Indicators
LED state Descripon
O Device not ready
Green ashing (1 Hz) Applicaon rmware started
Red/green ashing Conguraon le error
Green/orange Device in Confguring state
ashing
Orange ashing (1 Lua ADK in remote mode
Hz)
Red ashing Device error
7.2.3. User LED
Indicates the primary applicaon status and can be congured with user dened setngs via Acon Rules. See
User Manual CAN-Gateway Conguraor for more inormaon.
7.2.4. CAN LED
CAN 1-4 LEDs indicate the status of the corresponding CAN interface.
LED state Descripon
O No CAN communicaon
Orange ashing Indicates a state of the auomac baud
rate deecon
Green ashing / CAN communicaon
green
Red ashing CAN communicaon, CAN controller in
Error state
Red Bus o
4.01.0331.20000 Version 2.0
Comments
No rmware, applicaon rmware not started
Device in Operatonal state
Rewring of conguraon to device necessary
In Confguring state the device read the conguraon from the
local le system.
Lua ADK in remote mode regardless of whether a Lua client is
connected via USB or not.
Applicaon signals a device error, error in conguraon or no
conguraon. Read log le for more inormaon (see
erase LOG File, p. 17).
Comments
No connecon to CAN
See User Manual CAN Gateway Confguraor
LED is triggered with each CAN message
CAN controller in Error Warning or Error Passive state,
recepon/ransmission of CAN messages possible
CAN controller is in Bus O state, no CAN communicaon
possible
