SA40
User Manual
SA40
Date: July 2021
Doc Version: 1.0
English
Thank you for choosing our product. Please read the instructions carefully
before operation. Follow these instructions to ensure that the product is
functioning properly. The images shown in this manual are for illustrative
purposes only.
P a g e
| 1
For further details, please visit our Company's website
www.zkteco.com.
Copyright©2020 ZKTECO CO., LTD. All rights reserved.
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SA40 and is the answer not in the manual?

Questions and answers

Summary of Contents for ZKTeco SA40

  • Page 1 Follow these instructions to ensure that the product is functioning properly. The images shown in this manual are for illustrative purposes only. For further details, please visit our Company’s website www.zkteco.com. P a g e Copyright©2020 ZKTECO CO., LTD. All rights reserved.
  • Page 2 Copyright © 2021 ZKTECO CO., LTD. All rights reserved. Without the prior written consent of ZKTeco, no portion of this manual can be copied or forwarded in any way or form. All parts of this manual belong to ZKTeco and its subsidiaries (hereinafter the "Company" or "ZKTeco").
  • Page 3 SA40 User Manual relating to the use of the information contained in or referenced by this manual, even if ZKTeco has been advised of the possibility of such damages. This manual and the information contained therein may include technical, other inaccuracies or typographical errors.
  • Page 4 User Manual About the Company ZKTeco is one of the world’s largest manufacturer of RFID and Biometric (Fingerprint, Facial, Finger-vein) readers. Product offerings include Access Control readers and panels, Near & Far-range Facial Recognition Cameras, Elevator/floor access controllers, Turnstiles, License Plate Recognition (LPR) gate controllers and Consumer products including battery-operated fingerprint and face-reader Door Locks.
  • Page 5 The general information which helps in performing the operations faster. The information which is significant. Care taken to avoid danger or mistakes. The statement or event that warns of something or that serves as a cautionary example. P a g e Copyright©2021 ZKTECO CO., LTD. All rights reserved.
  • Page 6 BASIC CONCEPTS ..........................9 ....................................9 ESCRIPTION OF ......................................9 ATEGORIES ......................................10 ATEGORIES ...................................... 10 IRING EFINITION OPERATIONS ............................10 APPENDIX 1: FAQ ............................16 APPENDIX 2: PACKING LIST ........................16 P a g e Copyright©2021 ZKTECO CO., LTD. All rights reserved.
  • Page 7 ③ If an extension cable needs to be connected between the all-in-one device and the controller, we recommend that you use a Category 6 or above unshielded network cable; otherwise, voltage drop may occur on the extension cable, resulting in an unstable card reading effect. P a g e Copyright©2021 ZKTECO CO., LTD. All rights reserved.
  • Page 8 I indicates the output current of the device power supply, U indicates the operating voltage of the lock, LOCK and I indicates the operating current of the lock. LOCK P a g e Copyright©2021 ZKTECO CO., LTD. All rights reserved.
  • Page 9 150mA. The power supply can work after its positive and negative poles are connected to +12V and GND terminals respectively. Do not reverse its positive and negative poles. (4) Connect other devices Exit button Door sensor Doorbell P a g e Copyright©2021 ZKTECO CO., LTD. All rights reserved.
  • Page 10 When the administrator card is directly swiped twice, the door sensor switches between the NO and NC modes. When the addition card is directly wiped, it enters the batch adding card- P a g e Copyright©2021 ZKTECO CO., LTD. All rights reserved.
  • Page 11 To restore its factory settings, make a short circuit between pins 1 and 2, or between pins 2 and 3 of the 3-pin connector (next to the relay) on the device board, and then power on the device. P a g e | 10 Copyright©2021 ZKTECO CO., LTD. All rights reserved.
  • Page 12 Swipe the second card The card is deleted. 7. Set Shortcut Operations In standby state, you can use the administrator card, addition card, and deletion card to enter different function modes. P a g e | 11 Copyright©2021 ZKTECO CO., LTD. All rights reserved.
  • Page 13 11. Delete a User You can delete a user by using three methods. Press *#administrator password4enter the user password# (You can consecutively enter the password to delete multiple users.) P a g e | 12 Copyright©2021 ZKTECO CO., LTD. All rights reserved.
  • Page 14 14. Modify User Password You can modify the user password by using two methods. Password-based users: Press *#administrator password6old password#new password of 4-6 digits# For example: *#12346123456#12345# P a g e | 13 Copyright©2021 ZKTECO CO., LTD. All rights reserved.
  • Page 15 2) Disable the alarms: Directly swipe the deletion card for three times to disable the door sensor alarm and the alarm for pressing a key by mistake. P a g e | 14 Copyright©2021 ZKTECO CO., LTD. All rights reserved.
  • Page 16 The default initial value is 8888. Door opening delay time The value range is 1-60s. The default value is 3s. Key backlight The default value is normally on. P a g e | 15 Copyright©2021 ZKTECO CO., LTD. All rights reserved.
  • Page 17 Appendix 2: Packing List Screws for wall FR107 diode Access control device & Card mounting back plate Rubber plugs L-shaped hexagonal Tamper User Manual screwdriver screw bolt P a g e | 16 Copyright©2021 ZKTECO CO., LTD. All rights reserved.
  • Page 18 ZKTeco Industrial Park, No. 32, 188 Industrial Road, Tangxia Town, Dongguan, China. Phone : +86 769 - 82109991 : +86 755 - 89602394 www.zkteco.com Copyright © 2021 ZKTECO CO., LTD. All Rights Reserved.
