CANbridge NT 200 and 420
1 Inormaon about target device (STS reecs Power LED of device)
2 Drop-down list Select device type
3 Drop-down list Select device version
4 Drop-down list Select operaonal mode
5 Buon New
6 Buon Open
7 Buon Save
8 Buon Save as
9 Buon Verify
10 Buon Scan
11 Combo box Target device
12 Buon Connect
13 Buon Write to
14 Buon Read from
1. Make sure, that the latest VCI driver is installed.
2. Make sure, that the device is correctly installed (see
3. Connect a device to the host computer via Mini USB cable.
4. Make sure, that the latest rmware is on the device (see
5. Make sure, that the lates CAN-Gateway Conguraor is installed (check whithin product support pages on
www.ixxat.com/support-bridges-gateways).
6. Start the Ixxat CAN-Gateway Conguraor.
7. Open menu Scan and select All Ixxat devices.
• Connected devices and rmware version of the devices are shown.
8. Select the type of CANbridge NT in use in drop-down list Select device type (2).
9. Select the rmware version of the device in drop-down list Select device version (3).
10. Select the desired operaonal mode for the device in use in drop-down list Select operaonal mode (4).
11. Select the device in combo box Target device (11).
12. Click buon Connect (12) to connect the selected device.
• If device is connected, STS (1) is green ashing.
• Inormaon about the target device is shown (1).
13. To create a new project le, click buon New (5).
14. To change the current conguraon of the device, click buon Read from (14) and safe the conguraon.
15. Congure the device in the desired mode (see
Conguraon, p. 14).
6.2. Conguring the Device Name
The displayed name of a connected device can be chosen freely.
Page 12 of 24
Installing the Hardware, p.
Checking and Updang the Firmware, p.
Repeater/Star Coupler Conguraon, p. 13
Conguring the Device Name
8).
9).
or Bridge
