320401042 Push button NP2-EA11（LAY5S-EA11） 320505020 Wire terminals TB-1504 320801001 Circuit breaker (3Ph) CDB6iC16/3P（CB-60A C16）...
-
Page 29: Annex 3, Hydraulic Schemes And Parts List
Installation, Operation and Parts Manual EE-F9M Annex 3, Hydraulic schemes and parts list 1.oil tank 2.oil sucking filter 3.motor 4. gear pump 5. relief valve 6.non-return valve 7.manual unloading valve 8.pressure compensating valve 9.oil tank cover 10.cushion valve 11. flow control connector 12 flow control connector 13.master cylinder... - Page 30 Installation, Operation and Parts Manual EE-F9M POS. Code Description Specification Power unit 2.2KW 207103025 Composite washer 13.7*20*1.5 310101008 Connector M14*1.5-G1/4 624008101 Oil hose L=1000 410902269 Long connector F9MV2-A7-B1 615001007 Master cylinder 6254E-A4-B6 615001009 Main connector 6254E-A4-B11 624001025 Oil hose L=2880...
- Page 31 Installation, Operation and Parts Manual EE-F9M POS. Code Description Specification 330405047 Oil tank SLYX-10L-L-BX 330403003 Oil filter YBZ-E2D3I1/1-10 330201025 Gear pump (3Ph) CBKA-F2.5F 330201005 Gear pump (1Ph) CBK-F220/CBK-2.1F 330404015 Coupling YBZ-E0.963Z0/1-02，46mm 320201020 Motor 220V-2.2KW-1PH-50HZ-2P...
- Page 32 Installation, Operation and Parts Manual EE-F9M POS. Code Description Specification 320201023 Motor 380V-2.2KW-3PH-50HZ-2P 320201030 Motor 220V-2.2KW-1PH-60HZ-2P 320201036 Motor 220V-2.2KW -3PH-60HZ-2P 320201021 Motor 230V-2.2KW-1PH-50HZ-2P 320201024 Motor 400V-2.2KW-3PH-50HZ-2P 330105017 Hydraulic block LBZ-T1BK-2 Hydraulic block (replace 330105017 330105027 YLBZ-T1KK-3 since 30 May,2023) 330301003...
-
Page 33: Annex 4, Mechanical Exploded Drawings And Parts List
Installation, Operation and Parts Manual EE-F9M Annex 4, Mechanical exploded drawings and parts list POS. Code Description Specification 615001010B Steel rope 6254E-A6 203101009 Hex nut 204101009 Flat washer φ16 201201007 Expansion bolt M18x160... - Page 34 Installation, Operation and Parts Manual EE-F9M POS. Code Description Specification Power unit 624008101 Oil hose L=1000 410902269 Long connector F9MV2-A7-B1 615001007 Main cylinder 6254E-A4-B6 615001009 Main connector 6254E-A4-B11 624001025 Oil hose L=2880 615001008 Short connector 6254E-A4-B10 206201011 Cotter pin M4*50...
- Page 35 Installation, Operation and Parts Manual EE-F9M POS. Code Description Specification 410010111 Chain wheel 6254E-A4-B4 410010313 Stop plate 6254E-A4-B7 202109017 Hex socket cylinder head screw M6*8 208108001 leaf chain LH1234-127LGB/T6074-1995 206201008 Cotter pin D4X30-GB91 410047350C Chain holder 62B-A3-B3-35T 203101009 Hex nut...
- Page 36 Installation, Operation and Parts Manual EE-F9M POS. Code Description Specification 206201004 Cotter pin M3*45 410010031 Washer 6254E-A1-B3 205101007 Bushing 2512 410044260 Pulley 62B-A1-B2 614901473 Carriage F9MV2-A3-B1 420680083 Sliding block C9Z-A3-B5 420680099B Sliding block F9MV2-A3-B3-1 420680124 Rubber protective pad 62B-A3-B11 202109031...
- Page 37 Installation, Operation and Parts Manual EE-F9M POS. Code Description Specification 410902013 Spring C9Z-A1-B10 410902014 Spring C9Z-A1-B11 410010031 Washer 6254E-A1-B3 204301009 Circlip D25-GB894_2 410902031 Shaft C9Z-A1-B6 202111033 Hex socket flat head screw M8x65-GB70_3 202109152 Hex cylinder head screw M4X5-GB70_1 203101005 Hex nut...
- Page 38 Installation, Operation and Parts Manual EE-F9M POS. Code Description Specification 410902491 Release steel rope L=6955mm 202110004 Hex socket button head screw M8x12 615068210B Support bracket for the upside pulley 6214DS-A10-2...
- Page 39 Installation, Operation and Parts Manual EE-F9M POS. Code Description Specification 614004005B Long support arm 6254E-A7-B1 614901362 Retractable arm 6254E-A7-B3 614901472 The secondary post F9MV2-A2-B1 201102026 Hex head full swivel bolt M12*25 204201006 Spring washer 204101007 Flat washer...
- Page 40 Installation, Operation and Parts Manual EE-F9M POS. Code Description Specification 203101004 Hex nut 204101004 Flat washer 410010051 Hook for the covering cloth 6254E-A1-B5(6254A-A1-B6) 615001002 Curtain 6254E-A1-B4 2700*140 410049031B Pin shaft 6254E-A12 202109085 Hex socket cylinder head screw M12*30 410901074 Teeth block...
- Page 41 Installation, Operation and Parts Manual EE-F9M Optional height-extension adapter and holder POS. CODE Description Specification 612004003B Height-extension adapter 6254E-A11 410901744 Holder 6254E-A1-B1-C6-V0 202110004 Hex socket button head screw M8X12-GB70_2...
