CANbridge NT 200 and 420
• See update package on the product support pages on
inormaon about updang to V5 or contact Ixxat support.
If the current rmware of the device in use is V5 or V6:
1. Check if newer rmware is available on the product support pages on
www.ixxat.com/support-bridges-gateways.
2. Download and unzip the update package.
3. Make sure, that the device is connected to power supply.
4. Connect the device to the computer via USB.
5. Make sure that the latest CAN-Gateway Conguraor is installed (check within product support pages on
www.ixxat.com/support-bridges-gateways).
6. Start the CAN-Gateway Conguraor.
7. In drop down list Select device type select the device in use.
8. In drop down list Select device version select the current rmware version of the device V5 or V6.
The device is only found if the selected rmware version matches the rmware version of the connected
device.
9. Scan for devices with buon Scan
10. Click buon Connect
11. Open menu Target and select Read conguraon from target.
12. Save the conguraon on the computer.
13. Open menu Target and select Update Firmware.
14. Select the update le.
• Firmware of the connected device is updated.
15. In the status window check if the update is completed successfully.
16. If the device was updated from V5 to V6 , select V6 in drop-down list Select device version.
17. If using a V5 conguraon, open menu File and select Convert V5 to V6 to convert the conguraon to the
latest version.
18. Write the saved conguraon to the device.
TIP
HMS recommends to verify conguraons that are converted from V5 to V6, to make sure that all
setngs are working correctly.
Page 10 of 24
and select the device in use in the combo box Target Device.
.
Checking and Updang the Firmware
www.ixxat.com/support-bridges-gateways for
