Model No. EE-62CE-42T
Installation, Operation
Two Post Lift
And Parts Manual
Electrical Release
Asymmetrical/symmetrical Installation
Lifting Capacity 4200KG
Distributed by
Please read this entire manual carefully and completely before installation or operation of the lift.
DATE: 16/08/2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EE-62CE-42T and is the answer not in the manual?

Questions and answers

Related Manuals for EAE EE-62CE-42T

Summary of Contents for EAE EE-62CE-42T

  • Page 1 Model No. EE-62CE-42T Installation, Operation Two Post Lift And Parts Manual Electrical Release Asymmetrical/symmetrical Installation Lifting Capacity 4200KG Distributed by Please read this entire manual carefully and completely before installation or operation of the lift. DATE: 16/08/2024...

  • Page 2: Important Notes

    Installation, Operation and Parts Manual EE-62CE-42T IMPORTANT NOTES Before start up, connecting and operating products, it is absolutely essential that the operating instructions/owner’s manual and, in particular the safety instructions are studied carefully. By doing so you can eliminate any uncertainties in handling products and thus associated safety risks up front;...

  • Page 3: Table Of Contents

    Installation, Operation and Parts Manual EE-62CE-42T IMPORTANT NOTES ............................2 SAFETY NOTES ..............................4 1.1 Operation of lifting platforms ..........................4 1.2 Checking of the lifting platforms ......................... 4 1.3 Important safety notices ............................5 1.4 Warning labels ..............................6 1.5 Potential safety risks ............................

  • Page 4: Safety Notes

    Installation, Operation and Parts Manual EE-62CE-42T SAFETY NOTES 1.1 Operation of lifting platforms This lift is designed for lifting normal on-road vehicles, such as passenger cars, buses and light trucks. Users are not allowed to use it for any other purposes. The applicable national regulations, laws and directives must be observed.

  • Page 5: Important Safety Notices

    Installation, Operation and Parts Manual EE-62CE-42T rules of engineering to be able to check and give an expert option on lifting platforms. 1.3 Important safety notices 1.3.1 Recommend for indoor use only. Do not expose the lift to rain, snow or excessive moisture.

  • Page 6: Warning Labels

    Installation, Operation and Parts Manual EE-62CE-42T 1.4 Warning labels All safety warning labels are clearly depicted on the lift to ensure that the operator is aware of and avoid the dangers of using the lift in an incorrect manner. The labels must be kept clean and they have to be replaced if detached or damaged. Please read carefully...

  • Page 7: Potential Safety Risks

    Installation, Operation and Parts Manual EE-62CE-42T 1.5 Potential safety risks 1.5.1 Main voltage nsulation damage and other faults may result in accessible components being live. Safety measures:  Only ever use the power cord provided or a tested power cord.

  • Page 8: Lifting And Handling

    Installation, Operation and Parts Manual EE-62CE-42T -Never stack to more than 2 meters in height. -Never make stacks of single pack. Always stack pairs of packs in a cross pattern so that the base is bigger and the resulting stack is more stable.

  • Page 9: Products Descriptions

    Installation, Operation and Parts Manual EE-62CE-42T PRODUCTS DESCRIPTIONS 3.1 General descriptions This is chassis supporting vehicle lift for road vehicles. It is mainly composed by two posts, two carriages, four swing arms, a power unit and control unit. It is driven by an electro-hydraulic system. The gear pump delivers hydraulic oil to oil cylinders and pushes upwards its piston. The cylinder piston drives to raise the carriage and swing arms.

  • Page 10: Construction Of The Lift

    Installation, Operation and Parts Manual EE-62CE-42T 3.2 Construction of the lift 1. Extending post 2. Hydraulic power unit 3. Control unit 4. Swing arm 5. Crossbeam 6. Pulley assembly 7. Steel rope 8. Hydraulic cylinder 9. Carriage 3.3 Technical data...

  • Page 11: Dimensions

    Installation, Operation and Parts Manual EE-62CE-42T 3.4 Dimensions 3.4.1 Dimensions for asymmetrical column configuration...
  • Page 12 Installation, Operation and Parts Manual EE-62CE-42T 3.4.2 Dimensions for symmetrical column configuration...

  • Page 13: Safety Devices Descriptions

    Installation, Operation and Parts Manual EE-62CE-42T 3.5 Safety devices descriptions Pos. Description Function Steel rope Balance carriages at both sides. Mechanical safety locking unit Catch the carriages in case of hydraulic failure. Max-height limit switch Stop rising at maximum height.

  • Page 14: Installation Instructions

    Installation, Operation and Parts Manual EE-62CE-42T INSTALLATION INSTRUCTIONS 4.1 Preparations before installation 4.1.1 Space requirements. The lift is designed for indoor installation only. Do not expose the lift to rain, snow or excessive moisture. Do not use the lift near explosives or open areas containing inflammable liquids.

  • Page 15: Installation Attentions

    Installation, Operation and Parts Manual EE-62CE-42T 4.2 Installation attentions 4.2.1 Tighten all hydraulic and electrical connections. 4.2.2 Tighten all screws, nuts and bolts. 4.2.3 Do not place any vehicle on the lift in the case of trial running. 4.3 General Installation Steps ONLY TRAINED AND QUALIFIED INSTALLERS CAN PERFORM LIFT INSTALLATION DUTIES.
  • Page 16 Installation, Operation and Parts Manual EE-62CE-42T Step 4: Connect extending piece for posts and assemble the crossbeam. 1. Assembly the extending piece. There are four pairs of holes reserved on extending piece. On condition that the ceiling of your workshop is higher than 4300mm, it is preferred to fix the extending piece with the main column using the pairs of holes P3 and P4.
  • Page 17 Installation, Operation and Parts Manual EE-62CE-42T 2. Assembly the overhead crossbeams and fix the roof protective rod. First, connect beam 1 and beam 2 using hex head full swivel screw M14*30. Then, fix the roof protective rod using hex socket cylinder head screw M6*35.
  • Page 18 Installation, Operation and Parts Manual EE-62CE-42T Step 6: Secure the post with the floor using anchoring bolts. 1. Check and align the position of the two base plates again. Floor plan for asymmetrical column configuration Align the two base plates, making the marking points C1, C2, C3 and C4 are in the same straight line.
  • Page 19 Installation, Operation and Parts Manual EE-62CE-42T 2. Use suitable means to raise the lifting carriage to the first latching position. All the mounting holes in the base plate are then accessible. Make sure the locking pawl is engaged. 3. Drill the mounting holes. Remove the drilling dust from the hole.
  • Page 20 Installation, Operation and Parts Manual EE-62CE-42T Step 7: Install the crossbeam onto the two posts. Refer to the following Fig.1 and Fig.2 for two types of configuration, ascertain and mark the right holes on the connecting part (Pos.5). Tighten the beam with the two connecting parts and connect the beam with the two posts by tightening the two connecting parts with the two posts.
  • Page 21 Installation, Operation and Parts Manual EE-62CE-42T Step 8: Install the mechanical locking unit. Fix four safety locking plates and electromagnets with two of them on each post. Orientation block Safety locking plate Electromagnet Hex socket cylinder head screw M6*8 Hex socket cylinder head screw M6*15...
  • Page 22 Installation, Operation and Parts Manual EE-62CE-42T Step 9: Connect steel ropes. 1. Ascertain the height configuration. 2. Before attempting to route the ropes, raise the lifting carriage at both sides to the first latching position making sure that the mechanical safety locking units in each post are fully engaged.
  • Page 23 Installation, Operation and Parts Manual EE-62CE-42T Step 10: Install the power unit. Mount the power unit onto the power side post. 1.Hex hut M10 2.Spring washer M10 3.Flat washer M10 4.Anti-shock pad 5.Hex head full swivel screw M10x35 Step 11: Connect the hydraulic hoses.
  • Page 24 Installation, Operation and Parts Manual EE-62CE-42T Step 12: Install the control unit. ONLY qualified electricians are permitted to do the electrical connection. Read the name plate and check that the supply voltage is adapted to the voltage of the lift.
  • Page 25 Installation, Operation and Parts Manual EE-62CE-42T 3. Fix roof-protection limit switch onto the overhead crossbeam and connect its wires with the corresponding terminals reserved in the control box. 1.Roof protection limit switch 2.Cross socket flat head screw M4x25 4. Connect quick connectors between electromagnets.
  • Page 26 Installation, Operation and Parts Manual EE-62CE-42T 5. Connect the solenoid valve wire and motor wire. 1.Power unit 2.Motor wire 3.Solenoid valve wire 4.Control box 5.Power supply wire Step 13: Install swing arms. Connect the four swing arms with the carriage using pin shafts. The pin shafts (No. 2) shall be greased at the installation.
  • Page 27 Installation, Operation and Parts Manual EE-62CE-42T Bleeding the hydraulic system. Vent air remained the oil cylinder. Screw loose the nut on top of the oil cylinder and slightly press the UP button until oil gets out. Screw the nut tight thereafter.
  • Page 28 Installation, Operation and Parts Manual EE-62CE-42T Step 17: Fix two protective covers. Fix the covers (Pos.2, Pos.4) onto the posts. 1.Hex socket cylinder head screw M6x12 2.Cover 1 3.Main post 4.Cover 2 5.Secondary post Step 18: Fix door-opening protection pads, feet protection fenders and lifting trays.

  • Page 29: Items To Be Checked After Installation

    Installation, Operation and Parts Manual EE-62CE-42T 4.4 Items to be checked after installation. Check items Screw torque of expansion bolts: 80-100Nm; √ Rising speed ≥20mm/s; √ Noise with rated load ≤75dB(A); √ Grounding resistance: Not bigger than 4Ω; √ Height difference of the two carriages ≤5mm;...

  • Page 30: Operation Instructions

    Installation, Operation and Parts Manual EE-62CE-42T OPERATION INSTRUCTIONS 5.1 Precautions · ONLY authorized persons are permitted in the lift area. · Do not try to raise the vehicle with excessive length or width. Otherwise there is risk of vehicle falling from lift.
  • Page 31 Installation, Operation and Parts Manual EE-62CE-42T Only one operator is allowed to work around the vehicle lift. Always engage the safety locking mechanism before any operation on the lifted vehicle. Do not make any operation on the lifted vehicle at a height under the first latching position (less than 500mm).

  • Page 32: Trouble Shooting

    Installation, Operation and Parts Manual EE-62CE-42T TROUBLE SHOOTING ATTENTION: If the trouble could not be fixed by yourself, please do not hesitate to contact us for help. We will offer our service at the earliest time we can. Troubles could be judged and solved much faster when more details or pictures could be provided.
  • Page 33 Installation, Operation and Parts Manual EE-62CE-42T TROUBLES POSSIBLE CAUSES SOLUTIONS Untightened oil cylinder. Replace the seal. The non-return valve leaks. Clean or replace it. (Pos.5 in the hydraulic exploded scheme) Unloading valve fails to work well. Clean or replace it.

  • Page 34: Inspection And Maintenance

    Installation, Operation and Parts Manual EE-62CE-42T INSPECTION AND MAINTENANCE Following are requirements for routine maintenance. Easy and low cost routine maintenance can ensure the lift work normally and safely. The plan for routine inspection and maintenance shall be worked out by referring to the following list as well as according to the regulations of the local authorities.
  • Page 35 Installation, Operation and Parts Manual EE-62CE-42T Pos. Components Methods Period Check if both mechanical catches can engage and disengage Mechanical safety locking unit Every day effectively by pushing control buttons. Use proper means to activate the switch and push UP button to...

  • Page 36: Annex 1, Floor Plan

    Installation, Operation and Parts Manual EE-62CE-42T Annex 1, Floor plan General requirements: The lift is designed for indoor installation only. Do not expose the lift to rain, snow or excessive moisture. Do not use the lift near explosives or open areas containing inflammable liquids.
  • Page 37 Installation, Operation and Parts Manual EE-62CE-42T Base layout for asymmetrical column configuration Check the angle of the two baseplates using a straight line. The line shall go through both openings reserved on the baseplates. Base layout for symmetrical column configuration...

  • Page 38: Annex 2, Electrical Diagrams And Parts List

    Installation, Operation and Parts Manual EE-62CE-42T Annex 2, Electrical diagrams and parts list (Note: For the specific requirements on voltage, the actual voltage of your lift may differ with the following diagram)
  • Page 39 Installation, Operation and Parts Manual EE-62CE-42T...
  • Page 40 Installation, Operation and Parts Manual EE-62CE-42T SQ1:Limit switch for maximum height SQ2: Limit switch for roof protection YA1-YA4: Electromagnet YV1:Solenoid valve for descending...
  • Page 41 Installation, Operation and Parts Manual EE-62CE-42T Supply cord Yellow-Green Blue Other colors 3 wires Earth wire Neutral wire Phase wire 5 wires Earth wire Neutral wire Phase wire Supply cord Yellow-Green Other colors 4 wires Earth wire Phase wire Pos.

  • Page 42: Annex 3, Hydraulic Diagrams And Parts List

    Installation, Operation and Parts Manual EE-62CE-42T Annex 3, Hydraulic diagrams and parts list 1.oil tank 2.oil sucking filter 3.gear pump 4.coupling 5.motor 6.hydraulic block 7.buffer valve 8.relief valve 9.non-return valve 10.solenoid valve for descending 11.flow-restrictive valve 12.lid of oil tank (breather ) 13.hose leakage protective valve...
  • Page 43 Installation, Operation and Parts Manual EE-62CE-42T Pos. Code Description Specification 622034290 Power unit 400V/230V-3.5kW-3Ph-50Hz-2P 622034341 Power unit 380V/220V-3.5kW -3Ph-50Hz-2P 207103025 Composite washer 13.7*20*1.5 310101008 Shift connector M14*1.5-G1/4 inside cone 624008046 Oil hose Φ8.,L=320mm 615006003 Three way connector 6214E-A4-B4 624002025B Rubber oil hose...
  • Page 44 Installation, Operation and Parts Manual EE-62CE-42T Pos. Code Descriptions Specification Motor 320204304 400V/230V-3.5kW-3Ph-50Hz-2P Motor 320204302 380V/220V-3.5kW -3Ph-50Hz-2P 330404006 Coupling 48mm（YBZ-F2.1D4H1/1-03） 203204102 Locking nut FHLM-1/2-20UNF Solenoid valve assembly (include part 791150005 DC24V No.3, 4-1,4-2 and 4-3) 330311005 Valve spool 24DC(Keta)（LSV-08-2NCP-M-2H） 330308032...
  • Page 45 Installation, Operation and Parts Manual EE-62CE-42T Pos. Code Descriptions Specification 310101008 Transition connector M14*1.5-G1/4 inside cone 210101014 Plug Z3/8 201101100 Bolt M6*50（NLJLD） 207101098 O-ring 109*5.3 330201008 Gear pump(3.5kW) CBK-F242 204101005 Washer 204201013 Spring washer Hex socket cylinder head screw 202109072...

  • Page 46: Annex 4 , Mechanically Exploded Drawings And Parts List

    Installation, Operation and Parts Manual EE-62CE-42T Annex 4 , Mechanically exploded drawings and parts list Pos. Code Description Specification 615068742 Steel rope 62C-A22 L=11260MM Φ9.3 615068742 Steel rope 62C-A22 L=11260MM Φ9.3 203101009 Hex nut 204101009 Flat washer 201201007 Expansion bolt...
  • Page 47 Installation, Operation and Parts Manual EE-62CE-42T Pos. Code Description Specification 625000013 Oil cylinder YG5060-38-1800 624002025B Rubber oil hose L=8625mm 410170101B Ring for cylinder fixation 6264-A24-B1 203103005 Hex locking nut 202109024 Hex head full swivel screw M6*35 615006003 Three way connector...
  • Page 48 Installation, Operation and Parts Manual EE-62CE-42T Pos. Code Description Specification 614901691 62C-A21-B1-42T-EA Crossbeam(out) 614901732 62C-A21-B3-42T-EA Connection plate 202109024 M6X35-GB70_1 Hex head full swivel screw 203103005 M6-GB889 Hex locking nut 201102035 M14X30-GB5783 Hex head full swivel screw 204101008 D14-GB95 Flat washer...
  • Page 49 Installation, Operation and Parts Manual EE-62CE-42T Pos. Code Description Specification 614901692 62C-A21-B2-42T-EA Crossbeam (in) 202111008 M10X16-GB70_3 Hex socket flat head screw 612901718 62C-A21-B3 Upside pulley shaft assembly 410902109 C9Z-A1-B2 Pulley 205101101 3520-SF-1X Bearing 410911631 62C-A21-B4 Space sheath 410274470C 6435B-A4-B30 Spring...
  • Page 50 Installation, Operation and Parts Manual EE-62CE-42T Pos. Code Description Specification 202110004 M8X12-GB70_2 Hex socket button head screw Pos. Code Description Specification 205101101 Bearing 3520-SF-1X 410902109 Pulley C9Z-A1-B2 410540080 Downside pulley shaft C12-A1-B3-C1 420680083 Slider C9Z-A1-B5 410902001B Pulling rod 6254E-A2-B1-C1-1 410150121...
  • Page 51 Installation, Operation and Parts Manual EE-62CE-42T Pos. Code Description Specification 204101006 Flat washer D10-GB95 204201005 Spring washer D10-GB93 202109042 Hex socket cylinder head screw M10X20-GB70_1 210101018 Plastic protective cover 80X80MM Pos. Code Description Specification 410040071 Orientation block 6254E-A17 410040061 Safety locking plate...
