EASYSENSE VISION User guide
Connecting VISION WiFi to a network
VISION WiFi can operate in two different modes:

Connected to its own local network (Access Point)
VISION WiFi is set to Access point by default. In this mode the iPad connects to a network created
by VISION. This connection is typically used when not in range or able to access the school's
network (perhaps on a field trip). While connected to VISION in Access mode, the iPad will NOT
be connected to any other networks, and therefore unable to access other items such as web
pages, email, cloud storage, etc.

Connecting to an existing school's network (Infrastructure)
In this mode VISION WiFi and the iPad connect to the same existing network. It has the
advantage of allowing the iPad to remain connected to other resources delivered by the school
network, such as web access, email, printing and cloud storage facilities, etc.
Note:

VISION WiFi loggers produced prior to April 2016 use 802.11b, ensure the WiFi
network is b mode compatible.
If a b mode module is fitted the logger's WiFi label will just show WiFi and
when you reset the logger it will flash 'with WiFi'

VISION WiFi loggers produced after April 2016 use 802.11n, ensure the WiFi
network is n mode compatible.
If an n mode module is fitted the logger's WiFi label will show WiFin and when
you reset the logger it will flash up 'with WiFi-n'
WiFi
VISION Access Point connection using the default settings
1. From the home screen tap on the Apps button, then double tap on the WiFi icon.
2. After a few seconds the VISION WiFi screen (with green tick) will reappear. VISION has now
created its own network.
It is possible to have multiple VISION WiFi loggers each creating their own separate networks.
The name of the VISION logger
The name of the access
point (AP) network

Connect the iPad or Android to the VISION's Access Point network:
 Select Settings.
 Select the Wi-Fi link. Ensure Wi-Fi is ON.
 Choose the VISION AP network from the list of available networks. Wait for confirmation
that the network has been joined e.g. a tick or it shows as Connected.

Start the EasySense App.

On an iPad tap on the 'Not Connected' text bottom right of the screen.
 Data Harvest Group Ltd.
▼
Start WiFi
►
Setup WiFi
Select Start WiFi to connect to the
network last accessed
Select Setup WiFi to make changes
e.g. access a different network
