6.13.1.3 Inverse polarity
When ticked, this reverses the function of the inputs "Set" and "Restore". This will mean that the "Set" will
be a closed circuit and the "Restore" will be an open circuit.
Alarm format SMS
Selecting SMS format for all pins or ticking this box for a specific pin will mean
that on input "Set" (open circuit) and input "Restore" (closed circuit), the
terminal will send the configured SMS text for the set or restore message to the
configured phone number.
6.13.2.1 Phone number
This option lets you enter the phone number to which the SMS message will be sent
6.13.2.2 Set msg and Restore msg
Enter the Set and Restore text messages to be sent. No message is sent for an entry that is blank.
Alarm format SIA
On input "Set" (open circuit) and input "Restore" (closed circuit), the terminal
will send SIA alarm protocol messages for that input.
6.13.3.1 Set msg and Restore msg
Here you can input the "Set" and "Restore" messages in the correct format as defined in SIA format protocol
SIA DC-03-1990.01(R2003.10). The default "Set" and "Restore" event codes are in the table below.
These defaults can be changed and text descriptions to be sent with the SIA alarm code (under SIA level 3
alarm protocols) can be added. If you exceed the maximum number of characters for the combined set and
restore messages supported by the terminal, a warning will be shown.
Text descriptions can be added by adding ^ before and after the text. For example, to add the text "Fire" to
the message SIA code "NFA01", input "NFA01^FIRE^" into the touchscreen.
These alarms are pre-coded as shown in the Default Alarm Message appendix.
Alarm format FF
Selecting FF for the inputs means that the inputs will send a specific Scancom FF
alarm protocol message on the event and restore for that input.
6.13.4.1 Alarm
This sets the input to be an alarm triggered by an input.
Signal Event Type
1 New alarm
3 New restore
5 Not in alarm
6 In alarm
Description
The alarm triggering input is active and has not yet
been reported.
The alarm triggering input has returned to its quiescent
state from the alarm state.
The alarm triggering input is quiescent.
The alarm triggering input is active and has been
reported.
