- Page 1 Bioness Medical, Inc. 25103 Rye Canyon Loop Valencia, CA 91355 USA Telephone: 800.211.9136 Website: BionessMedical.com Rx Only © 2025 Bioness Medical, Inc. 602-00690-001 Rev. J 03/2025...
- Page 2 INSTALLATION GUIDE...
- Page 4 Disclaimer Bioness Medical, Inc. and its affiliates shall not be liable for any injury or damage suffered by any person, either directly or indirectly, as a result of the unauthorized use or repair of Bioness Medical, Inc. products. Bioness Medical, Inc. does not accept any responsibility for any damage caused to its products, either directly or indirectly, as a result of use and/or repair by unauthorized personnel.
-
Page 5: List Of Symbols
List of Symbols Caution Warning Class II Equipment (Double Insulated) Type BF Applied Part(s) Non-Ionizing Radiation Date of Manufacture Manufacturer This Product Must Not Be Disposed of with Other Household Waste Refer to Instruction Manual/Booklet FCC ID: RYYEYSHSN Re-Order Number Lot Number Serial Number Warning Electricity... -
Page 6: Table Of Contents
Table of Contents Introduction ............................1 Precautions and Warnings .........................1 Precautions ..............................1 Warnings ..............................1 BITS Installation Component List .....................3 BITS Balance Installation Component List ..................5 Tools Needed for Installation ......................7 Unpacking and Setting Up the Hardware Kit ..................7 Adjusting Display Stand Lift Tension ......................8 Computer Installation .........................9 USB Hub .............................. - Page 7 Changing the Administrator Profile Password ..................22 Activating BITS Balance ........................... 23 Changing the Language Preference Settings ..................23 Log Out and Exit ............................26 Technical Specifications ........................26 55" Display Technical Specifications ....................... 26 Motion Sensor Technical Specifications ....................27 Radio Communication Information ......................
-
Page 8: Introduction
• Always exercise universal precautions and wear gloves when cleaning any component of the system. Warnings • Do not move the Bioness Integrated Therapy System over obstacles on the floor or over uneven or soft surfaces. Doing so could cause the equipment to fall causing damage and/or injury. - Page 9 • Refer to the manufacturer's instructions provided with the touchscreen display for additional warnings and safety information. • Bioness Integrated Therapy System is not intended to act as a diagnostic device and does not identify the presence or absence of clinical diagnoses.
-
Page 10: Bits Installation Component List
BITS Installation Component List The components for the BITS product consists of three different kits: Hardware Kit, Software Kit, and Computer Kit. Do not start the installation process until all three kits have been received. BITS Hardware Kit: BIT-2055 (55" Display) Description Illustration (Reference Only) Quantity... - Page 11 BITS Software Kit: BIT-2055 Description Illustration (Reference Only) Quantity Extension USB Cord Wire Loom Zip Ties Mounting Bases Fasteners 2 packages Round Cord Clips 1 package Literature BITS Installation Guide BITS Computer Kit: BIT-2055 Description Illustration (Reference Only) Quantity Computer with Mounting Bracket, Hardware, and Power Adapter with Cord Multi-country AC Plugs...
-
Page 12: Bits Balance Installation Component List
BITS Balance Installation Component List The components for the BITS Balance product consists of two different kits: BITS Balance Accessory Kit and BITS Balance Platform Kit. Do not start the installation process until both kits have been received. Note: BITS Balance components are only shipped if BITS Balance Module has been purchased. BITS Balance Accessory Kit: BIT-3655 Description Illustration (Reference Only) - Page 13 EU Power Cord Note: Verify that all components have been received. Do not start the installation process if any of the listed components are missing. For technical support contact Bioness Product Support Department at 800.211.9136, Option 3 or your Bioness Sales Representative.
-
Page 14: Tools Needed For Installation
Tools Needed for Installation The list below includes items needed to install the BITS. The tools are not provided with the system. • 14mm Wrench • 14mm Socket Driver (optional) • Phillips Screw Driver • Scissors • Safety Gloves • Box Cutter with Safety Guard Unpacking and Setting Up the Hardware Kit 1. -
Page 15: Adjusting Display Stand Lift Tension
Side Cardboard Panel with Foam Inserts Side Cardboard Flap Wooden Ramp Figure 2: Side Cardboard Flaps and Front Panel Figure 3: Knob, Back of Mounting Bracket Adjusting Display Stand Lift Tension The display monitor should be able to move smoothly and easily on the tower of the portable display stand and stay in place. -
Page 16: Computer Installation
Figure 4: Portable Stand Tower Cover (Left), Adjustment Nut on Portable Stand Tower (Right) Computer Installation 1. Open the computer package and verify that the computer, mounting bracket, hardware, and power adapter are present. 2. Attach the computer mounting bracket to the CPU Mount. See Figure 5. Secure with the four screws provided in the Hardware Kit. -
Page 17: Usb Hub
Screws Figure 6: Attaching Screws to Back of the Computer (Left) Attaching Computer to the Computer Mounting Bracket (Right) Note: When attached, the connection ports on the computer will be on the right hand side. USB Hub 1. Remove the USB Hub from its packaging. 2. -
Page 18: Wireless Keyboard
Wireless Keyboard 1. Remove the Wireless Keyboard with integrated touch pad and small USB from package. 2. Plug the small USB into the USB Hub. See Figure 8. 3. Remove the battery protection strip(s) from the bottom of the keyboard. Turn the keyboard on by sliding the switch located on the front panel of the keyboard to the ON position. -
Page 19: Power And Hdmi Cable Installation
Power and HDMI Cable Installation 1. Remove the Touchscreen Display Monitor Power Cord from package and insert into the back of the monitor. 2. Connect the PC Power Adapter to the PC Power Cord and plug it into the PC power port on the right side of the computer. - Page 20 Seam Insert Cables Figure 11: Inserting Cables into the Wire Loom 4. Remove the protective covers from five mounting bases and attach the bases to the back of the Display Monitor. See Figure 12 for suggested attachment locations. The number of mounting bases used and the attachment position will vary depending on the Display Monitor size.
- Page 21 Figure 13: Feeding Zip Tie into Mounting Base (Left), Securing Zip Tie (Right) Figure 14: Inserting PC Power Cord and Display Monitor Cord (example only) 9. Carefully push the Touchscreen Display Monitor down to the lowest position on the tower of the display stand. 10.
-
Page 22: Moving The Bits Display Stand
Slack in Wire Loom Figure 15: Wire Loom Inserted into Left Side of the Tower Covers USB Hub Computer Touch Screen HDMI Cable PC Power Adapter and Power Cable USB Extension Port HDMI Cable Display Monitor Power Cable Touchscreen USB Cable Touchscreen Panel Key Figure 16: Example of BITS with Completed Cable Management... -
Page 23: Samsung Display Monitor
Position of Hands on Tower Position of Touch Screen Display Figure 17: Correct Position for Moving Portable Display Stand 6. Plug the power cord on the Power Strip into a 3 pronged grounded wall outlet. Samsung Display Monitor The Display Monitor requires the use of a Remote Control. See Table 1 below for descriptions of the commonly used buttons on the Remote Control. -
Page 24: Input Source
3. Place the Platform to desired location. Charging the Sensors Warning: Sensor should not be in use while charging. To charge the Sensor: 1. Plug charging block and cable provided by Bioness into a wall outlet. 2. Connect charging cable with Sensor. See Figure 20. -
Page 25: Turning The System On
Charging Port Figure 20: Charging the Sensor Turning the System On 1. Press the On/Off button on the center of the bottom edge of the Display Monitor. 2. Press the On/Off button on the computer. Note: The touchscreen display will enter a sleep mode and shut down when the computer is inactive. While in this sleep mode, turning on the computer will also activate the touchscreen display. -
Page 26: Calibrating The Touch Screen Display
Calibrating the Touch Screen Display 1. Access the Windows 10 Start Screen by pressing the Start button in the lower-left corner of the screen. 2. Click on the tile for the folder called, “PulseIRUtility_1.0.1.8_” 3. A File Explorer window will open. Open the file called, “Pulse IRController.exe” 4. -
Page 27: Date And Time Settings
Figure 23: Calibration Screen Date and Time Settings The computer date, time, and time zone settings will need to be verified. 1. From the Windows Settings menu, select the Time & Language settings icon. See Figure 24. Figure 24: Windows Settings Menu 2. -
Page 28: Printer Setup
Figure 25: Date and Time Settings Menu Printer Setup Only USB connected printers should be connected to the BITS PC. 1. Follow the setup instructions specific to the printer being attached to the BITS PC. 2. Upload the necessary printer drivers onto a USB memory device 3. - Page 29 2. The BITS Login Screen will open. To open the on-screen keyboard, press the Keyboard Icon located at the bottom right of the screen. See Figure 27. Keyboard Icon Figure 27: BITS Login Screen 3. Use the keyboard to enter "admin" as the username and "BITS" as the password. 4.
-
Page 30: Changing The Administrator Profile Password
Changing the Administrator Profile Password For security purposes, it is recommended that the default Administrator Profile Password be changed before adding Client Profiles or entering patient data into the BITS System. 1. From the Home Screen, press the System Settings Button. See Figure 28. 2. -
Page 31: Changing The Language Preference Settings
Changing the Language Preference Settings The default language setting for BITS is English (US). Please note that if BITS Balance is activated, language settings will no longer available. 1. Navigate to the System Settings Screen. 2. Click on the Global Language Preference field. See Figure 30. Global Language Preference Field Date, Time &... - Page 32 Figure 32: Select the Desired Language for Date & Time Format 6. From the Windows Settings menu, select the Time & Language settings icon. See Figure 33. Figure 33: Windows Settings Menu 7. From the Region & Language menu, select the appropriate language and press Set as default. See Figure 34. 8.
-
Page 33: Log Out And Exit
To exit the BITS software application, press the "X" Button located in the upper right corner of the Login Screen. The display screen will return to the operating system's desktop. The installation process for the Bioness Integrated Therapy System is now complete. Technical Specifications 55"... -
Page 34: Motion Sensor Technical Specifications
Radio Communication Information Several components of the Bioness Integrated Therapy System use radio communication. They have been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 (Radio Frequency Devices) of the FCC rules. -
Page 35: Electromagnetic Emissions
The Bioness Integrated Therapy System is medical electrical equipment and applicable components were tested for electromagnetic compatibility (EMC) in accordance with International Electrotechnical Committee (IEC) 60601-1-2. The Bioness Integrated Therapy System should be configured and used in accordance with the instructions provided in this guide. -
Page 36: Patch Technical Specifications
Cleaning Single Use Only Software Specifications Software Specifications The Bioness Integrated Therapy System (BITS) is intended to challenge and assess the visual, auditory, cognitive, motor, and balance abilities of individuals, including those with deficits resulting from traumatic injuries and movement disorders as well as competitive athletes.
