Bioness NESS H200 User Reference Manual

User's Reference Card
Charging the H200 Wireless System
Connect the System Charger Set to the H200 Wireless Orthosis and the H200 Wireless
Control Unit simultaneously. Charge the H200 Wireless System daily.
H200 Wireless
Control Unit
System
Charger Set
Putting on the H200 Wireless Orthosis
Wet and attach the cloth electrodes.
1
Position the Orthosis on a stable surface, and put your hand into the spiral end. The Thenar
2
(with attached electrode) should rest at the base of your thumb.
Position the wrist bridge comfortably on the back of your wrist.
3
Place your forearm in the Orthosis flexor support.
4
Close the extensor wing.
5
Fasten the wrist strap, if appropriate.
6
1 2
H200 Wireless Orthosis Displays
System On
Status Light
Flashes Green
