Fault reporting to Monitoring Center
Relay outputs
Maximum operating voltage
Maximum current rating
Power supply
Supply voltage
IRIS-4 160
others
Typical current
IRIS-4 50 (DS2220)
IRIS-4 160
IRIS-4 200/220/240
IRIS-4 400/420/440
IRIS-4 400/420/440G
IRIS-4 620/640
IRIS-4 620D/640D
Maximum current
Recommended external PSU
Environmental
Operating temperature range
Operating humidity range
Weights and dimensions: IRIS-4 50 (DS2220)
Physical dimensions
PCB weight
Fully packaged weight
Weights and dimensions: IRIS-4 160
Physical dimensions
PCB weight
Fully packaged weight
Weights and dimensions: IRIS-4 2xx
Physical dimensions
PCB weight
Fully packaged weight
Weights and dimensions: IRIS-4 4xx
Physical dimensions
PCB weight
Fully packaged weight
Weights and dimensions: IRIS-4 6xx
Physical dimensions
PCB weight
Fully packaged weight
page 64
Tamper input (where fitted)
Transmission interface/path fault
24V DC
100mA DC
9V to 15V DC
9V to 28V DC
At 12V DC: 80mA
At 24V DC: 40mA
At 12V DC: 83mA
At 12V DC: 138mA / 110mA / 153mA
At 24V DC: 78mA / 63mA / 86mA
At 12V DC: 157mA / 120mA / 160mA
At 24V DC: 87mA / 68mA / 89mA
At 12V DC: 122mA/130mA/137mA
At 24V DC: 63mA/69mA/73mA
At 12V DC: 68mA / 89mA
At 24V DC: 55mA / 76mA
At 12V DC: 134mA /142mA
At 24V DC: 58mA / 81mA
At 12V DC and 24V DC: 1A
12V DC 1A 12 Watt
Note: The Radio Equipment Directive states that the length of the
power cable may only be a maximum of 3 meters long.
-10°C to 55°C
95% max., non-condensing
87mm x 55mm x 16mm
85 grams (with wire harness)
200 grams
11 cm x 17.5 cm x 4.5 cm
400 grams
600 grams
19 cm x 13 cm x 4 cm
550 grams
750 grams
14 cm x 11.5 cm x 1.5cm
300 grams
500 grams
12 cm x 9 cm x 2cm
60 grams
160 grams
