SOMFY Dexxo Compact io Instructions Manual page 6

EN
TRANSLATED VERSION OF THE MANUAL
CONTENTS
1 Safety instructions ................................................................................
1.1 Caution - Important safety instructions....................................
1.2 Product specifications .................................................................
SAFETY MESSAGES
DANGER
Indicates a danger which may result in immediate death or serious injury.
WARNING
Indicates a danger which may result in death or serious injury.
PRECAUTION
Indicates a danger which may result in minor or moderate injury.
CAUTION
Indicates a danger which may result in damage to or destruction of the
product.
1 SAFETY INSTRUCTIONS
1.1 Caution - Important safety instructions
DANGER
The motorisation must be installed and
adjusted by a professional motorisation and
home automation installer, in compliance
with the regulations of the country in which it
has been commissioned. Furthermore, he
must follow the instructions in this guide
throughout the installation procedure. Failure
to comply with these instructions may result
in serious injury, e.g. due to crushing by the
garage door.
WARNING
Installation instructions and training the users
For reasons of personal safety, it is important
to follow all the instructions, as incorrect
installation can lead to serious injury. Retain
these instructions.
The installer must train all users to ensure
completely safe use of the motorisation, in
accordance with the user manual.
The user manual and installation manual must
be given to the end user.
The installer must explain clearly to the end
user that installation,
maintenance of the motorisation must be
performed by a professional motorisation and
home automation installer.
WARNING
Use of the product
Any use made of this product outside the field
of application described in this manual is
prohibited (see "Field of application" section).
The use of any accessory or component not
recommended by Somfy is prohibited as this
may place people at risk.
6
6
6
6
Somfy cannot be held responsible for any damage
resulting from non-compliance with the instructions
in this guide.
If you have any doubts when installing the
motorisation or to obtain additional information,
please consult the website www.somfy.com .
These instructions may be modified in the event of a
change to the standards or the motorisation.
1.2 Product specifications
Dexxo Compact 600 io/Dexxo Compact 750 io
This product is a drive for vertically opening garage
doors in residential use as defined in standard EN
60335-2-95, with which it complies.
Dexxo Compact 1000 io
This product is a motorisation for vertically- or
horizontally-opening garage doors, for residential
use as defined in standards EN 60335-2-95 and EN
60335-2-103, with which it complies.
The main purpose of these instructions is to satisfy
the requirements of the aforementioned standards,
and to ensure personal and equipment safety.
1.3 Preliminary checks
1.3.1 Installation environment
1.3.2 Condition of the door to be motorised
adjustment and
Before installing the motorisation, check that:
1.3 Preliminary checks .......................................................................
1.4 Risk prevention.............................................................................
1.5 Electrical installation ....................................................................
1.6 Safety instructions relating to installation .................................
1.7 Regulations ...................................................................................
1.8 Assistance .....................................................................................
CAUTION
Do not spray water onto the drive.
Do not install the drive in an explosive
environment.
Check that the temperature range marked on
the drive is suited to the installation location.
CAUTION
Do not install the drive in a wet environment.
This drive is intended for indoor use.
• the door is in good mechanical condition
• the door is correctly balanced
• The structures of the garage (walls, lintel,
partitions, ceiling, etc.) enable the motorisation
to be mounted securely. Reinforce these if
necessary.
• the door can be correctly opened and closed
using a force of less than 150 N.
DANGER
It is dangerous to perform any operation on
the door springs (the door may fall).
Copyright
Dexxo Compact io
© 2024 SOMFY ACTIVITES SA. All rights reserved.
