6.3 Account name/number
This option lets you change the account name/number for the terminal, as
allocated by the ARC.
For Iris this can be alphanumerical and up to 32 characters long. It is normal to
have a simple 4- or 6-digit numerical account name.
For DC-09, the account name can be between 3 and 16 hexadecimal characters.
Enter the account (name/number) provided by the ARC. Click «save».
6.4 Eth 1: For terminals with Ethernet capability
If your terminal has one Ethernet connector, this will be called "Dialler IP
Address". This allows you to set up the IP address of the terminal to use either
automatic (DHCP) or a fixed IP address. The settings below will show the IP
address either received (DHCP mode) or, if fixed will, let you set the IP address,
Subnet Mask and Gateway:

IP Address

Subnet Mask

Gateway

Mac Address (view only)
6.5 Eth 2: For terminals with dual Ethernet capability
By default, the Eth 2 connector is a shared Ethernet port with Eth 1 acting like a
switch.
If you require the Eth 2 connection to be separate to Eth 1, make sure "Eth 1/2
Switch" is not ticked.
Cellular Bridge
Cellular Bridge creates a bridge between Eth2 and the terminal's cellular
interface for UDP and TCP traffic. The IP address of the connected device should
be set to be the same as the IP address for data connections allocated by the
SIM card as shown in the "Cell/Client IP" sub-menu.
Note that there is potentially a security risk of unauthorized access to the device connected to Eth2 and to
minimize this risk the SIM card should use a private APN (see Cellular Settings section below), such as that
provided by the AddSecure Link service.
6.5.1.1 DHCPSRV or Fixed
Click on «DHCPSRV» if you want the terminal to assign the IP address to the device attached to Eth 2
automatically.
6.5.1.2 Cell/Client IP
This is the IP address that must be assigned to the device attached to Eth 2 and called from the cellular
network when a remote connection to this device is required. This address is the address the cellular
network assigns to the SIM card and cannot be changed.
