- Page 1 UPort 200/400 Series Quick Installation Guide Version 5.3, April 2025 Technical Support Contact Information www.moxa.com/support 2025 Moxa Inc. All rights reserved. P/N: 1802002001017 *1802002001017*...
- Page 2 Overview The UPort™ 200/400 Series industrial-grade USB 2.0 hubs expand one USB port to four or seven ports. The hubs provide true USB 2.0 Hi- Speed 480 Mbps data transmission through each port, even for heavy- load applications. As USB-IF certified products, the UPort™ 200/400 Series have passed high speed compliance testing and are eligible to bear the USB logo.
-
Page 3: Ordering Information
Ordering Information Package Checklist The UPort™ 200/400 Series package should contain the following items. If any of these items are missing or damaged, contact Moxa for replacement. • 1 UPort 200 or 400 USB hub • USB cable: CBL-USBA/B-100 • 100 to 240 VAC power adapter suitable for your region (excluding T models) •... - Page 4 Front View Back View LED Indicators The LED indicators on the panel are used to display status as follows: Type Color Meaning Ready Green Steady on: Power is on and UPort™ is functioning normally 1. No device connected 2. Device cannot be detected Fault Steady on: Device over current is detected Power...
- Page 5 - 5 -...
- Page 6 Wall Mounting The UPort™ 400 Series comes with two metal attachment plates to allow installation on a wall. First, attach the brackets to the back of the UPort™ 400 with screws. Next, mount the unit to a wall with screws. Screws should be less than 5.0 mm in head diameter, and less than 3.0 mm in shaft diameter.
- Page 7 Dimensions UPort UPort - 7 -...
- Page 8 UPort UPort - 8 -...
-
Page 9: Specifications
Specifications USB Interface Compliance: USB 1.1/2.0 compliant Upstream: 1 USB port, Type B connector Downstream: UPort™ 204/404: 4 USB ports, Type A connectors UPort™ 207/407: 7 USB ports, Type A connectors Speed: 480 Mbps (Hi-Speed USB) and 12 Mbps (Full-Speed USB) Physical Characteristics Housing: UPort™... -
Page 10: Compliance Notice
Compliance Notice CE Warning This is a Class A product. In a domestic environment, this product may cause radio interference in which case the user may be required to take appropriate measures. Federal Communications Commission Statement FCC - This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 11 BSMI (UPort 407 only) BSMI Warning 警告：為避免電磁干擾，本產品不應安裝或使用於住宅環境。 限用物質含有情況標示聲明書 Declaration of the Presence Condition of the Restricted Substances Marking 設備名稱：工業級 USB 集線器 型號（型式）：UPort 407, UPort 407-T Equipment name Type designation (Type) 限用物質及其化學符號 Restricted substances and its chemical symbols 單元 Unit 六價鉻 多溴聯苯...
- Page 12 — Note 3: The “ ” indicates that the restricted substance corresponds to the exemption. 產品名稱： Industrial USB Hub 工業級 USB 集線器 型號：UPort 407, UPort 407-T 製造商資訊： Moxa 四零四科技股份有限公司 +886-3-273-7575 桃園市八德區和平路 1111 號 - 12 -...
- Page 13 KC (UPort 407 only) 사용자안내문 (User Guide) 이 기기는 업무용 환경에서 사용할 목적으로 적합성평가를 받은 기기로서가정용 환경에서 사용하는 경우 전파간섭의 우려가 있습니다. (This equipment has KC approval for use in industrial environments and could possibly interfere with household equipment.) 기 종별 사용자안내문...
