Data Harvest EASYSENSE VISION User Manual page 16

EASYSENSE VISION User guide

From File, Interface select Bluetooth and Network. OK.
Note: When first selected you may need to change Windows firewall
settings to allow network access for this app.

Select the connection status text top
right of the EasySense window.

Select the VISION's name (as
displayed on its screen) from
the list.

The connection status will change
to show that it is 'Controlling xx or
Viewing xx the logger.
A link symbol on VISION's
screen will indicate when a
connection has been made to
a computer.
When you've finished select the connection status icon in the EasySense software to disconnect, then
Exit on the VISIONs screen and the logger will restart.
* If auto install fails, download and unzip the drivers for the Bluetooth USB adaptor (Product 2070 or 2071) from
the Data Harvest website. Open Device Manager, right click on the entry for the dongle (typically listed under
Other devices) and select Update drivers. Select to 'Browse my computer' (install manually), locate and select the
BLED112 directory. When installed the adaptor will be listed under the Ports (COM & LPT) section.
When connecting to a iPad or Android device
An iPad will need to support Bluetooth Low Energy (BLE) also known as Smart or 4 (iPad 3 or later or
any iPad Mini). V1.10 or later of the EasySense iPad software must be installed.
An Android will need to support Bluetooth Low Energy (BLE) / Smart – OS 4.4 or later. V1.05 or later
of the EasySense Android software must be installed.
Note: No pairing is required.

Check in Settings that Bluetooth is On.

Start the Bluetooth app on VISION.

Start the EasySense software.

On an iPad tap on the 'Not Connected' text bottom right of the screen.
On the Android select the connect icon

Select the VISION's name from the list.

The status will change to show that it is 'Controlling VISION xx or Viewing VISION xx'.
When you've finished select the connection status icon in the EasySense software to disconnect, then
Exit on the VISIONs screen and the logger will restart.
VISION as an interface in WiFi mode
It is recommended that VISION is connected to its mains power supply when used in WiFi mode as
the power requirements are high, and will drain the battery quickly.
The EasySense App
EasySense iPad is a free app. Search for 'EasySense' in the App Store on your iPad and install.
