Data Harvest EASYSENSE VISION User Manual page 19

EASYSENSE VISION User guide
3. On an iPad tap on the 'Not Connected' text bottom right of the screen. On the Android select
the connect icon
4. Select the VISION's name from the list.
5. Select the VISION logger from the list. The status button will change to show that it is
'Controlling Vision xx or Viewing Vision xx'.
When you've finished select the connection status icon in the EasySense software to disconnect, then
Exit on the VISIONs screen and the logger will restart.
To connect back to an Access Point network

Select WiFi, then Settings.

Select the Access Point tab.

To connect the Access Point network
without making any changes simply select
Create.
Open the EasySense App. Tap on the connection
status and select the V-Log's name from the list.
To change the Name, Channel or Encrypt the Access Point network
 Select WiFi then Settings.
 Select the Access Point tab.
 To change the Name tap in the box under Access Point
Name and use the keyboard that opens to enter a new
name. Select Create.
 To change the WiFi Channel to one that is less congested
select the number from the supported channels 1 to 11. Select
Create.
 To Encrypt an Access Point network Tap in the box under
Access Point Password and using the keyboard enter a a
suitable password (minimum of 8 characters). Select Create.
 This password will be displayed on the initial WiFi screen.
To make VISION forget known WiFi networks or reset to default
 Select WiFi then Settings.
 Select the Saved Networks tab.
To make VISION forget an individual network:
 Select the network from the list.
 Select Forget. Enter
password, OK.
To make VISION erase all rembered
networks and reset to its default AP setting:
 Select Forget. Enter
 Select Yes to confirm the reset. A message will confirm that all networks are erased.
To change VISION's name
 Select WiFi then Settings.
 Select the About tab. Tap in the box under
Logger Name and using the keyboard enter a
new name.
 Data Harvest Group Ltd.
, top right of the screen.
DHG2020
as the
DHG2020
as the password, OK.
19
D0233 (7)
