Quick Start Guide
SenseFace 4 Series
Version: 1.1
Due to regular upgrades of systems and products, ZKTeco could not guarantee exact consistency between
the actual product and the written information in this manual.

Advertisement

loading
Need help?

Need help?

Do you have a question about the SenseFace 4 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ZKTeco SenseFace 4 Series

Summary of Contents for ZKTeco SenseFace 4 Series

  • Page 1 Quick Start Guide SenseFace 4 Series Version: 1.1 Due to regular upgrades of systems and products, ZKTeco could not guarantee exact consistency between the actual product and the written information in this manual.
  • Page 2 1 Overview 84.5mm 21.65mm Near-infrared Flash Camera Microphone 4.3-inch Touchscreen Card Reading Area Fingerprint Sensor* USB (Type A ; Drive Only) Magnetic Tamper Speaker Switch Reset Auxiliary Input Exit Button Lock Sensor 485B RS485 485A 12V-OUT Power Wiegand Output/Inuput Note: Ÿ...

  • Page 3: Installation Environment

    2 Installation Environment Please refer to the following recommendations for installation: INSTALL INDOORS AVOID INSTALLATION AVOID DIRECT AVOID USE OF ANY ONLY NEAR SUNLIGHT HEAT SOURCE NEAR THE DEVICE GLASS WINDOWS AND EXPOSURE Ÿ Avoid direct contact to sunlight for a long time. Ÿ...
  • Page 4 4 Exit Button and Door Sensor Connection Door Sensor 485B 485A 12V-OUT ExitButton 5 Smoke Detection Connection Smoke Detector 485B 485A 12V-OUT...

  • Page 5: Power Connection

    6 Power Connection 12V DC Recommended Power Supply: Ÿ 12V ± 10%, at least 3000mA. Ÿ To share power with other devices, use a power supply with higher current ratings. 7 RS485 and Wiegand Connection 485- 485B 485+ 485A +12V 12V-OUT RS485 Reader Wiegand Device...

  • Page 6: Ethernet Connection

    8 Ethernet Connection Router ZKBio CVAccess RJ 45 Click COMM. > Ethernet > IP Address to set the relevant parameters of network. Note: In LAN, the IP address of the server (PC) and the device must be in the same network segment when connecting to the software. 9 Lock Relay Connection The system supports Normally Opened Lock and Normally Closed Lock.

  • Page 7: User Registration

    10 User Registration When there is no super administrator set in the device, click icon to enter the menu. Add a new user, set their User Role to Super Admin, and the system will request administrator verification before granting access to the menu. It is strongly recommended to register a super administrator initially for security purposes.
  • Page 8 Method 2: Register on ZKBio CVAccess Software Register on the PC Please set the IP address and cloud service server address in the Comm. Menu option on the device. Click [Access] > [Device] > [Search] > [Search] to search the device on the software.
  • Page 9 Register on the Phone Once the ZKBio CVAccess software is installed, the users could enroll their face tem- plate via a browser application on their own mobile phone. Click [Personnel] > [Parameters], enter ‘’http://Server address: Port’’ in the QR Code URL bar. The software will automatically generate a QR code. Scan the QR code or login onto ‘’http://Server address: Port/tokenAdreg’’...
  • Page 10 11 Ethernet and Cloud Server Settings Click on    > COMM. > Ethernet to set the network parameters. If the TCP/IP communication of the device is successful, the icon will be displayed in the upper right corner of the standby interface. Click on    >...

  • Page 11: Sip Settings

    12 SIP Settings The device achieves video intercom there are two modes, respectively, the LAN and SIP server. Local Area Network Use In this mode, please make sure that the SIP Server of the device is disabled. This function needs to be used with the indoor monitor VT07-B01. Set the indoor monitor to the same network segment as the device.
  • Page 12 Call Contact List On the SIP Settings interface, click Local Settings to enable the call contact list. Click icon on the device to enter the call page, then you can click the icon to open the contact list, select the number of the indoor monitor you want to call.
  • Page 13 Calling Shortcut Keys On the SIP Settings interface, click Calling Shortcut Settings to enable and define the shortcut keys. Name: Customize the name of the shortcut keys. Number: Select the room number that set in the Contact List Menu. Click the icon on the device and click the calling shortcut keys to call the indoor monitor.
  • Page 14 Direct Calling On the SIP Settings interface, click Calling Shortcut Settings > Call Mode > Direct Calling Mode > Add. Select the indoor monitors that you want to call, then the indoor monitors will be displayed in the list. Click the icon on the device to call the indoor monitors directly.
  • Page 15 SIP Server In this mode, please make sure that the SIP Server of the device is enabled. This function needs to be used with the ZKBio CVAccess server, ZKBio Zexus Mobile App, indoor monitor VT07-B26L-W / VT07-B22L and PC Client BioTalk Pro. There are 2 kinds of SIP server: Cloud SIP and PBX server.
  • Page 16 Click Video Intercom > Extension Management > Extension Number > New to add the extension numbers. Click Contact List > New to add the contacts. Then click the icon to add extension numbers to it. Define the short number -15-...
  • Page 17 Click Extension Assignment > Extension Assignment to assign an extension number and synchronize the contacts to the device. Once the SIP is set up correctly, a green dot will appear in the upper right corner of the call page, indicates that the device is connected to the server. Device Call the Indoor Monitor (VT07-B26L-W / VT07-B22L) On the ZKBio CVAccess software, click Video Intercom >...
  • Page 18 322603 2601 Device Call the Phone (ZKBio Zexus App) On the ZKBio CVAccess software, assign an extension number to the personnel. Click the icon on the device to enter the call page, enter the Short Number of the personnel, or click the icon to open the contact list, select the personnel you want to call.
  • Page 19 Device Call the PC Client (BioTalk Pro) Install the BioTalk Pro software and configure the SIP account. (The SIP account is created in the ZKBio CVAccesss.) Click the icon on the device to enter the call page, enter the Short Number of the PC client, or click the icon to open the contact list, select the PC clinet you want to call.
  • Page 20 13 Connect the Wireless Doorbell This function needs to be used with the wireless doorbell. First, power on the wireless doorbell. Then, press and hold the music button 1.5 seconds until the indicator flashes to indicate it's in pairing mode. After that, click on the device icon , if the wireless doorbell rings and the indicator flashes, it means the connection is successful.

  • Page 21: Onvif Settings

    14 ONVIF Settings This function needs to be used with the Network Video Recorder (NVR). Set SenseFace 4 Series device to the same network segment as the NVR. Click >Intercom > ONVIF Settings to set the User Name and Password.
  • Page 22 Select the checkbox for the device you want to add and edit the parameters in the corresponding text field, then click on OK to add it to the connection list. After successfully adding, the video image obtaining from the device can be viewed in real-time.
  • Page 23 ZKTeco Industrial Park, No. 32, Industrial Road, Tangxia Town, Dongguan, China. Phone : +86 769 - 82109991 : +86 755 - 89602394 www.zkteco.com Copyright © 2025 ZKTECO CO., LTD. All Rights Reserved.
