Product Descripon
4. Product Descripon
TIP
To use all features the latest version of the CAN-Gateway Conguraor as well as the latest rmware
of the CANbridge NT must be installed. For documenaon of rmware versions below V6 contact
Ixxat support.
The CANbridge NT is a universal, intelligent CAN topology component, that allows the coupling of several CAN
networks with dieren baud rates or frame formats in the operaonal modes Repeater/Star Coupler and Bridge.
The CANbridge NT 420 addionally is capable of CAN FD. CAN messages are received by one network and
ransmied in the other network, according to ler and implemenaon rules. The lering mechanism is based
on a list of CAN ideners. With the CANbridge NT 420 bridging between Classic CAN and CAN FD is possible.
4.1. Features
• CANbridge NT 200: 2 x CAN connecons (terminal adapters)
• CANbridge NT 420: 4 x CAN connecons (terminal adapters), via the CAN-Gateway Conguraor two
connecons can be switched between Classic CAN and CAN FD
• 1 x mini USB 2.0 port, high-speed, for conguraon
• CAN/CAN FD according to ISO 11898-1:2015
• CAN high speed according to ISO 11898-2:2016
• freely congurable baud rates
• auomac baud rate deecon
• With the CAN-Gateway Conguraor a conguraon can be created, modied, wrien to and read from the
target device via USB or Ethernet connecon.
The conguraon of the following features are described in detail in the User Manual CAN- Gateway
Confguraor CANbridge NT & CAN@net NT 100/200/420:
• Classic CAN/CAN FD ID lering (mapping)
• Classic CAN to CAN FD mapping and CAN FD to Classic CAN mapping (with NT 420)
• J1939 mapping
• cyclic transmission of CAN messages
• command line program CANGWle (available for Windows and Linux)
• acon rules via i-his-acon-hen-ha-even unconaliy
4.2. Default Conguraon
By default the CANbridge NT is congured as Repeater, the CANbridge NT 420 as Star Coupler with baud rate 125
kBaud on each port. In the Repeater/Star Coupler mode all messages are ransmied unchanged to the other
ports in Classic CAN mode.
4.3. Operaonal Modes
4.3.1. Repeater/Star Coupler
The CANbridge NT 200 can be congured as Repeater and the CANbridge NT 420 as Star Coupler. In the
Repeater/Star Coupler mode all messages are ransmied unchanged to the other ports in Classic CAN mode.
Filters, CAN-ID modicaons and CAN-FD mode are not possible.
The following setngs and features are possible:
