Quick Start Guide
SenseFace 2A
Version: 1.1
Due to regular upgrades of systems and products, ZKTeco could not guarantee exact consistency between the
actual product and the written information in this manual.

Advertisement

loading
Need help?

Need help?

Do you have a question about the SenseFace 2A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ZKTeco SenseFace 2A

Summary of Contents for ZKTeco SenseFace 2A

  • Page 1 Quick Start Guide SenseFace 2A Version: 1.1 Due to regular upgrades of systems and products, ZKTeco could not guarantee exact consistency between the actual product and the written information in this manual.

  • Page 2: Terminal Block

    1 Overview Microphone 33.30mm 74.20mm Flash Camera Near-infrared Flash 2.4-inch Color Screen Keypad Doorbell Button Reset Fingerprint Sensor Speaker Card Reading Area Front Bottom Side 2 Terminal Block Lock, Door Sensor& Exit Button 12VIN Power In Network Tamper Switch...

  • Page 3: Installation Environment

    3 Installation Environment Please refer to the following recommendations for installation. 10ft KEEP DISTANCE AVOID GLASS AVOID DIRECT AVOID USE OF REFRACTION SUNLIGHT ANY HEAT SOURCE AND EXPOSURE NEAR THE DEVICE 4 Device Installation ① Stick the mounting template sticker to the wall and drill holes according to the mounting template sticker. ②...

  • Page 4: Standalone Installation

    5 Standalone Installation Door Sensor Exit Button Wireless Doorbell Lock ZKBio CVAccess TCP/IP ★ Note: Features and parameters with mark are not available in all devices. 6 Power Connection AC Adapter DC 12V 1.5A Recommended AC Adapter 1) 12V ± 10%, at least 1500mA. 2) To share the power with other devices, use an AC Adapter with higher current ratings.

  • Page 5: Ethernet Connection

    7 Ethernet Connection Connect the device and computer software via an Ethernet cable. As shown in the example below: Router ZKBio CVAccess Enter [COMM.] > [Ethernet] to set the relevant parameters of network. Note: In LAN, the IP address of the server (PC) and the device must be in the same network segment when connecting to the software.

  • Page 6: Lock Relay Connection

    9 Lock Relay Connection The system supports Normally Opened Lock and Normally Closed Lock. The NO LOCK (normally unlocks when power-on) is connected with 'NO' and 'COM' terminals, and the NC LOCK (normally locks when power-on) is connected with 'NC' and 'COM' terminals.
  • Page 7 10 Connect the Wireless Doorbell This function needs to be used with the wireless doorbell. First, power on the wireless doorbell. Then, press and hold the music button for 1.5 seconds until the indicator flashes to indicate it's in pairing mode. After that, press the doorbell button on the device, if the wireless doorbell rings and the indicator flashes, it means the pairing was successful.

  • Page 8: User Registration

    11 User Registration Press the M/OK key to access the main menu in case the device has not been configured with a super administrator. When creating a new user, assign the User Role as Super Admin. This action will prompt the system to request verification from the administrator before granting access to the menu.
  • Page 9 When an appropriate server address and port is set on the device, the searched device displays automatically. SenseFace 2A Click [Add] in operation column, a new window will pop-up. Select Icon type, Area, and Add to Level from each drop down list and click [OK] to add the device.
  • Page 10 Method 3: Register on the phone: Click [Personnel] > [Parameters], enter ‘’http://Server address: Port’’ in the QR Code URL bar. The software will automatically generate a QR code. Scan the QR code or login onto ‘’http://Server address: Port/tokenAdreg’’ by the mobile phone to register users.
  • Page 11 12 Ethernet and Cloud Server Settings Press M/OK and enter [COMM.] > [Ethernet] to set the network parameters. If the TCP/IP communication of the device is successful, the icon will be displayed in the upper right corner of the standby interface. Press M/OK and enter [COMM.] >...

  • Page 12: Onvif Settings

    13 ONVIF Settings This function needs to be used with the Network Video Recorder (NVR). Set the device to the same network segment as the NVR. 2. Press M/OK and enter [Intercom] > [ONVIF Settings] to set the User Name and Password.
  • Page 13 4. Select the checkbox for the device you want to add and edit the parameters in the corresponding text field, then click on OK to add it to the connection list. 5. After successfully adding, the video image obtaining from the device can be viewed in real-time.

  • Page 14: Sip Settings

    14 SIP Settings The device achieves video intercom there are two modes, respectively, the LAN and SIP server. Local Area Network Use In this mode, please make sure that the SIP Server of the device is disabled. This function needs to be used with the indoor monitor VT07-B01. Set the indoor monitor to the same network segment as the device.
  • Page 15 Call Contact List On the SIP Settings interface, enter [Local Settings] to enable the call contact list. Press the key on the device to enter the call page, then you can press the Up key to open the contact list, select the number of the indoor monitor you want to call.
  • Page 16 Press the key on the device and select the calling shortcut keys to call the indoor monitor. Direct Calling On the SIP Settings interface, enter [Calling Shortcut Settings] > [Call Mode] > [Direct Calling Mode]> [Add]. Select the indoor monitors that you want to call, then the indoor monitors will be displayed in the list.
  • Page 17 SIP Server In this mode, please make sure that the SIP Server of the device is enabled. This function needs to be used with the ZKBio CVAccess server, ZKBio Zexus Mobile App, indoor monitor VT07-B26L-W / VT07-B22L and PC Client BioTalk Pro. There are 2 kinds of SIP server: Cloud SIP and PBX server.
  • Page 18 2. Add the device to the Access Module of the software. Then the device will be automatically synchronized to the Video Intercom module. Click Video Intercom > Extension Management > Extension Number > New to add the extension numbers. Click Contact List > New to add the contacts. Then click the icon to add extension numbers to it.
  • Page 19 Click Extension Assignment > Extension Assignment to assign an extension number and synchronize the contacts to the device. Once the SIP is set up correctly, a green dot will appear in the upper right corner of the call page, indicates that the device is connected to the server. Device Call the Indoor Monitor (VT07-B26L-W / VT07-B22L) On the ZKBio CVAccess software, click Video Intercom >...
  • Page 20 322603 2601 Device Call the Phone (ZKBio Zexus App) On the ZKBio CVAccess software, assign an extension number to the personnel. Press the key on the device to enter the call page, enter the Short Number of the personnel, or press the Up key to open the contact list, select the personnel you want to call.
  • Page 21 Device Call the PC Client (BioTalk Pro) Install the BioTalk Pro software and configure the SIP account. (The SIP account is created in the ZKBio CVAccesss.) Press the key on the device to enter the call page, enter the Short Number of the PC client or press the Up key to open the contact list, select the PC client you want to call.
  • Page 22 ZKTeco Industrial Park, No. 32, Industrial Road, Tangxia Town, Dongguan, China. Phone : +86 769 - 82109991 : +86 755 - 89602394 www.zkteco.com Copyright © 2025 ZKTECO CO., LTD. All Rights Reserved.
