- Page 1 Model No. EE-62CE-50T Installation, Operation Two Post Lift and Parts Manual Electrical Release Lifting Capacity 5000KG Distributed by Please read this entire manual carefully and completely before installation or operation of the lift. DATE: 16/05/2023...
- Page 2 Liability The liability of EAE is limit to the amount that the customer has actually paid for this product. This exclusion of liability does not apply to damages caused through willful misconduct or gross negligence on the part of EAE.
- Page 3 Installation, Operation and Parts Manual EE-62CE-50T IMPORTANT NOTES ............................2 SAFETY NOTES ..............................4 1.1 Operation of lifting platforms ..........................4 1.2 Checking of the lifting platforms ..........................4 1.3 Important safety notices ............................5 1.4 Warning labels ............................... 6 1.5 Potential safety risks ..............................
- Page 4 Installation, Operation and Parts Manual EE-62CE-50T SAFETY NOTES 1.1 Operation of lifting platforms This lift is specially designed for lifting motor vehicles. Users are not allowed to use it for any other purposes. The applicable national regulations, laws and directives must be observed.
- Page 5 Installation, Operation and Parts Manual EE-62CE-50T rules of engineering to be able to check and give an expert option on lifting platforms. 1.3 Important safety notices 1.3.1 Recommend for indoor use only. DO not expose the lift to rain, snow or excessive moisture.
- Page 6 Installation, Operation and Parts Manual EE-62CE-50T 1.4 Warning labels All safety warning labels are clearly depicted on the lift to ensure that the operator is aware of and avoid the dangers of using the lift in an incorrect manner. The labels must be kept clean and they have to be replaced if detached or damaged. Please read carefully...
- Page 7 Installation, Operation and Parts Manual EE-62CE-50T 1.5 Potential safety risks 1.5.1 Main voltage nsulation damage and other faults may result in accessible components being live. Safety measures: Only ever use the power cord provided or a tested power cord.
- Page 8 Installation, Operation and Parts Manual EE-62CE-50T PACKING, STORAGE AND TRANSPORTATION Packing, lifting, handling, transporting operations must be performed only by experienced personnel with appropriate knowledge of the lift and after reading this manual. 2.1 The lift was dismantled into the following 3 parts for transportation...
- Page 9 Installation, Operation and Parts Manual EE-62CE-50T PRODUCTS DESCRIPTIONS 3.1 General descriptions This is chassis supporting vehicle lift for road vehicles. It is mainly composed by two posts, two carriages, four swing arms and a power and control unit. It is driven by an electro-hydraulic system. The gear pump delivers hydraulic oil to oil cylinders and pushes upwards its piston. The cylinder piston drives to raise the carriage and swing arms.
- Page 10 Installation, Operation and Parts Manual EE-62CE-50T 3.4 Dimensions...
- Page 11 Installation, Operation and Parts Manual EE-62CE-50T 3.5 Safety devices descriptions POS. Description Function Steel cable Ensure sure the synchronization for both carriages Mechanical safety locking unit Catch the carriages in case of hydraulic failure Limit switch Stop rising movement at maximum safety height...
- Page 12 Installation, Operation and Parts Manual EE-62CE-50T INSTALLATION INSTRUCTIONS 4.1 Preparations before installation 4.1.1 Space requirements. Indoor installation only. Refer to 3.4 for the dimensions of the lift. There must also be a clearance of at least 1 meter between the lifting platform and fixed elements (e.g.
- Page 13 Installation, Operation and Parts Manual EE-62CE-50T 4.2.3 Do not place any vehicle on the lift in the case of trial running. 4.3 General Installation Steps ONLY TRAINED AND QUALIFIED INSTALLERS CAN PERFORM LIFT INSTALLATION DUTIES. Step 1: Remove the packaging, take out the carton for accessories.
- Page 14 Installation, Operation and Parts Manual EE-62CE-50T 2. Connect the beams and fix the roof protection bumper 1.Self-locking nut M6 2.Hex socket cylinder screw M6*35 3.Hex head screw M14*35 4.Flat washer M14 5.Spring washer M14 6.Hex nut M14 7.Car roof protective rod Step 5: Fix the standing position for the two posts.
- Page 15 Installation, Operation and Parts Manual EE-62CE-50T Anchoring bolt (foundation thickness ) (drilling depth) (anchoring depth) M18x200 ≥200mm 160mm 145mm 200mm 320mm ≤55mm Step 8: Install the mechanical locking unit. Fix four safety locking plates and electromagnets with two of them on each post.
- Page 16 Installation, Operation and Parts Manual EE-62CE-50T Step 9: Connect steel cables. 1. Route and fix according to the following diagram of steel cable connection. 2. Use suitable means to raise carriages at both sides to the first latching point. Ensure the both carriages are locked.
- Page 17 Installation, Operation and Parts Manual EE-62CE-50T 2. Connect oil hoses according to the following diagram. Don’t let any solid substance go into the hydraulic line. Ensure the connectors are screwed tight against leakage. 1.Oil hose 1 2.Hydraulic power unit 3.Oil hose 2 4.Oil hose 3...
- Page 18 Installation, Operation and Parts Manual EE-62CE-50T 3.Connect the limit switch fixed at the cross beam. 1.Cross socket flat head screw M4*25 2.Limit switch D4MC1000 4. Connect quick connectors between electromagnets. Adjustable bolt Quick connector 5. Connect the solenoid valve wire and motor wire.
- Page 19 Installation, Operation and Parts Manual EE-62CE-50T Step 11: Install lifting arms. Connect the lifting arm and the carriage. The arm pin shafts must be greased at the installation. Ensure the arm lock can engage and release effectively. . Attention: Install Lifting arms and fix feet protection bars ONLY after the complete assembly has been erected and anchored.
- Page 20 Installation, Operation and Parts Manual EE-62CE-50T Check the synchronization of lifting carriages. Ensure the synchronization by adjusting the steel cables at both sides. Make both cables be of the same tension. This could be judged by the sound emitted by the safety locking unit during lifting process.
- Page 21 Installation, Operation and Parts Manual EE-62CE-50T 4.4 Items to be checked after installation. Check items Screw torque of expansion bolts : 80-100Nm; √ Rising speed ≥20mm/s; √ Noise with rated load ≤75dB(A); √ Grounding resistance: not bigger than 4Ω; √...
- Page 22 Installation, Operation and Parts Manual EE-62CE-50T Pos. Descriptions Function Power switch Control main power Power indicator Show if electricity is connected UP button Control the rising movement Safety lock button Engage the mechanical safety lock DOWN button Control the lowering movement...
- Page 23 Installation, Operation and Parts Manual EE-62CE-50T TROUBLE SHOOTING ATTENTION: If the trouble could not be fixed by yourself, please do not hesitate to contact us for help. We will offer our service at the earliest time we can. Troubles could be judged and solved much faster when more details or pictures could be provided.
- Page 24 Installation, Operation and Parts Manual EE-62CE-50T MAINTENANCE Following are requirements for routine maintenance. Easy and low cost routine maintenance can ensure the lift work normally and safely. Frequency of routine maintenance is determined by working condition and frequency. Components Methods...
- Page 25 Installation, Operation and Parts Manual EE-62CE-50T Components Methods Period Push the UP button and inspect and to ensure the lifting platform Limit switch Every day stops rising when the switch is activated. Unloading valve Inspect if the valve leaks or not. Clean or change the valve if it leaks.
- Page 26 Installation, Operation and Parts Manual EE-62CE-50T Annex 1, Floor plan Indoor installation only. The space requirement specified in the below scheme is for reference only. There must be sufficient space for driving and lifting vehicles and enough safety distance shall be reserved according to the regulations of the local authorities.
- Page 27 Installation, Operation and Parts Manual EE-62CE-50T Annex 2, Electrical diagrams and parts list (Note: For the specific requirements on voltage, the actual voltage of your lift may differ with the following diagram)
- Page 28 Installation, Operation and Parts Manual EE-62CE-50T...
- Page 29 Installation, Operation and Parts Manual EE-62CE-50T ： Limit switch for maximum height SQ2: Limit switch for roof protection YA1-YA4: Electromagnet YV: Solenoid valve for descending...
- Page 30 Installation, Operation and Parts Manual EE-62CE-50T Supply cable Yellow-Green Blue Other colors 3 wires Earth wire Neutral wire Phase wire 5 wires Earth wire Neutral wire Phase wire Supply cable Yellow-Green Other colors 4 wires Earth wire Phase wire Pos.
- Page 31 Installation, Operation and Parts Manual EE-62CE-50T Annex 3, Hydraulic diagrams and parts list 1.oil tank 2.oil sucking filter 3.gear pump 4.coupling 5.motor 6.hydraulic block 7.cushion valve 8.overflow valve 9.single way valve 10.solenoid valve for descending 11.flow control valve 12.tank cover 13.composite connector...
- Page 32 Installation, Operation and Parts Manual EE-62CE-50T Pos. CODE Description Specification Power unit 207103019 Composite washer 310101008 Shift connector M14*1.5-G1/4 inside cone 624008046 Rubber oil hose L=320 615006003 Three way connector 6214E-A4-B4 624002005B Rubber oil hose L=10100 624002004B Rubber oil hose...
- Page 33 Installation, Operation and Parts Manual EE-62CE-50T Pos. Code Descriptions Specification 320201001 AC motor 220V-2.2KW -1PH-50HZ-2P AC motor 320201002 230V-2.2KW -1PH-50HZ-2P AC motor 320201003 240V-2.2KW -1PH-50HZ-2P AC motor 320201004 380V-2.2KW -3PH-50HZ-2P AC motor 320201005 400V-2.2KW -3PH-50HZ-2P...
- Page 34 Installation, Operation and Parts Manual EE-62CE-50T Pos. Code Descriptions Specification AC motor 320201006 415V-2.2KW -3PH-50HZ-2P AC motor 320204016 380V-3.0KW -3PH-50HZ-2P AC motor 320204017 400V-3.0KW -3PH-50HZ-2P AC motor 320204018 415V-3.0KW -3PH-50HZ-2P AC motor 320203001 380V-3.5KW -3PH-50HZ-2P AC motor 320203005 400V-3.5KW -3PH-50HZ-2P...
- Page 35 Installation, Operation and Parts Manual EE-62CE-50T Annex 4 , Mechanically exploded drawings and parts list Pos. Code Description Specification 615016001C Steel cable L=12530 203101012 Hex nut 204101011 Flat washer φ20 201201008 Expansion bolt M18*200...
- Page 36 Installation, Operation and Parts Manual EE-62CE-50T Pos. Code Description Specification 615017013 Oil cylinder 6264-A24 624002005B Oil hose L=10100mm 410170101B Ring for cylinder fixation 6264-A24-B1 203103005 Hex locking nut 202109096 Hex socket cylinder head screw M6*40 615006003 Three way connector 6214E-A4-B4(6214A-A5-B2)
- Page 37 Installation, Operation and Parts Manual EE-62CE-50T...
- Page 38 Installation, Operation and Parts Manual EE-62CE-50T Pos. Code Description Specification 614016006 Inside beam 6215E-A10-B2 410160023 6215E-A10-B3 203103005 Hex locking nut 202109024 Hex head full swivel screw M6*35 201102035 Hex head full swivel screw M14*30 204101008 Flat washer 204201007 Spring washer...
- Page 39 Installation, Operation and Parts Manual EE-62CE-50T Pos. Code Description Specification 202111007 Hex socket flat head screw M8*20 420130010 Rund rubber pad 6214EKZ-A4-B4-C4 615035037 Lifting tray 6214EKZ-A4-B4 202109040 Hex socket cylinder head screw M10*15 614013213B Retractable arm 6255E-A4-B3 614013212 Middle arm...
- Page 40 Installation, Operation and Parts Manual EE-62CE-50T Pos. Code Description Specification 206201004 Cotter pin M3*45 410010031 Washer 6254E-A1-B3 205101008 Bushing 2518 410130051 Pulley 6255E-A1-B2 206102013 Elastic cylindrical pin D6X40-GB879 410901966 Teeth block 6255E-A3-B6 410150121 Pressed spring 6254E-A2-B4 410902399 Pull rod assembly (Old version)
