1 About this manual
This Technical Reference manual applies to the complete range of IRIS-4 models, see chapter 2 "About IRIS-4
product range".
1.1 Target group
This document is intended as a technical reference for engineers and for anybody that needs technical
information about the IRIS-4 range of terminals.
1.2 Scope
This document has all the technical information about the IRIS-4 range of terminals running software version
4.24.1. Many of the features described are also available in earlier software versions. More information
about connecting to proprietary alarm panels is in the separate documents.
The manual has these chapters:
1 About this manual
2 About the IRIS-4 product range
3 Circuit board layouts
4 Basic Setup
5 Configuring the terminal
6 Settings
7 Installation for EN54-21:2006
Compliance
8 Installation for VdS 2463
Compliance
9 Trouble reporting and test
10 Maintenance
11 Technical Specifications
12 Conformance
A1 Setting up the IRIS Toolbox
A2 Abbreviations used
A3 T-NG-ENC2 enclosure.
A4 Panel Specific Protocol Handling
(Emulation Mode)
A5 Default alarm messages
generated by the terminal
page 8
Describes the range and scope of the manual.
Presents the terminals in the IRIS-4 range.
Presents the Printed Circuit Boards (PCB) for each terminal.
Explains how to install the terminals.
Explains how to configure the terminals for their purpose.
Explains how to configure all the settings.
Installation instructions for complying with this standard.
Installation instructions for complying with this standard.
Explains how the terminal reports problems and how to test an
installation.
Explains maintenance procedures.
Lists all the technical specifications for the products.
Lists the standards to which the products conform.
Explains how to install the IRIS Toolbox.
Lists and explains all abbreviations used in the document.
Description and installation instructions for the enclosure for the
IRIS-4 4xx and 6xx terminals.
Explains how settings for specific alarm panel types can be used to
enable alarms to be sent based on serial messages from the panel.
Some input and fault related alarms are generated directly by the
terminal and sent to the ARC. This section lists the default
settings.
