  • Page 1 Dexxo Optimo RTS Installation manual Manual de instalación Manual de instalação Εγχειρίδιο εγκατάσταση̋ 5056739C...

  • Page 3: Table Of Contents

    CONTENTS GENERAL PRESENTATION __________________________________________________ 2 SAFETY INSTRUCTIONS ____________________________________________________ 2 Caution Safety instructions PRODUCT DESCRIPTION ____________________________________________________ 2 Product components Area of application POINTS TO CHECK PRIOR TO INSTALLATION __________________________________ 3 Preliminary checks Safety instructions INSTALLATION _____________________________________________________________ 3 Installation height Detailed description of installation steps PROGRAMMING ___________________________________________________________ 5 Programming button description End limit setting and self-learning...

  • Page 4: General Presentation

    Failure to comply with these instructions absolves Somfy from any liability resulting from damage that may be caused. Dexxo Optimo RTS is a product that must be installed inside the garage with an integrated back-up control system.

  • Page 5: Points To Check Prior To Installation

    (spring tension). Remember that any work performed on door springs may be dangerous. The structure of your garage (walls, lintel, inside surfaces, cross members, door rails…) are used to mount the Dexxo Optimo RTS system. Reinforce them where necessary.
  • Page 6 Fitting the rail onto the motor head (Fig. 6) Fitting the complete assembly onto the garage ceiling (Fig. 7 à 9) Fitting to the lintel bracket (Fig. 7) Ceiling mounting • Flush with the ceiling: mount the system directly onto the ceiling using the rail (Fig.

  • Page 7: Programming

    Memorising remote controls for full opening cycle Fig. Up to 32 control channels can be stored. Running this procedure for a previously stored channel will clear it. At this stage in the installation process, the Dexxo Optimo RTS motor drive unit is ready to run.

  • Page 8: Operating Test

    OPERATING TEST Using the remote controls Fig. Obstacle detection function Fig. 18 and 19 The detection of an obstacle during door opening will stop the door (Fig. 18). The detection of an obstacle during door closure will reopen the door (Fig. 19). Make sure that obstacle detection works when the door encounters an obstacle 50 mm from the ground.

  • Page 9: Setup And Operating Options

    SETUP AND OPERATING OPTIONS General setup diagram Fig. Meanings of the various parameters Programming example: adjusting the long slowdown zone “P1=3” (Fig. 24) Code Description Values Comments Obstacle detection sensitivity If this setting is changed, it is essential to run the force measurement : low sensitivity sequence at the end of the installation procedure : low sensitivity...

  • Page 10: Technical Specifications

    TECHNICAL SPECIFICATIONS Dexxo Optimo RTS BASIC TECHNICAL CHARACTERISTICS Mains power supply 230 V - 50 Hz Max. power consumption Standby-Operation 4 W - 120 W Traction force Peak force 800 N Starting force (1) 650 N 20 cycles per day max. tested for 36,500 cycles Number of Opening/Closing cycles per day Max.
  • Page 11 Dexxo Optimo RTS User Manual CONTENTS GENERAL PRESENTATION __________________________________________ 2 The world of Somfy Support SAFETY INSTRUCTIONS ____________________________________________ 2 Standards Safety instructions PRODUCT PRESENTATION __________________________________________ 2 OPERATION AND USE ______________________________________________ 3 Normal operation Special operation PERIPHERALS _____________________________________________________ 5 MAINTENANCE ____________________________________________________ 5...

  • Page 12: General Presentation

    Failure to comply with these instructions absolves Somfy from any liability for any damage that may be caused. Dexxo Optimo RTS is a product that must be installed inside the garage with a built-in back-up control system.

  • Page 13: Operation And Use

    Manual release cord operation (Fig. 8) Dexxo Optimo RTS is fitted with a manual release mechanism so that you can move the door manually should a power failure occur, for example. The manual release mechanism should be easily accessible and located no more than 1.80 metres above floor level.

  • Page 14: Special Operation

    Special operation Depending on the peripherals installed and the operating options set by your installer, the Dexxo Optimo RTS system may perform the following special operations: Full opening cycle using Telis or similar remote controls (Fig. 9a) Partial opening cycle using Telis or similar remote controls (Fig. 9b) Safety photoelectric cell operation An obstacle detected between the cells will prevent the door from closing.

  • Page 15: Peripherals

    PERIPHERALS A number of peripherals are available. Description Comments Hand held 2 channel remote control. Keytis 2NS RTS remote control Keytis 4NS RTS remote control Hand held 4 channel remote control. KEYGO remote control Four channel keyring remote control. RTS pushbutton Wall mounted 2 channel remote control switch.

  • Page 16: Checking

    Traction force – Peak force 800 N 20 cycles per day with a standard rail (tested for 36,500 cycles) Number of channels that can be memorised Somfy radio frequency 433,42 MHz RTS Integrated light 24 V / 21 W max. E13 socket Operating temperature -20 °C / +60 °C...
