EASYSENSE VISION User guide
The text at the top right of the EasySense window will indicate that
a Local Interface connection has been established.
Transferring files between VISION and a PC computer
Saved data files can either be transferred from VISION to your PC by using VISION in 'disc drive'
mode or can be opened direct into the EasySense software by using the Retrieve Remote function
while VISION is connected as an interface.
Saved setup and bitmap files can be transferred from VISION to your PC by using VISION in 'disc
drive' mode.

Save any data you have on screen.

Connect VISION to the PC using the USB cable supplied (connect the 'square' type B plug of the
USB cable to the USB client port
on your computer).
Using VISION in Disc Drive mode

From the Home screen select Disk
Drive from the PC Connection menu.
VISION's screen
will alter to show its
USB connected.

The first time VISION is connected allow the USB device drivers to
install. VISION will appear as a removable storage device on the PC
(no special drivers are required).
Windows Explorer can be used to drag and drop files between
VISION and your PC (maximum file size for VISION is 5 MB).
Note: If no connection is made to the PC within 8 seconds then VISION's
EasySense software will restart.

When you've finished safely remove VISION from the PC e.g. by
using the Safely Remove Hardware icon from the computer's taskbar
and once safe to do so disconnect VISION from the USB port.
VISIONs EasySense software will restart.
With VISION connected as an Interface

Select Interface either from VISION's Home screen or the PC
Connection menu.
VISION's screen will alter to show its USB connected.

Open the EasySense software on your PC computer e.g. Start ► Programs ► Data
Harvest ► and double click on EasySense Software.

Select Remote -> Retrieve Remote from the PC's Home screen.

Select the data file from the list then Retrieve.
When you've finished using VISION as an interface, disconnect VISION from the USB port and
Visions EasySense software will restart.
 Data Harvest Group Ltd.
on VISION and connect the 'flat' type A plug to a USB port
10
