Connecting CipherLab 9700 Handheld to PC
To connect CipherLab 9700 scanner to your PC or Laptop, follow the steps:
1. Plug the handheld into the computer as shown on Figure 3.
2. Make sure the dock is connected to the power.
3. Place the handheld on the dock.
NOTE! Before beginning, make sure your handheld is charged so that
way you don't lose anything due to it running out power.
Connecting CipherLab 9700 Handheld Using LAIRD Wireless
You can connect the CipherLab 9700 handheld to a network over LAIRD wireless.
Prerequisites
Before you set up a wireless connection for the CipherLab 9700 handheld, make sure that the following
prerequisites are met:
You have information about network ports and settings of the router to which you are planning to
•
connect.
You have information about the name of the Wi-Fi network and password to connect to the router.
•
The router is connected hardline on the site where you are setting up the CipherLab 9700 handheld.
•
NOTE! It is recommended that you always have a spare Ethernet cable. Make sure that you do not connect the
handheld to computer over USB.
Connecting CipherLab 9700 Handheld To Router
To connect CipherLab 9700 Handheld to the router over LAIRD wireless, follow the steps:
1. Power on the CipherLab 9700 Handheld.
2. On the AppLock screen, click the Laird Wi-Fi icon.
© Petrosoft LLC. All rights reserved. Confidentiality level – Internal use
CIPHERLAB 9700 WITH MOBILE ASSISTANT APPLICATION
CipherLab 9700 Scanner to PC
/ Version 1.1
FIGURE 3 Connecting
