EASYSENSE VISION User guide
If the interval between samples is 10 seconds or more VISION will automatically use sleep mode and
will wake each time it needs to take a reading.
The EasySense software overview
Detailed information is available in the EASYSENSE VISION software guide (DO234) available on
from the Resources tab at
Select a User level
The first time VISION is started a 'Select Program Level window may automatically open. Select a
suitable user level - Level 1 is aimed at 'start' level (e.g. up to 9 years old), Level 2 is aimed at 'mid' level
(e.g. 9 – 15 years old), Level 3 is aimed at 'exam' level (e.g.15 years plus).
Note: The program level can be altered once a logging option has been opened.
The Home screen
Home is the main navigation window, which contains the icons for all the logging
options.The options available and the complexity of the toolbars and functions are altered
by the user level selected.
Meters
The Meters window gives an introduction to sensors and how they respond to change. Up
to four section displays can be open at any one time and they can be any combination of
sensors and displays.
The program will open with live data from one sensor in a Numeric window. Click on the appropriate
picture icon on the Menu bar to open other section displays i.e. Numeric, Gauge, Colour Change or
Bar. To alter the sensor displayed in a section, tap & hold (or right click with a mouse) in the individual
section window and select the sensor from the list.
Click on the Stop icon to stop logging.
EasyLog
EasyLog will open pre-set to record sensor values continuously as a line graph until
stopped.
Click on the Start icon
when this has elapsed the time will double automatically. This will continue until the recording is
stopped by clicking on the Stop icon.
Snapshot
Snapshot will open pre-set to record sensor values on demand (manual sampling) with a
bar graph display.
Click on the Start icon
active sensor. Click on the Stop
Graph
Graph is pre-set to record sensor values against a chosen time span as a line graph
display. The window opens with the logging wizard from which the time span, interval
between samples, start condition and triggers for the recording can be chosen. (The
options available will depend on the level you have selected to work at). When the
selection has been made, click on Finish.
Click on the Start icon
met e.g. if None was the selected trigger then the recording will start as soon as the Start icon is
clicked. The recording will stop when the selected time span has passed.
 Data Harvest Group Ltd.
www.data-harvest.co.uk.
to start recording. Logging will start with a time span of 30 seconds and
to start recording. Click in the graph area to record the current value for each
icon to stop data being recorded.
and the recording will start when the start condition you have selected is
